Image preview - the first page of the document
>> Download Схема в разобранном виде и список деталей documenatation <<
Text preview - extract from the document
Exploded View & Part List
4. Exploded View & Part List
4-1 PS42E71SX/BWT
You can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
FT532 2901-001374 FILTER-EMI AC LINE 250V,6A,UL/SA/VDE,0.1 1 S.A
M0013 BN96-03527A ASSY STAND P-BASE 42E71,HIPS HB,SV012P,R 1 S.A
M0013 BN96-03069A ASSY COVER P-REAR 42E7,PCM T0.5 1 S.A
M0013 BN96-03070B ASSY COVER P-REAR BOTTOM 42E7,HIPS HB,BK 1 S.A
M0020 BN96-03075A ASSY BOARD P-SIDE A/V AUDI,SJ05-01-430,S 1 S.A
M0112 BN63-02367D COVER-FRONT 42E7S,HIPS,HB,GRAY,BKP-1526+ 1 S.N.A
T0448 M0145 BN96-02784A ASSY BOARD P-FUNCTION TWISTER,CT5000-385 1 S.A
M0013 M0146 BN96-02050D ASSY BOARD P-POWER & IR Twister,CT5000-3 1 S.A
T0003 BN96-03625D ASSY COVER P-FRONT 42E7S(HQ),XEC,HIPS HB 1 S.A
T0023 BN64-00419A KNOB-POWER 42V6,PC,VIOLET 1 S.N.A
T0023 BN64-00421A KNOB POWER 42V6,DECO,ABS,HB,BLK(BK500),C 1 S.N.A
T0044 BN96-03073A ASSY PDP MODULE P M1,SPD-42D5SD,D71C,V5. 1 S.A
T0152 T0057 BP64-00177A BADGE-BRAND ALL,AL,T1.5,70,11.3,BLK,SILI 1 S.N.A
T0074 T0268 T0079
FT532 T0059 BN64-00366A INDICATOR LED ROME-I,PC,CLEAR,ALL MODEL 1 S.N.A
T0312 T0060 BN61-02184A SPRING ETC SUS304,OD11.2,L30,N7 1 S.N.A
T0074 BN59-00531A REMOCON AUDI,TM86,SAMSUNG,45Key,31mArms, 1 S.A
T0159 T0079 BN94-00933B ASSY PCB MISC-MAIN PS-42E7S,EU,D74A,AUDI 1 S.A
T0044 T0152 BN96-01774A ASSY BRACKET P-WALL RIGHT SPD-42P5HD,SEC 1 S.N.A
T0448 M0013 T0159 BN96-03052A ASSY PCB P-SMPS PS42E7H,100~240V,245*370 1 S.A
T0175 BN96-02785A ASSY SPEAKER P 8ohm,Twister,42inch,10W 1 S.A
T0268 3903-000145 CBF-POWER CORD DT,EU,FP3/YES,U(IEC C13-R 1 S.A
T0312 BN96-03067A ASSY COVER P-REAR SUB 42E7,SECC,T1.0,AUD 1 S.N.A
T0448 BN96-01775A ASSY BRACKET P-WALL LEFT SPD-42P5HD,SECC 1 S.N.A
M0020 T0448 BN96-03068A ASSY BRACKET P-TERMINAL 42E7,XEC,PCM T0. 1 S.A
T0456
T0456 BN67-00160A GLASS-FILTER EMI 42V4,Sputter,NTR,T=49%, 1 S.N.A
T0003 M0013
M0112
T0175
T0059
M0146
T0057
T0060
T0023 M0145
T0023
Samsung Electronics 4-1
