Image preview - the first page of the document
>> Download Alignment & Adjustment documenatation <<
Text preview - extract from the document
Alignment and Adjustments
2. Alignment and Adjustments
2-1 Service Mode
2-1-1 SERVICE MODE Entry Method (General Transmitter)
For the General Transmitter
1. Turn the power off and set to stand-by mode.
2. Press the buttons of the transmitter in this order; INFO-MENU-MUTE-POWER ON to turn the set on.
3. The set turns on and enters service mode.
For the Factory Transmitter
1. Turn the power on.
2. Press the buttons of the transmitter in this order : INFO-Factory.
3. The set enters service mode.
* If you fail to enter service mode, repeat steps 1 and 2 above.
2-1-2 Initial DISPLAY State of SERVICE MODE
2-1-2(A) OSD DISPLAY
Factory Mode Current Input Mode Indicates selected input mode
01. Picture Improvement Picture Adjustment
02. Initial Setting Setting the Initial Values
03. PIP/TTX/Test Pattern Setting the Special Features
04. Option-1 Options-1 : Options of the Product Particulars
05. Option-2 Options-2 : Options of the PDP Properties
06. Reset Initializing after saving the adjustments
Software Version Information
Release : Oct 06 2004 11 : 41 : 14
Version : T-NPL42PEU1-1215
2-1-2(B) Button Operations in SERVICE MODE
Menu Displays all menus
UP/DOWN Cursor move to select items
LEFT/RIGHT Enable to increase and decrease the data of the selected items
(ENTER) Confirm your choice(Store OR Enter)
Samsung Electronics 2-1
Alignment and Adjustments
2-2 WHITE Balance Coordinates
2-2-1 PS42P4A1 White Balance Adjustment
1. W/B Adjustment is required for the following four modes: DVI-> COMPONENT-> PC->VIDEO
2. Adjustment Method
(Signal equipment : MSPG-925LTH, Measurement equipment : CA210)
(1) Adjust the target set by adjusting the panel logic and the video DNIe adjustment register in
order to determine the referential W/B of the panel with a DVI input, which is the full digital path.
(2)For Component adjustment, adjust the adjustment register of AD9883 to align the DTV signal
to the DNIe and logic panel value which was fixed with a DVI adjustment so that they are
in effect considered to be the same signals. (At this time, do not adjust the gain of AD9883 -> the Highlight W/B does not need
to be adjusted since its deviation falls within valid distribution range.)
(3)PC adjustment is same as Component adjustment. (The offset can be applied to the values obtained through DTV adjustment.
However, additional adjustment is required for Y, Cb, and Cr of Component since PC processes R, G, and B signals.)
* Attention for Component/PC adjustment
- Load the Auto color pattern. (Pattern #21)
- Excute Auto color of factory mode to adjust gain and offset.
- Load the Toshiba Pattern.(Pattern #16) and then adjust W/B.
(4)Video adjustment is performed with the Toshiba pattern (in-house signal) and differs from the VG828 signals in the above
three modes. Hence, it should be performed with the same method of (1) DVI adjustment.
Also, Video adjustment should be performed with Video port and Graphic port separately.
* Thus, Micom saves the W/B data separately for each memory mode of the block (See the block diagram given below) during W/B
adjustment.
2-2 Samsung Electronics
Alignment and Adjustments
1-2-2 White Balance Coordinates by Mode
VIDEOI Component PC DVI
x 268 268 283 283
H/L y 263 263 295 295
Y(fL) 32 32 30 28
x 268 268 283 283
L/L y 263 263 295 295
Y(fL) 1.6 1.4 0.9 0.9
1-3 Factory Data
1-3-1 Factory OSD Main Menu
Factory Mode Current Input Mode Indicates selected input mode
01. Picture Improvement Picture Adjustment
02. Initial Setting Setting the Initial Values
03. PIP/TTX/Test Pattern Setting the Special Features
04. Option-1 Setting the Options of the Product Particulars
05. Option-2 Setting the Options of the PDP Properties
06. Reset Initializing after saving the adjustments
Software Version Information
Release : Oct 06 2004 11 : 41 : 14
Version : T-NPL42PEU1-1215
01.Picture Improve
01.Picture Improvement Current Input Mode
01. White Balance White Balance Adjustment
02. Color Color Adjustment
03. Cont/Bri Enhancement Contrast & Brightness Enhancement
04. Detail Enhancement Detail Enhancement Sharpness Adjustment
05. Y/C Delay Y/C Delay Setting according to the System and
Input Modes
06. Motion Motion Enhancing Adjustment
07. DNIe DNIe Registers
08. DNIe Additional DNIe Registers
09. Logic Logic Registers of the Panel
10. Picture Size Picture Size Registers
Samsung Electronics 2-3
Alignment and Adjustments
01.Picture Improve => 01.White Balance Adjustment
Initial Values of Input Modes
ITEM Relevant IC
Video Component PC DVI
01.White Balance TV Mode-1 Mode-2 Mode-3 Mode-4
01.R Drive 128 128 128 128 128
02.G Drive 128 128 128 128 128
03.B Drive 128 128 128 128 128
DNIe
04.R Cutoff 120 120 120 120 120
05.G Cutoff 120 120 120 120 120
06.B Cutoff 120 120 120 120 120
07.Sub Contrast 31 W/B W/B W/B W/B
ASI510
08.Sub Brightness 63 W/B W/B W/B W/B
09.R Gain X x 128 128 x
10.G Gain X x 144 128 x
11.B Gain X x 128 128 x
12.R/Cr Offset X AD9883 x 64 64 x
13.G/Y Offset X x 53 64 x
14.B/Cb Offset X x 64 64 x
15.Auto color on/off x X X x
h Input modes require respective storing the changes after adjustment.
01~06 : DNIe
07~08 : ASI510
09~15 : AD9883
2-4 Samsung Electronics
Alignment and Adjustments
01.Picture Improve => 02.Color Adjustment
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
02.Color TV Mode-1 Mode-2 Mode-3 Mode-4
01.U-Saturation 32 32 x x x
02.V-saturation 34 34 x x x
03.RGB/YUV U-SAT 24 VSP9437 24 x x x
04.RGB/YUV V-SAT 24 24 x x x
05.RGB/YUV Tint 3 3 x x x
06.FLI-saturation 120 FLI2310 120 x x x
07.R Gamma 32 32 32 32 32
08.G Gamma 32 ASI510 32 32 32 32
09.B Gamma 32 32 32 32 32
10.Gain-Sel 1 1 x x x
11.Cr Gain 7 7 x x x
CXA2151
12.Cb Gain 7 7 x x x
13.Y Gain 1 1 x x x
14.FLI - Y/G Bir 0 0 0 0 0
15.FLI - Cr/R Bir 0 FLI2310 0 0 0 0
16.FLI - Cb/B Bir 0 0 0 0 0
01 ~05 : VSP9437
07~09 : ASI510
06 , 14~16 : FLI2310
10~13 : CXA2151
Samsung Electronics 2-5
Alignment and Adjustments
01.Picture Improve => 03.Contrast & Brightness Enhancement
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
03.Cont/Bri Enhancement TV Mode-1 Mode-2 Mode-3 Mode-4
01.Contrast 32 32 x x x
02.Brightness 45 45 x x x
VSP9437
03.RGB/YUV Contrast 37 37 x x x
04.RGB/YUV Brightness 10 10 x x x
05.FLI-Contrast 100 100 x x x
FLI2310
06.FLI-Brightness 128 128 x x x
07.R Contrast 32 32 32 32 32
08.G Contrast 32 32 32 32 32
09.B Contrast 32 32 32 32 32
ASI510
10.R Brightness 0 0 0 0 0
11.G Brightness 0 0 0 0 0
12.B Brightness 0 0 0 0 0
01~04 : VSP9437
07~12 : ASI510
05~06 : FLI2310
2-6 Samsung Electronics
Alignment and Adjustments
01.Picture Improve => 04.Detail Enhancement
Initial Values of Input Modes
ITEM Relevant IC
Video Component PC DVI
04.Detail Enhancement TV Mode-1 Mode-2 Mode-3 Mode-4
01.VAPGAIN x x x x x
02.VAPINV x x x x x
uPD64083
03.YPFT x x x x x
04.YPFG x x x x x
05.APK-1st-BPM 1 1 x x x
06.APK-2nd-BPM 2 2 x x x
07.Denoise-BPM 1 1 x x x
VSP9437
08.APK-1st-HPM 5 5 x x x
09.APK-2nd-HPM 2 2 x x x
10.Denoise-HPM 0 0 x x x
11.HenhGain 64 64 x x x
12.HLEGain 64 FLi2310 64 x x x
13.HChrEnGain 32 32 x x x
01~04 : uPD64083
05~10 : VSP9437
11~13 : FLI2310
Samsung Electronics 2-7
Alignment and Adjustments
01.Picture Improve => 05.Y/C Delay Setting according to the System and Input Modes
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
05.Y/C Delay TV Mode-1 Mode-2 Mode-3 Mode-4
01. PAL-B/G 254 254 x x x
02. PAL-D/K/L 254 254 x x x
03. PAL-I 254 254 x x x
04. SECAM-B/G 254 254 x x x
05. SECAM-D/K/L 251 251 x x x
06. NTSC 254 VSP9437 254
07. PAL-AV 254 254
08. SECAM-AV 252 252
09. NTSC-AV 254 254
10. RGB/YUV-Y 90 90
11. RGB/YUV-UV 90 90 x x x
12. FLI-Y 5 5 x x x
FLI2310
13. FLI-C 11 11 x x x
01~11 : VSP9437
12~13 : FLI2310
01.Picture Improve => 06.Motion Enhancing Adjustment
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
06.Motion TV Mode-1 Mode-2 Mode-3 Mode-4
01.HPLL Speed-1 0 VSP9437-M 0 x x x
02.HPLL Speed-2 0 VSP9437-S 0 x x x
03.V-motion Tresh 32 FLi2310 32 x x x
04. Chrominance coring 0 VSP9437-UVCORM 0 x x x
01 : VSP9437-M
02 : VSP9437-S
03 : FLI2310
04 : VSP9437-UVCORM
2-8 Samsung Electronics
Alignment and Adjustments
01.Picture Improve => 07.DNIe Registers
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
07.DNIe TV Mode-1 Mode-2 Mode-3 Mode-4
01.SUB BRIGHT W/B W/B W/B W/B W/B
02.SUB CONT W/B W/B W/B W/B W/B
03.SCALE MAX 48 48 48 48 48
04.SCALE MIN 16 16 16 16 16
05. DCE CUTOFF 16 16 16 16 16
06. DCE UPPER 230 230 240 240 240
07. R GAIN 1X 12 12 16 10 10
08.CE UPPER 220 220 240 240 240
09.CE CUTOFF 32 32 32 32 32
10. R GAIN 1Y 11 11 11 6 6
11. R D ALPHAL 100 100 64 64 64
12. R GAIN 2X 8 8 6 4 4
13. R GAIN 2Y 8 DNIe 8 6 2 2
14. R ND ON 1 1 1 1 1
15. R CORING ON 1 1 1 1 1
16. PATT SEL 0 0 0 0 0
17. R CORING TH1 1 1 1 2 2
18. R CORING TH2 1 1 1 2 2
19. R CORING TH3 1 1 1 2 2
20. BLACK GAIN 69 69 69 69 69
21. WHITE GAIN 156 156 26 26 26
22. WTE GAIN 300 300 300 300 300
23. CTE GAIN 0 0 0 0 0
03~23 : DNIe
Samsung Electronics 2-9
Alignment and Adjustments
01. Picture Improve => 08. DNIe Additional
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
08. DNIe Additional TV Mode-1 Mode-2 Mode-3 Mode-4
01. R D ALPHAU 60 60 75 75 75
02. R BLACK GAIN MAX 320 320 358 358 358
03. R BLACK TILT 90 90 90 90 90
DNIe
04. R WHITE GAIN MAX 300 300 358 358 358
05. DNIe Gamma 0 0 0 0 0
06. R GAIN3 X 3 3 1 0 0
01 ~ 06 : DNIe
2-10 Samsung Electronics
Alignment and Adjustments
01.Picture Improve => 09.Logic Registers
ITEM Relevant IC Video Component PC DVI
09. Logic TV Mode-1 Mode-2 Mode-3 Mode-4
01. CNDC(READ) 68 0 0 0 0
02. ERRS 0 0 0 0 0
03. ERRC(READ) 98 0 0 0 0
04. DSPBIT 0 0 0 0 0
05. QMODE 2 2 2 2 2
06. CCFMD 0 0 0 0 0
07. DCFMD 0 1 1 0 0
08. DSETEN 0 Logic 0 0 0 0
09. CCFON 0 0 0 0 0
10. CCFORM 0 0 0 0 0
11. GAMSEL 2 2 2 2 2
12. R-RATIO 255 255 255 255 255
13. G-RATIO 235 255 255 235 235
14. B-RATIO 240 255 255 240 240
15. GAMOO 31 31 31 31 31
16. PWMP 0 0 0 0 0
17. PWMAX 3 3 3 3 3
18. DSET 0 0 0 0 0
01~18 : Logic
Samsung Electronics 2-11
Alignment and Adjustments
01.Picture Improve => 10.Picture Size Registers
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
10.Picture Size TV Mode-1 Mode-2 Mode-3 Mode-4
01. H START OFFSET 0 0 0 0 0
02. V START OFFSET 0 0 0 0 0
03. H END OFFSET 0 0 0 0 0
04. V END OFFSET 0 ASI510 0 0 0 0
05.OVERSCAN B 63 63 63 63 63
06.OVERSCAN G 63 63 63 63 63
07.OVERSCAN R 63 63 63 63 63
01~07 : ASI510
02.Setting the Initial Values
02.Initial Setting Current Input Mode Indicates selected input mode
Reset after saving the P-Mode adjustments
01. Initial P-Mode
P-MODE the data Values
02. P-Mode Value
Reset after saving the color tone adjustments
03. Initial Color Tone
Color tone the data Values
04. Color Tone Value
02.Initial Setting => 01.Initial P-Mode
01.Initial P-Mode Current Input Mode
01. Dynamic Available options for the PC/DVI Mode are High,Middle,
02. Standard Low and Custom.
03. Movie
04. Custom
02.Initial Setting => 02.P-Mode Value
02. P-Mode Value Current Input Mode
01. Dynamic Available options for the PC/DVI Mode are High,Middle,
02. Standard Low and Custom.
03. Movie
04. Custom
2-12 Samsung Electronics
Alignment and Adjustments
02.Initial Setting => 02.P-Mode Value => 01.Dynamic
01.Dynamic Current Input Mode
01. Contrast 100
02. Brightness 45
03. Sharpness 75
04. Color 55
05. Tint 50
02.Initial Setting => 02.P-Mode Value => 02.Standard
02.Standard Current Input Mode
01. Contrast 80
02. Brightness 50
03. Sharpness 50
04. Color 50
05. Tint 50
02.Initial Setting => 02.P-Mode Value => 03.Movie
03.Movie Current Input Mode
01. Contrast 50
02. Brightness 55
03. Sharpness 25
04. Color 40
05. Tint 50
02.Initial Setting => 02.P-Mode Value => 04.Custom
04.Custom Current Input Mode
01. Contrast 80
02. Brightness 50
03. Sharpness 50
04. Color 50
05. Tint 50
02.Initial Setting => 03.Initial Color Tone
02.Initial Setting Current Input Mode Available Settings for the PC Mode are
01. Cool2 Custom,Color Tone 1, Color Tone 2, Color Tone 3
02. Cool1
03. Normal Available options for the DVI Mode are
04. Warm1 ColorTone1, ColorTone2, ColorTone3
05. Warm2
Samsung Electronics 2-13
Alignment and Adjustments
02.Initial Setting => 04.Color Tone Value
Adjusting and Storing the Changes:
04.Color Tone Value Current Input Mode Change the White Balance (Color Temperature)
01. Cool2 1. Selecting an item will display the same options to
02. Cool1 those of the White Balance.
03. Normal 2. Available options for the PC Mode are Custom,Color
04. Warm1 Tone 1, Color Tone 2, Color Tone 3
05. Warm2 3. Available options for the DVI Mode are ColorTone1,
ColorTone2, ColorTone3.
4. Data Storing is classifled according to the PC Mode
& Other Modes.
03.PIP/TTX/Test Pattern
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
03.PIP/Test Pattern TV Mode-1 Mode-2 Mode-3 Mode-4
01.PIP R CONT 32 32 32 32 32
02.PIP G CONT 32 32 32 32 32
03.PIP B CONT 32 32 32 32 32
04.PIP R BRIGHT 0 0 0 0 0
05.PIP G BRIGHT 0 0 0 0 0
ASI510
06.PIP B BRIGHT 0 0 0 0 0
07.PIP FILTER LC 0 0 0 0 0
08.PIP FILTER ML 0 0 0 0 0
09.PIP FILTER MR 0 0 0 0 0
10.PIP FILTER UC 0 0 0 0 0
11. TTX CONT 0 0 0 0 0
SDA6001
12. TTX BRIGHTNESS 0 0 0 0 0
13.LOG PATTERN 0 0 0 0 0
14.LOG HIGH LEVEL 255 Logic 255 255 255 255
15.LOG LOW LEVEL 0 ASI510 0 0 0 0
16.ASI COLORBAR 1 1 1 1 1
01~10 : ASI510
11~12 : SDA6001
13~16 : Logic, ASI510
2-14 Samsung Electronics
Alignment and Adjustments
04.Option-1
04.Option-1 Current Input Mode
00. AGC Off
01. SCART/RCA SCART 00. Off => On
02. CW/CS CW 01. Scart(Full input) => RCA(Scart delete)
03. TELE-WEB OFF 02. CW(EUROPE) => CS(SOUTHASIA)
04. LANGUAGE GROUP EUROPE 03. Off => On
05. LANGUAGE ENGLISH 04. Europe => Asia
06. ATM ON 05. English => 18 Language(Europe)
07. Melody Volume 4 06. On => Off
08. LNA Search OFF 07. On => Off
09. LNA ON 08. On => Off
10. CHILD LOCK ON 09. On => Off
11. TOP TTX ON 10. On => Off
12. TTX GROUP Language 11. On => Off
13. HIGH DEVIATION ON 12. W.Europe => 6 Group
14. SD Delay 3 13. Off => On
15. HD Delay 2 14. O(default),1(27ms),2(54ms),3(108ms)
16. Video Port Graphic 15. O(default),1(27ms),2(54ms),3(108ms)
17. Debugger OFF
18. DRC-Level OFF
19. Initial Write OFF
01. Scart/RCA : Scart => RCA
- Scart : Europe and the region where using Scart
- RCA : Southeast Asia and the region where using RCA
02. CW/CS : CW => CS
- CW : PAL, SECAM-B/G, D/K, I, L/L', NTSC4.43 = West Europe
- CS : PAL, SECAM-B/G, D/K, I, NTSC3.58/4.43 = Countries except West Europe.
Ex) Southeast Asia,the Middle East,Russia,China, etc.
03. Tele-Web
- Off : TeleWeb non-broadcasting Country
- On : TeleWeb broadcasting Country
04. Language Group : Europe => Asia
-. Europe : 18 languages
-. Asia : 7 languages
05. Language : Select language
- Language Group is Europe : 18 languages
(English=>Bulgarian=>Croatian=>Czechoslovak=>Netherlandish=>French=>German=>Greek=>Hungarian=>
Italian=>Poland=>Portuguese=>Rumanian=>Russian=>Spanish=>Swedish=>Turki=>Yugoslave)
- Language Group is Asia : 7 languages
(English=>Arabic=>French=>Indonesian=>Malay=>Persian=>Chinese)
06. ATM : On => Off
-. ATM available region : On
-. ATM non-available region : Off
07. Plug & Play
-. On : TV Model and plug&play funtion deletion model.
-. Off : Monitor Model
Samsung Electronics 2-15
Alignment and Adjustments
08. Tuner
-. 2-Tuner / 1-Tuner / Off
09. LNA
- On : Using LNA built-in Tuner
- Off : Not in use LNA built-in Tuner
10. Child Lock
-. On : TV Model
-. Off : Model has deletion of Child Lock function
11. Top TTX
- On : Only Top broadcasting region set 'On'
Ex) Germany, Switzerland, etc
- Off : Country except Top broadcasting region.
12. TTX Group : TTX Language Group and National Option Code
- By language, Select at the factory option table.
- TTX language will be displayed by National Option code.
- TTX Language Group by each country : 6 Groups
West Europe => East Europe => Turkish/Greek => Cyrillic => Arabic/Hebrew => Farsi/Hebrew
13. High Deviation : To prevent the Sound Buzz according to the regional characteristics of the input signal.
- Set to `Off' for the standardized sound input signal, in the region such as Europe.
- Set to `On' for the over-modulated sound input signal, in the region such as Southeast Asia.
14. SD Delay : AV mode Delay
1.8ms delay --------- delay0
27ms delay --------- delay1
54ms delay --------- delay2
108ms delay (max) --------- delay3
15. HD Delay : DTV/PC/DVI mode Delay
05.Option-2
05.Option-2 Current Input Mode 00. On => Off
00. Pixel Shift Not Use 01. 0: minute , 1: SEC
01. Shift Test 0 02. Left,right movement Pixel
02. Pixel Number 1 03. Upper, low movement Pixel
03. Shift Line 1 04. Shift Test
04. Shift Time Not Use
05. Number Range Not Use
06. Line Range Not Use
07. Temp Protection On
08. DNIe DEMO On
09. PILOT HIGH 21
10. PILOT LOW 16
11. CHECKSUM 0000
2-16 Samsung Electronics
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
