Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
Exploded View & Parts List
3. Exploded View & Parts List
3-1 PS42P4A1X/XEC
Loc.No Code No Description;Specification Q'ty S.N.A
T0554 BN96-00996B ASSY MISC P-BRKT FRONT;42P4A,AL,NEW 1 S.N.A
T0555 BN96-00723A ASSY MISC P-BRKT TERMINAL;PS42P4A 1 S.N.A
T0003 BN96-00997C ASSY COVER P-FRONT;42P4A,ABS+ACRYL,HB,GU 1
T0008 BN96-01077B ASSY COVER P-BACK SUB;42P4A,SECC,T0.8 1 S.N.A
T0001 BN96-00998B ASSY COVER P-BACK;42P4A,AL,T1.2 1
T0054 SCREEN-EMI,FILTER;FILTER,42P3,984*584,T3 1
FT532 2901-001278 FILTER-EMI AC LINE;250V,6A,-,1000PF,50X2 1
T0132 BN94-00625B ASSY PCB MISC-DIGITAL;PS42P4A1X/XEC,D68A 1
T0091 BN94-00519A ASSY PCB MISC-SIDE A/V;PS42P4AX/XEC,D68A 1
M0145 BN96-01033A ASSY BOARD P-FUNCTION;SPD-42P4HD,FUNCTIO 1
T0714 BN96-01034A ASSY BOARD P-IR;SPD-42P4HD,IR 1
T0044 BN96-00774A ASSY PDP MODULE P;FPF42C128128UC-S3,994 1
T0152 BN94-00626A ASSY PCB MISC-TUNER;PS42P4A1,D68A,DNIE3 1
T0074 BN59-00397B REMOCON;MOZART,TM77,SAMSUNG,D65A,47,EX,P 1
T0268 3903-000145 CBF-POWER CORD;DT,EU,FP3/YES,U(IEC C13-R 1
Samsung Electronics 3-1
Exploded View & Parts List
3-2 MODULE BLOCK
3-2 Samsung Electronics
