Image preview - the first page of the document
>> Download 03_Alignment & Adjustment documenatation <<
Text preview - extract from the document
Alignment and Adjustments
2. Alignment and Adjustments
2-1 Service Mode
2-1-1 SERVICE MODE Entry Method
For the General Transmitter
1. Turn the power off and set to stand-by mode.
2. Press the buttons of the transmitter in this order; INFO-MENU-MUTE-POWER ON to turn the set on.
3. The set turns on and enters service mode.
For the Factory Transmitter
1. Turn the power on.
2. Press the buttons of the transmitter in this order : INFO-Factory.
3. The set enters service mode.
* If you fail to enter service mode, repeat steps 1 and 2 above.
2-1-2 Initial DISPLAY State of SERVICE MODE
2-1-2(A) OSD DISPLAY
Factory Mode Current Input Mode Indicates selected input mode
01. Picture Improvement Picture Adjustment
02. Initial Setting Setting the Initial Values
03. PIP/TTX/Test Pattern Setting the Special Features
04. Option-1 Options-1 : Options of the Product Particulars
05. Option-2 Options-2 : Options of the PDP Properties
06. Reset Initializing after saving the adjustments
Software Version Information
Release : 2004-06-10-10:15
Version : T-NPL42PEA-1108
2-1-2(B) Button Operations in SERVICE MODE
Menu Displays all menus
UP/DOWN Cursor move to select items
LEFT/RIGHT Enable to increase and decrease the data of the selected items
(ENTER) Confirm your choice(Store OR Enter)
SOURCE Change input source
While in Tuner mode, the direct access buttons can be used to select and change channels.
Samsung Electronics 2-1
Alignment and Adjustments
2-2 WHITE Balance Coordinates
2-2-1 PS-42P4H White Balance Adjustment
1. W/B Adjustment is required for the following six modes :
DVI ' Component(1080i) ' Component(720p) ' PC ' VIDEO (Video port) ' VIDEO (Graphic port)
2. Adjustment Method (Signal equipment : MSPG-925LTH, Measurement equipment : CA210)
MSPG-925LTH
Equipment that outputs analog and digital signals simultaneously
(Analog / Digital signal output / TV signal output (S-Video included) / HDTV signal output)
-. Digital Serial : TMDS (DVI24, SiI160) + DVI-I (Analog, Digital)
-. Monitor Signal (Analog): R, G, B, HS, VS, CS
-. TV Signal (CVBS) : NTSC M, NTSC J (7.5 IRE On/Off) (BNC or RCA), PAL B, D, G, H, I, PAL M, Nc
-. D-TV Signal (1080i, 720p, 480p)
MSPG-925 is used to adjust the W/B.
CA210 : Color Analyzers adjusting brightness, chromaticity and etc.
-. R.G.B monochrome correction, brightness and gamma character adjustment
-. White Balance and flickering measurement
(a) DVI
1) Input Toshiba pattern (#16) at 720p resolution.
2) Select 02. Picture Improvement -> 01. White Balance.
3) Adjust items 07(Sub Contrast) & 08(Sub Brightness).
4) Adjust Items 01-03 (RGB Drives) and Items 04-06 (RGB Cutoffs).
(b) Component
1) Input Toshiba Pattern (#16) at 1080i resolution.
2) Select 01. Picture Improvement > 01. White Balance.
3) Adjust White Balance by selecting and adjusting Items 01. - 08. as performed in DVI mode.
4) Change input to Toshiba Pattern (#16) at 720p resolution.
5) Adjust White Balance by selecting and adjusting Items 01. - 08. as performed in DVI mode.
(c) PC
1) Input Toshiba Pattern (#16) in PC input at 1024 x 768 @ 60Hz.
2) Select 01. Picture Improvement -> 01. White Balance.
3) Adjust White Balance by selecting and adjusting Items 01 - 08 as performed in DVI mode.
(d) Video
The video signal uses the video port when there is no other input signal.
However, signal uses the graphic port in PIP mode, which includes other input signals (PC, DVI, Component, etc.), Video
adjustment should be performed with Video portand Graphic port separately.
2-2 Samsung Electronics
Alignment and Adjustments
1) Input Toshiba Pattern (#16) to Video Input.
2) Select 04. Option-1 -> 10. Video Port.
3) Set 10. Video Port equal to Video.
4) At Main SVC Menu, select 01. Picture Improvement -> 01. White Balance.
5) Adjust Items 01 - 08 as performed in DVI mode.
6) Return to Main SVC menu and select 04. Option-1 -> 10. Video Port.
7) Set 10. Video Port equal to Graphic.
8) At Main SVC Menu, select 01. Picture Improvement -> 01. White Balance.
9) Adjust Items 01 -> 08 as performed in DVI Mode.
* Thus, Micom saves the W/B data separately for each memory mode of the block (See the block diagram given below) during
W/B adjustment.
Samsung Electronics 2-3
Alignment and Adjustments
2-2-2 White Balance Coordinates by Mode
VIDEO Component PC DVI
x 269 269 285 285
H/L y 273 273 295 295
Y(fL) 35 37 30 33
x 269 269 285 285
L/L y 273 273 295 295
Y(fL) 2.5 0.9 0.9 0.8
2-3 Factory Data
2 -3-1 Factory OSD Main Menu
Factory Mode Current Input Mode Indicates selected input mode
01. Picture Improvement Picture Adjustment
02. Initial Setting Setting the Initial Values
03. PIP/TTX/Test Pattern Setting the Special Features
04. Option-1 Setting the Options of the Product Particulars
05. Option-2 Setting the Options of the PDP Properties
06. Reset Initializing after saving the adjustments
Software Version Information
Release : 2004-06-10-10:00
Version : T-NPL42PEA-1108
01.Picture Improve
01.Picture Improvement Current Input Mode
01. White Balance White Balance Adjustment
02. Color Color Adjustment
03. Cont/Bri Enhancement Contrast & Brightness Enhancement
04. Detail Enhancement Detail Enhancement Sharpness Adjustment
05. Y/C Delay Y/C Delay Setting according to the System and
Input Modes
06. Motion Motion Enhancing Adjustment
07. DNIe DNIe Registers
08. DNIe Additional DNIe Registers
09. Logic Logic Registers of the Panel
10. Picture Size Picture Size Registers
2-4 Samsung Electronics
Alignment and Adjustments
01.Picture Improve => 01.White Balance Adjustment
Initial Values of Input Modes
ITEM Relevant IC
Video Component PC DVI
01.White Balance TV Mode-1 Mode-2 Mode-3 Mode-4
01.R Drive 128 128 128 128 128
02.G Drive 128 128 128 128 128
03.B Drive 128 128 128 128 128
Logic
04.R Cutoff 120 120 120 120 120
05.G Cutoff 120 120 120 120 120
06.B Cutoff 120 120 120 120 120
07.Sub Contrast 31 W/B W/B W/B W/B
DNIe
08.Sub Brightness 63 W/B W/B W/B W/B
09.R Gain X x 142 142 x
10.G Gain X x 142 142 x
11.B Gain X x 142 142 x
12.R/Cr Offset X AD9883 x 60 60 x
13.G/Y Offset X x 48 48 x
14.B/Cb Offset X x 64 64 x
15.Auto color on/off x O O x
Input modes require respective storing the changes after adjustment.
01~06 : Logic
07~08 : DNIe
09~15 : AD9883
Samsung Electronics 2-5
Alignment and Adjustments
01.Picture Improve => 02.Color Adjustment
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
02.Color TV Mode-1 Mode-2 Mode-3 Mode-4
01.U-Saturation 36 35 x x x
02.V-saturation 36 35 x x x
03.RGB/YUV U-SAT 22 VSP9437 22 x x x
04.RGB/YUV V-SAT 22 22 x x x
05.RGB/YUV Tint 3 3 x x x
06.FLI-saturation 110 FLI2310 125 x x x
07.R Gamma 29 29 32 32 32
08.G Gamma 29 ASI510 29 32 32 32
09.B Gamma 29 29 32 32 32
10.Gain-Sel 1 x 1 x x
11.Cr Gain 7 x 7 x x
CXA2151Q
12.Cb Gain 7 x 7 x x
13.Y Gain 1 x 1 x x
01 ~05 : VSP9437
07~09 : ASI510
06 , 14~16 : FLI2310
10~13 : CXA2151
2-6 Samsung Electronics
Alignment and Adjustments
01.Picture Improve => 03.Contrast & Brightness Enhancement
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
03.Cont/Bri Enhancement TV Mode-1 Mode-2 Mode-3 Mode-4
01.Contrast 32 32 x x x
02.Brightness 48 45 x x x
VSP9437
03.RGB/YUV Contrast 32 Scart_RGB:32 ,YUV:35 x x x
04.RGB/YUV Brightness 16 16 x x x
05.FLI-Contrast 128 128 x x x
FLI2310
06.FLI-Brightness 128 128 x x x
07.R Contrast 32 32 32 32 32
08.G Contrast 32 32 32 32 32
09.B Contrast 32 32 32 32 32
ASI510
10.R Brightness 0 0 0 0 0
11.G Brightness 0 0 0 0 0
12.B Brightness 0 0 0 0 0
01~04 : VSP9437
07~12 : ASI510
05~06 : FLI2310
Samsung Electronics 2-7
Alignment and Adjustments
01.Picture Improve => 04.Detail Enhancement
Initial Values of Input Modes
ITEM Relevant IC
Video Component PC DVI
04.Detail Enhancement TV Mode-1 Mode-2 Mode-3 Mode-4
01.VAPGAIN x x x x x
02.VAPINV x x x x x
uPD64083
03.YPFT x x x x x
04.YPFG x x x x x
05.APK-1st-BPM 1 1 x x x
06.APK-2nd-BPM 0 0 x x x
07.Denoise-BPM 0 0 x x x
VSP9437
480i,Scart_RGB:5,
08.APK-1st-HPM 7 x x x
Etc. Input mode:7
09.APK-2nd-HPM 3 3 x x x
10.Denoise-HPM 0 0 x x x
11.HenhGain 64 FLi2310 64 x x x
12.HLEGain 64 64 x x x
01~04 : uPD64083
05~10 : VSP9437
11~12 : FLI2310
2-8 Samsung Electronics
Alignment and Adjustments
01.Picture Improve => 05.Y/C Delay Setting according to the System and Input Modes
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
05.Y/C Delay TV Mode-1 Mode-2 Mode-3 Mode-4
01. PAL-B/G 254 254 x x x
02. PAL-D/K/L 254 254 x x x
03. PAL-I 254 254 x x x
04. SECAM-B/G 254 254 x x x
05. SECAM-D/K/L 251 251 x x x
06. NTSC 254 VSP9437 254 x x x
07. PAL-AV 254 254 x x x
08. SECAM-AV 252 252 x x x
09. NTSC-AV 254 254 x x x
10. RGB/YUV-Y 90 90 x x x
11. RGB/YUV-UV 90 90 x x x
12. FLI-Y 5 5 x x x
FLI2310
13. FLI-C 11 11 x x x
01~11 : VSP9437
12~13 : FLI2310
01.Picture Improve => 06.Motion Enhancing Adjustment
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
06.Motion TV Mode-1 Mode-2 Mode-3 Mode-4
01.HPLL Speed-1 0 VSP9437-M 0 x x x
02.HPLL Speed-2 0 VSP9437-S 0 x x x
03.V-motion Tresh 42 FLi2310 42 x x x
01 : VSP9437-M
02 : VSP9437-S
03 : FLI2310
Samsung Electronics 2-9
Alignment and Adjustments
01.Picture Improve => 07.DNIe Registers
Initial Values of Input Modes
TV
AV1,1,3
ITEM Relevant IC
V1,2,3 Comp1,2-p PC DVI
S-V1,2
Comp1,2-i
07.DNIe Range Mode-1 Mode-2 Mode-3 Mode-4
01.SUB BRIGHT 0~94 W/B W/B W/B W/B
02.SUB CONT 0~94 W/B W/B W/B W/B
03.SCALE MAX 0~255 48 36 36 36
04.SCALE MIN 0~255 16 16 16 16
05.DCE CUTOFF 0~255 16 16 16 16
06.DCE UPPER 0~255 230 230 230 230
07.R GAIN 1X 0~63 12 16 10 10
08.CE UPPER 0~255 220 220 220 220
09.CE CUTOFF 0~255 32 32 32 32
10.R GAIN 1Y 0~63 11 11 8 8
DNIe
11.R D ALPHAL 0~255 48 48 48 48
12.R GAIN 2X 0~63 5 5 6 6
13.R GAIN 2Y 0~63 5 5 4 4
14.R ND ON 0~1 1 1 1 1
15.R CORING ON 0~1 1 1 1 1
16.PATT SEL 0~19 0 0 0 0
17.R CORING TH1 0~7 1 1 1 1
18.R CORING TH2 0~7 1 1 1 1
19.R CORING TH3 0~7 1 1 1 1
20.BLACK GAIN 0~2048 400 188 188 188
21.WHITE GAIN 0~2048 156 156 156 156
22.WTE GAIN 0~1024 300 300 300 300
23.CTE GAIN 0~255 176 176 176 176
01~23 : DNIe
2-10 Samsung Electronics
Alignment and Adjustments
01.Picture Improve => 08.DNIe Additional Registers
Initial Values of Input Modes
TV
ITEM Relevant IC AV1,1,3
V1,2,3 Comp1,2-p PC DVI
S-V1,2
Comp1,2-i
08. DNIe Additional Range Mode-1 Mode-2 Mode-3 Mode-4
01. R D ALPHAU 0~255 75 75 75 75
02. R BLACK GAIN MAX 0~1023 300 300 300 300
03. R BLACK TILT 0~255 DNIe 90 90 90 90
04. R WHITE GAIN MAX 0~1023 300 300 300 300
05. DNIe GAMMA 0~7 0 0 0 0
06. R GAIN 3 X 0~63 0 0 0 0
Samsung Electronics 2-11
Alignment and Adjustments
01.Picture Improve => 09.Logic Registers
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
08.Logic TV Mode-1 Mode-2 Mode-3 Mode-4
01.R DRIVE W/B W/B W/B W/B W/B
02.G DRIVE 128 128 128 128 128
03.B DRIVE W/B W/B W/B W/B W/B
04.R CUTOFF W/B W/B W/B W/B W/B
05.G CUTOFF 128 128 128 128 128
06.B CUTOFF W/B W/B W/B W/B W/B
07.GAMMA 1 1 1 1 1
08.GTS SET 1 0 0 0 0
09.ERD MODE 2 Logic 2 2 2 2
10.RANDOM NOISE 0 0 0 0 0
11.DIFF FILTER 1 1 1 1 1
12.APC 1 1 1 1 1
13.APC SET 0 0 0 0 0
14.APC VALUE 127 127 127 127 127
15.ACTIVE VPOS 12 12 12 12 12
16.ACTIVE HPOS 19 19 19 19 19
17.VSYNC POS 3 3 3 3 3
18.HSYNC POS 32 32 32 32 32
19.VSYNC WIDTH 2 2 2 2 2
20.HSYNC WIDTH 12 12 12 12 12
01~20 : Logic
2-12 Samsung Electronics
Alignment and Adjustments
01.Picture Improve => 09.Picture Size Registers
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
09.Picture Size TV Mode-1 Mode-2 Mode-3 Mode-4
01. H START OFFSET 0 0 0 0 0
02. V START OFFSET 0 0 0 0 0
03. H END OFFSET 0 0 0 0 0
04. V END OFFSET 0 ASI510 0 0 0 0
05.OVERSCAN B 63 63 63 63 63
06.OVERSCAN G 63 63 63 63 63
07.OVERSCAN R 63 63 63 63 63
01~07 : ASI510
02.Setting the Initial Values
02.Initial Setting Current Input Mode Indicates selected input mode
Reset after saving the P-Mode adjustments
01. Initial P-Mode
P-MODE the data Values
02. P-Mode Value
Reset after saving the color tone adjustments
03. Initial Color Tone
Color tone the data Values
04. Color Tone Value
02.Initial Setting => 01.Initial P-Mode
01.Initial P-Mode Current Input Mode
01. Dynamic Available options for the PC/DVI Mode are High,Middle,
02. Standard Low and Custom.
03. Movie
04. Custom
02.Initial Setting => 02.P-Mode Value
02. P-Mode Value Current Input Mode
01. Dynamic Available options for the PC/DVI Mode are High,Middle,
02. Standard Low and Custom.
03. Movie
04. Custom
Samsung Electronics 2-13
Alignment and Adjustments
02.Initial Setting => 02.P-Mode Value => 01.Dynamic
01.Dynamic Current Input Mode
01. Contrast 100
02. Brightness 45
03. Sharpness 75
04. Color 55
05. Tint 50
02.Initial Setting => 02.P-Mode Value => 02.Standard
02.Standard Current Input Mode
01. Contrast 80
02. Brightness 50
03. Sharpness 50
04. Color 50
05. Tint 50
02.Initial Setting => 02.P-Mode Value => 03.Movie
03.Movie Current Input Mode
01. Contrast 50
02. Brightness 55
03. Sharpness 25
04. Color 40
05. Tint 50
02.Initial Setting => 02.P-Mode Value => 04.Custom
04.Custom Current Input Mode
01. Contrast 80
02. Brightness 50
03. Sharpness 50
04. Color 50
05. Tint 50
02.Initial Setting => 03.Initial Color Tone
02.Initial Setting Current Input Mode Available Settings for the PC Mode are
01. Cool2 Custom,Color Tone 1, Color Tone 2, Color Tone 3
02. Cool1
03. Normal Available options for the DVI Mode are
04. Warm1 ColorTone1, ColorTone2, ColorTone3
05. Warm2
2-14 Samsung Electronics
Alignment and Adjustments
Samsung Electronics 2-15
Alignment and Adjustments
2-16 Samsung Electronics
Alignment and Adjustments
03.PIP/TTX/Test Pattern
Initial Values of Input Modes
ITEM Relevant IC Video Component PC DVI
03.PIP/Test Pattern TV Mode-1 Mode-2 Mode-3 Mode-4
01.PIP R CONT 32 32 32 32 32
02.PIP G CONT 32 32 32 32 32
03.PIP B CONT 32 32 32 32 32
04.PIP R BRIGHT 0 0 0 0 0
05.PIP G BRIGHT 0 0 0 0 0
ASI510
06.PIP B BRIGHT 0 0 0 0 0
07.PIP FILTER LC 0 0 0 0 0
08.PIP FILTER ML 0 0 0 0 0
09.PIP FILTER MR 0 0 0 0 0
10.PIP FILTER UC 0 0 0 0 0
11. TTX CONT 0 0 0 0 0
SDA6001
12. TTX BRIGHTNESS 0 0 0 0 0
13.LOG PATTERN 0 0 0 0 0
14.LOG HIGH LEVEL 255 Logic 255 255 255 255
15.LOG LOW LEVEL 0 ASI510 0 0 0 0
16.ASI COLORBAR 1 1 1 1 1
01~10 : ASI510
11~12 : SDA6001
13~16 : Logic, ASI510
Samsung Electronics 2-17
Alignment and Adjustments
04.Option-1
04.Option-1 Current Input Mode
00. AGC Off
01. TTX ON 00. Off => On
02. CW/CS CS 01. Scart(Full input) => RCA(Scart delete)
03. TELE-WEB OFF 02. CW(EUROPE) => CS(SOUTHASIA)
04. LANGUAGE GROUP ASIA 03. Off => On
05. LANGUAGE ENGLISH 04. Europe => Asia
06. ATM ON 05. English => 18 Language(Europe)
07. Melody Volume 10 06. On => Off
08. TUNER 2-TUNER 07. On => Off
09. LNA ON 08. 2-Tuner => 1-Tuner => Off
10. CHILD LOCK ON 09. On => Off
11. TOP TTX ON 10. On => Off
12. TTX GROUP Language 11. On => Off
13. HIGH DEVIATION OFF 12. W.Europe => 6 Group
14. SD Delay 3 13. Off => On
15. HD Delay 2 14. O(default),1(27ms),2(54ms),3(108ms)
16. Video Port Graphic 15. O(default),1(27ms),2(54ms),3(108ms)
16. Graphic <-> Video
01. TTX : ON <-> OFF
- ON : The other area with the exception of china
- OFF : China area
02. CW/CS : CW => CS
- CW : PAL, SECAM-B/G, D/K, I, L/L', NTSC4.43 = West Europe
- CS : PAL, SECAM-B/G, D/K, I, NTSC3.58/4.43 = Countries except West Europe.
Ex) Southeast Asia,the Middle East,Russia,China, etc.
03. Tele-Web
- Off : TeleWeb non-broadcasting Country
- On : TeleWeb broadcasting Country
04. Language Group : Europe => Asia
-. Europe : 18 languages
-. Asia : 7 languages
05. Language : Select language
- Language Group is Europe : 18 languages
(English=>Bulgarian=>Croatian=>Czechoslovak=>Netherlandish=>French=>German=>Greek=>Hungarian=>
Italian=>Poland=>Portuguese=>Rumanian=>Russian=>Spanish=>Swedish=>Turki=>Yugoslave)
- Language Group is Asia : 7 languages
(English=>Arabic=>French=>Indonesian=>Malay=>Persian=>Chinese)
06. ATM : On => Off
-. ATM available region : On
-. ATM non-available region : Off
07. Melody Volume
-. 0 ~ 20 (In case of power ON/OFF, Melody volume setting up)
2-18 Samsung Electronics
Alignment and Adjustments
08. Tuner
-. 2-Tuner / 1-Tuner / Off
09. LNA
- On : Using LNA built-in Tuner
- Off : Not in use LNA built-in Tuner
10. Child Lock
-. On : TV Model
-. Off : Model has deletion of Child Lock function
11. Top TTX
- On : Only Top broadcasting region set 'On'
Ex) Germany, Switzerland, etc
- Off : Country except Top broadcasting region.
12. TTX Group : TTX Language Group and National Option Code
- By language, Select at the factory option table.
- TTX language will be displayed by National Option code.
- TTX Language Group by each country : 6 Groups
West Europe => East Europe => Turkish/Greek => Cyrillic => Arabic/Hebrew => Farsi/Hebrew
13. High Deviation : To prevent the Sound Buzz according to the regional characteristics of the input signal.
- Set to `Off' for the standardized sound input signal, in the region such as Europe.
- Set to `On' for the over-modulated sound input signal, in the region such as Southeast Asia.
14. SD Delay : AV mode Delay
1.8ms delay --------- delay0
27ms delay --------- delay1
54ms delay --------- delay2
108ms delay (max) --------- delay3
15. HD Delay : DTV/PC/DVI mode Delay
16. Video Port : Setting of Aurora Input Port for VIDEO signal
-. Graphic : Input Video Signal though Graphic port of Aurora (In case of NON-PIP VIDEO)
-. Video : Input Video Signal though Graphic port of Aurora (In case of PIP VIDEO)
05.Option-2
05.Option-2 Current Input Mode 00. On => Off
00. Pixel Shift V 01. 0: minute , 1: SEC
01. Shift Test 0 02. Left,right movement Pixel
02. Pixel Number 1 03. Upper, low movement Pixel
03. Shift Line 1 04. Shift Test
04. Shift Time 4
05. Left, Right movement pixel range
05. Number Range 4
06. Upper, Low movement line range
06. Line Range 4
07. Temp Protection On 07. Protection of SMPS temperature
08. DNIe DEMO On 08. DNIe DEMO OSD : ON, OFF
09. PILOT HIGH 21 09. Setting value of Stereo Identify Level
10. PILOT LOW 16 10. Setting value of Mono Identify Level
11. CHECKSUM 0000 11. EEPORM Code Check
Samsung Electronics 2-19
Alignment and Adjustments
MEMO
2-20 Samsung Electronics
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
