Image preview - the first page of the document



>> Download user guide documenatation <<

Text preview - extract from the document

                                        PDP-TELEVISION
                                        (PLASMA DISPLAY PANEL)



                          Owner's Instructions
                                 Before operating the unit,
                            please read this manual thoroughly,
                              and retain it for future reference.




                           ON-SCREEN MENUS
                          Picture In Picture (PIP)
                               Energy Saving
                             TELETEXT (Option)
                              SRS TruSurround XT
                          Digital Natural Image engine
                 Register your product at www.samsung.com/global/register
                 Record your Model and Serial number here for future reference.
BN68-01171Q-03    Model _______________  Serial No. _______________
    User Instructions
     Screen Image retention
     Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the
     plasma monitor panel for more than 2 hours as it can cause screen image retention. This image
     retention is also known as "screen burn". To avoid such image retention, reduce the degree of
     brightness and contrast of the screen when displaying a still image.
     Height
     The PDP can normally operate only under 2000m in height. It might abnormally function at a place
     over 2000m in height so do not install and operate there.
     Heat on the top of the PDP TV
     The top side of the product may be hot after long period of use as heat dissipates from the panel
     through the vent hole in the upper part of the product. This is normal and does not indicate any defect
     or operation failure of the product. However, children should be prevented from touching the upper
     part of the product.
     The product is making a `cracking' noise.
     A `cracking' noise may occur when the product contracts or expands due to a change of surrounding
     environment such as temperature or humidity. This is normal and not a defect of the unit.
     Cell Defects
     The PDP uses a panel consisting of 1,230,000(SD-level) to 3,150,000(HD-level) pixels which require
     sophisticated technology to produce. However, there may be few bright or dark pixels on the screen.
     These pixels will have no impact on the performance of the product.
     Avoid operating the TV at temperatures below 5
