Image preview - the first page of the document
>> Download 20051117095655078_D72A-evapl-4 documenatation <<
Text preview - extract from the document
Exploded View & Part List
4. Exploded View & Part List
4-1 PS42S5HX/XEE
You can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr
Loc.No. Code No. Description Specification Q'ty SA/SNA Remark
CIS7 AA61-60003B SPRING ETC-CS -,SUS304,-,-,OD11.2,N7,OD1 1 S.N.A
M0006 BN63-01634C COVER-REAR SUB 42S5,SECC,T1.0 1 S.N.A
M0006 BN63-01633C COVER-REAR 42D5,SECC,T0.5 1 S.N.A
M0013 BN96-02140C ASSY STAND P-BASE 42S5H,XEC,HIPS HB,SV01 1 S.A
M0013 BN96-01786C ASSY COVER P-REAR SP-R4232,SECC,BLM 5113 1 S.A
M0111 BN63-01813G COVER-STAND 42S5H,XEC,HIPS,T3.5,HB,SV012 1 S.N.A
M0112 BN63-01631B COVER-FRONT 42S5,HIPS,HB,XEC,SV012P 1 S.N.A
M0145 BN96-02049C ASSY BOARD P-FUNCTION SP-R4232,CT5000-36 1 S.N.A
M0146 BN96-02050B ASSY BOARD P-POWER & IR SCHUBERT,CT5000- 1 S.N.A
T0003 BN96-01773B ASSY COVER P-FRONT 42P5,42S5,EXPORT 1 S.A
T0023 BN96-01788A ASSY COVER P-KNOB POWER SPD-42P5HD 1 S.N.A
T0044 BN96-01886A ASSY PDP MODULE P M1,SPD-42P5HD,D71A,V4, 1 S.A
T0073 AA63-01078A GASKET-EMI 42P5,T1.5,7,1006 2 S.N.A
T0073 AA63-01079A GASKET-EMI 42P5,T1.5,W7,L614.5 2 S.N.A
T0074 BN59-00468A REMOCON PS42S5S,TM76A,59*22*209,ZILOG MB 1 S.A
T0079 BN94-00683B ASSY PCB MISC-MAIN PS42S5HX/XEC,D72A,EU, 1 S.A
T0175 AA96-02814A ASSY SPEAKER P 8ohm,S5,42,15W 1 S.A
T0268 3903-000145 CBF-POWER CORD DT,EU,FP3/YES,U(IEC C13-R 1 S.A
T0275 BN96-02369A ASSY MISC P-INLET HP-R4252,STRAUSS,DOCUM 1 S.A
T0456 BN67-00144A GLASS-FILTER EMI 42P5,Mesh,48%,1053*639, 1 S.A
T0555 BN96-01392D ASSY MISC P-BRKT TERMINAL 42S5,XEC,SECC 1 S.N.A
T0603 BN64-00338A WINDOW-RMC 42P5,ACRYL,5% 1 S.N.A
Samsung Electronics 4-1
Exploded View & Part List
4-2 PS42S5HX/XEU
You can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr
Loc.No. Code No. Description Specification Q'ty SA/SNA Remark
CIS7 AA61-60003B SPRING ETC-CS -,SUS304,-,-,OD11.2,N7,OD1 1 S.N.A
M0006 BN63-01634C COVER-REAR SUB 42S5,SECC,T1.0 1 S.N.A
M0006 BN63-01633C COVER-REAR 42D5,SECC,T0.5 1 S.N.A
M0013 BN96-02140C ASSY STAND P-BASE 42S5H,XEC,HIPS HB,SV01 1 S.A
M0013 BN96-01786C ASSY COVER P-REAR SP-R4232,SECC,BLM 5113 1 S.A
M0111 BN63-01813G COVER-STAND 42S5H,XEC,HIPS,T3.5,HB,SV012 1 S.N.A
M0112 BN63-01631B COVER-FRONT 42S5,HIPS,HB,XEC,SV012P 1 S.N.A
M0145 BN96-02049C ASSY BOARD P-FUNCTION SP-R4232,CT5000-36 1 S.N.A
M0146 BN96-02050B ASSY BOARD P-POWER & IR SCHUBERT,CT5000- 1 S.N.A
T0003 BN96-01773B ASSY COVER P-FRONT 42P5,42S5,EXPORT 1 S.A
T0023 BN96-01788A ASSY COVER P-KNOB POWER SPD-42P5HD 1 S.N.A
T0044 BN96-01886A ASSY PDP MODULE P M1,SPD-42P5HD,D71A,V4, 1 S.A
T0073 AA63-01078A GASKET-EMI 42P5,T1.5,7,1006 2 S.N.A
T0073 AA63-01079A GASKET-EMI 42P5,T1.5,W7,L614.5 2 S.N.A
T0074 BN59-00468A REMOCON PS42S5S,TM76A,59*22*209,ZILOG MB 1 S.A
T0079 BN94-00683B ASSY PCB MISC-MAIN PS42S5HX/XEC,D72A,EU, 1 S.A
T0175 AA96-02814A ASSY SPEAKER P 8ohm,S5,42,15W 1 S.A
T0268 3903-000193 CBF-POWER CORD DT,GB,GP3/YES,U(IEC C13-R 1 S.N.A
T0275 BN96-02369A ASSY MISC P-INLET HP-R4252,STRAUSS,DOCUM 1 S.A
T0456 BN67-00144A GLASS-FILTER EMI 42P5,Mesh,48%,1053*639, 1 S.A
T0555 BN96-01392D ASSY MISC P-BRKT TERMINAL 42S5,XEC,SECC 1 S.N.A
T0603 BN64-00338A WINDOW-RMC 42P5,ACRYL,5% 1 S.N.A
4-2 Samsung Electronics
Exploded View & Part List
4-3 PS42S5HX/XEH
You can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr
Loc.No. Code No. Description Specification Q'ty SA/SNA Remark
CIS7 AA61-60003B SPRING ETC-CS -,SUS304,-,-,OD11.2,N7,OD1 1 S.N.A
M0006 BN63-01634C COVER-REAR SUB 42S5,SECC,T1.0 1 S.N.A
M0006 BN63-01633C COVER-REAR 42D5,SECC,T0.5 1 S.N.A
M0013 BN96-02140C ASSY STAND P-BASE 42S5H,XEC,HIPS HB,SV01 1 S.A
M0013 BN96-01786C ASSY COVER P-REAR SP-R4232,SECC,BLM 5113 1 S.A
M0111 BN63-01813G COVER-STAND 42S5H,XEC,HIPS,T3.5,HB,SV012 1 S.N.A
M0112 BN63-01631B COVER-FRONT 42S5,HIPS,HB,XEC,SV012P 1 S.N.A
M0145 BN96-02049C ASSY BOARD P-FUNCTION SP-R4232,CT5000-36 1 S.N.A
M0146 BN96-02050B ASSY BOARD P-POWER & IR SCHUBERT,CT5000- 1 S.N.A
T0003 BN96-01773B ASSY COVER P-FRONT 42P5,42S5,EXPORT 1 S.A
T0023 BN96-01788A ASSY COVER P-KNOB POWER SPD-42P5HD 1 S.N.A
T0044 BN96-01886A ASSY PDP MODULE P M1,SPD-42P5HD,D71A,V4, 1 S.A
T0073 AA63-01078A GASKET-EMI 42P5,T1.5,7,1006 2 S.N.A
T0073 AA63-01079A GASKET-EMI 42P5,T1.5,W7,L614.5 2 S.N.A
T0074 BN59-00468A REMOCON PS42S5S,TM76A,59*22*209,ZILOG MB 1 S.A
T0079 BN94-00683B ASSY PCB MISC-MAIN PS42S5HX/XEC,D72A,EU, 1 S.A
T0175 AA96-02814A ASSY SPEAKER P 8ohm,S5,42,15W 1 S.A
T0268 3903-000145 CBF-POWER CORD DT,EU,FP3/YES,U(IEC C13-R 1 S.A
T0275 BN96-02369A ASSY MISC P-INLET HP-R4252,STRAUSS,DOCUM 1 S.A
T0456 BN67-00144A GLASS-FILTER EMI 42P5,Mesh,48%,1053*639, 1 S.A
T0555 BN96-01392D ASSY MISC P-BRKT TERMINAL 42S5,XEC,SECC 1 S.N.A
T0603 BN64-00338A WINDOW-RMC 42P5,ACRYL,5% 1 S.N.A
Samsung Electronics 4-3
