Image preview - the first page of the document
>> Download 02_product_specifications(map) documenatation <<
Text preview - extract from the document
2. Product Specification
2. Product Specification
2.1. Model Comparison
Series PE8500
Front View
Front Color Black
Without Stand 46.87 x 27.88 x 2.18
51"
With Stand 46.87 x 29.27 x 10.63
Dimensions
Without Stand 54.8 x 32.6 x 2.18
WxDxH 60"
With Stand 54.8 x 34.22 x 11.81
(inch)
Without Stand 58.37 x 34.56 x 2.18
64"
With Stand 58.37 x 36.14 x 12.6
Without Stand 20.9 kg
51"
With Stand 23.4 kg
Weight Without Stand 29.2 kg
60"
(lbs) With Stand 32.4 kg
Without Stand 32.8 kg
64"
With Stand 36.3 kg
Premium Display Panel
Smart HUB (Golden Bridge(UI))
Anynet+ (HDMI-CEC)
Feature
SMART Interaction
Miracast
All share (Screen Mirroring / Contents Sharing)
