Image preview - the first page of the document



>> Download pck6115r documenatation <<

Text preview - extract from the document

                     SAMSUNG PROJECTION TV SERVICE GUIDE




                                         *Supercedes and appends service manual data*
                                               Covers Models: (P51 Chassis)

              PCJ612R/PCJ 522R (covers PCK520)
              PCJ533R
              PCJ533RF
              PCJ534RF (covers PCJ532RF, PCK5315R)
              PCJ614RF (covers PCJ611RF, PCK6115R)
              HCJ552W/HCJ652W


          Last update: 3/14/01


Downloaded from www.Manualslib.com manuals search engine
                     SAMSUNG PROJECTION TV SERVICE GUIDE


                                                            Table of Contents

                                                                 Sections

                                                       1. How to Use This Guide
                                                       2. Service Bulletins

                                                       3. Flow Charts/Micro Kits
                                                       4. Macro Kit Instructions

                                                       5. Parts Data
                                                       6. Assembly/Disassembly

                                                       7. Escalation/Who to Call




          Last update: 3/14/01


Downloaded from www.Manualslib.com manuals search engine
                       SAMSUNG PROJECTION TV SERVICE GUIDE
                                                   Section 1 - How to Use This Guide


                  How to use this Guide
                       This guide is divided into seven sections. Start with the section marked
                       "Instructions".

                            The models covered in this document are derived from the P51A chassis. However; this
                            chassis has several different versions that are NOT covered in the service manuals.

                            Instructions to Start Service:
                            1. Obtain model, serial and symptom.

                            2. Review service bulletins (section 2), for common fixes. If Service Bulletin states that
                               repair is common, complete repair as indicated. Otherwise, proceed to section 3.

                            3. Review symptom/repair list as per the micro kit section (3). Order part number for
                               "kit" or individual parts.
                            Important Note: Order MACRO Kit only when technically required or the individual boards are
                            not available as an additional 45 minutes to 1 hour is needed for convergence, alignments and
                            other configuration setup.

                            4. If the previous steps do lead to a clear diagnosis, then proceed to the flow chart in
                               section 3 to help assist you in determining the correct PCB's to order.

                            5. Place order through Samsung Parts Department.

                            Note: Distributors DO NOT carry PCB's or macro kits, so backorder with
                            no eta will result. Parts Department will not accept an order for PTV parts without a
                            serial number because correct ID cannot be assured.

                            6. Parts will automatically ship 2nd day or faster. It is essential that the macro kit be
                               returned A.S.A.P. Your account will be charged, depending on the kit, up to
                               $1500.00 if the kit is not returned within 30 days.

                            7. When installing parts (refer to section 6 - Assembly/Disassembly), repair alignment
                                or adjustment will be necessary. There are three adjustment modes:
                                Convergence
