Image preview - the first page of the document
>> Download exploded_view_and_part_list_819 documenatation <<
Text preview - extract from the document
Exploded View & Parts List
3. Exploded View & Parts List
3-1 SP43R1HL1X/XEC
You can search for the updated part code through ITSELF web site. M0045
URL : http://itself.sec.samsung.co.kr
Loc.No Code No Description;Specification Q'ty S.N.A
M0014 BP94-00756A ASSY PCB MAIN;EU,OMEGA2 1
T0074
T0068 T0108 M0045 AA64-02734A CABINET-BACK,TOP;43T7,HIPS,HB,GR503 1
T0054 T0929 T0002 BP96-00897C ASSY COVER P-FRONT BOTTOM;43R1,EUP,HIPS, 1
T0053 T0254 T0003 BP96-00895C ASSY COVER P-FRONT;43R1,EUP,HIPS,HB,GR50 1
T0015 AA64-02735B CABINET-BACK,BOT;43T7,HIPS,HB,GR503 1
T0023 BP64-00312A KNOB POWER-ASSY;43T9,ABS,HB,GRY 1 S.N.A
T0003
T0056 T0053 AA67-00115E SCREEN FRESNEL;SCREEN FRESNEL,910*692,T= 1
T0091
T0054 BP67-00104C SCREEN LENTI;43,PMMA,908*690,0.76 1
T0056 T0056 BP61-00110A BRACKET-SCREEN,RL;43T7,SECC,T1.0,SCREEN 1 S.N.A
T0384 T0268
T0056 BP61-00110A BRACKET-SCREEN,RL;43T7,SECC,T1.0,SCREEN 1 S.N.A
T0023 T0068 BP61-00008A BRACKET-MIRROR,ASSY;42W5,SECC,T1.0,AA61- 2 S.N.A
T0070 AA61-01127A HOLDER-CHASSIS;COMMANDO,HIPS V0,G4309 1 S.N.A
T0254
T0074 BP59-00062A REMOCON;OMEGA,TM76A,Projection,47,L/GRAY 1
T0091 BP94-01405A ASSY PCB MISC-A/V SIDE;SP43R1HL1X,J60B 1 S.N.A
T0015
T0097 BP94-01431A ASSY PCB MISC-PWR DEF;J60B,EU 1
T0103 BP59-00045A MODULE-FOCUS PACK ASS'Y;SVP-43W6HE,F301- 1
T0600 T0105 BP94-00567A ASSY PCB MISC-DY JACK;SVP-43W6,CHAMP 1
T0601 T0130 T0108 AA67-00205B MIRROR-BACK;43T7,SSM,795*569*554*(78) 1
M0014
T0118 T0097
T0115 AA61-00475B BRACKET-CRT,MAIN;54",SECC,T1.6,-,-,-,- 1
T0105
T0118 BP26-00004A TRANS FBT-H/V DISTRIBUTOR;FUW50A002B/FFA 1
T0130 BP96-00513H ASSY COVER P-TERMINAL ANT;43Q5,HIPS,V0,B 1 S.N.A
T0103 T0245 BP94-01404A ASSY PCB MISC-KEY CONTROL;SP43R1HL,J60B 1 S.N.A
T0254 BP61-00109A BRACKET-SCREEN,TB;43T7,SECC,T1.0,SCREEN 1 S.N.A
T0254 BP61-00109A BRACKET-SCREEN,TB;43T7,SECC,T1.0,SCREEN 1 S.N.A
T0268 AA39-10006X CBF-POWER CORD;-,KKP419C,KLCE-2F,2.286MT 1
T0115 T0324 BP96-00949A ASSY COVER P-WOOD;43R1,WOOD,SDE8336R(SIL 1 S.N.A
T0070 T0384 BP94-01444A ASSY PCB MISC-PWR CONTROL;SP43R1HL,J60B 1 S.N.A
T0324
T0002 T0600 AA60-00072C SPACER-COVER,DUST;43T7,SPONGE 94HF-1,T3. 1
T0601 BP91-00995A ASSY PRT;43T8,P59A 1 S.N.A
T0929 BP61-00300A HOLDER-MIRROR R ASSY;43T8,HIPS,HB,BLK 1 S.N.A
T0245
Samsung Electronics 3-1
