Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
5-1. Exploded View
M0081
T0514
T0453 T0603
M0081
M0081 T0081
M0006
5. Exploded View & Part List
T0071
T0501
T0056
T0081
T0049
T0603
SHIELD-TOP M0081
M0081
T0531
T0915
M0081
SHIELD-BOT
T0530
5. Exploded View & Part List
5-1
5. Exploded View & Part List
5-1-2. Parts List
NO I TEM CODE NO Q'TY MATERIAL REMARK
1 ASSY COVER-TOP - 1 -
1-1 COVER-TOP BP63-009794 1 SPA400, PC, VO, BLK
1-2 COVER-DECORATION BP63-00982A 1 SPA400, AL, BLK
1-3 WINDOW-RMC BP64-00652A 1 SPA400, PC, VIOLET
1-4 BRACKET-SUPPORT BP61-01572A 2 SPA400, SECC, T1, 0
1-5 SCREW-TAPTITE 6003-000282 4 BH, M3, L8, BLK BRACKET-SUPPORT+COVER-TOP
2 ASSY COVER-REAR - 1 -
2-1 COVER-REAR BP63-00972A 1 SPA400, PC, VO, BLK
2-2 INLAY-TERMINAL BP-64-00658A 1 SPA400, PS SHEET, TO.5, BLK
2-3 WINDOW-REAR BP64-00653A 1 SPA400, PC, VIOLET
3 ASSY PCB-MAIN SHIELD - 1 -
3-1 SHIELD-PCB MAIN BOT BP63-01047A 1 SPA400, SECC, TO, 8
3-2 MAIN-PCB - 1 -
3-3 SHIELD-PCB MAIN TOP BP63-01048A 1 SPA400, SECC, TO.5
3-4 SCREW-TAPTITE 6003-000282 5 BH, M3, L8, BLK MAIN-PCB+SHIELD-PCB MAIN BOT
SHIELD-PCB MAINTOP
3-5 SCREW-TAPTITE 6003-000282 2 BH, M3, L8, BLK
+SHIELD-PCB MAIN BOT
4 ASSY PCB-SMPS SHIELD - 1 -
4-1 SHIELD PCB SMPS BOT BP63-01054A 1 SPA400, SECC, T1.0
4-2 SMPS-PCB - 1 -
4-3 BRACKET-PLATE BP61-01592A 1 SPA400, SECC, T1.0
4-4 LIGHT-EFFECT - 1 -
4-5 SCREW-TAPTITE 6003-000282 2 BH, M3, L8, BLK SMPS+SHIELD-PCB SMPS BOT
BRACKET-PLATE+
4-6 SCREW-TAPTITE 6003-000282 2 BH, M3, L8, BLK
SHIELD-PCB SMPS BOT
4-7 SCREW-TAPTITE 6003-000282 2 BH, M3, L8, BLK LIGHT-EFFECT+BRACKET-PLATE
5 TOUCH-KEY PAD - 1 -
6 HOLDER-BALLAST BP61-01587A 1 SPA400, PC+ABS VO, BLK
7 FAN 60 - 1 -
8 LAMP-BALLAST BP47-00039A 1 -
9 SCREW-TAPTITE 6003-001003 1 BH, M4, L12, BLK HOLDER-BALLAST+COVER-BOT
10 SCREW-TAPTITE 6003-000282 1 BH, M3, L8, BLK HOLDER-BALLAST+COVER-BOT
11 SCREW-TAPTITE 6003-001355 2 BH, M4, L20, BLK FAN+ HOLDER-BALLAST
12 SCREW-TAPTITE 6003-000282 3 BH, M3, L8, BLK BALLAST+COVER-BOT
13 COVER-DUCT TOP BP63-00932A 1 PC
5-2
5. Exploded View & Part List
14 SCREW-MACHINE 6001-000677 2 RH, +, M3, L6 COVER-DUCT TOP+ENGINE
15 ASSY COVER-DUCT - 1 -
16 SCREW-TAPTITE 6003-001003 3 BH, M4, L12, BLK ASSY COVER-DUCT+COVER-BOT
17 HOLDER-LED BP61-01573A 1 SPA400, PC+ABS VO,BLK
18 LED-PCB - 1 -
HOLDER-LED+COVER-DUCT
19 SCREW-TAPTITE 6003-000282 1 BH, M3, L8, BLK
OUT TOP
20 ASSY ENGINE - 1 -
21 SCREW-TAPTITE 6003-001003 7 BH, M4, L12, BLK ASSY ENGINE+COVER-BOT
22 HOLDER-CAP LENS BP61-01571A 1 -
23 CAP ZOOM LENS BP67-00318A 1 A400, PC+ABS, T3.5, BLACK
24 COVER-BOTTOM BP63-00980A 1 SPA400, PC+ABS, VO, BLK
25 NUT - 2 -
26 HOLDER-MODULE BP61-01480A 1 SPA400, PC+ABS, VO, BLK
27 WINDOW-PCB - 1 -
28 SCREW-TAPTITE 6003-000282 1 BH, M3, L8, BLK HOLDER-MODULE+COVER-TOP
29 DETECTOR-S/W - 1 -
30 SCREW-TAPTITE 6003-000233 1 PH, M2, L6, BLK
31 ASSY-HOLDER P FOOT BP96-01741A 2 SPA400, ABS FOOT SHAFT, BLK
32 COVER-LAMP BP63-00981A 1 SPA400, PC+ABS VO, BLK
33 SCREW-MACHINE 6001-000581 1 PH, M4, L12, N1 COVER-LAMP+COVER-BOT
34 RUBBER-FOOT 6104-001010 2 BLACK, POLYURETHANE, -
BRACKET-GUIDE
35 SCREW-TAPTITE 6003-000282 2 BH, M3, L8, BLK
POWER+COVER-REAR
36 BRACKET-GUIDE POWER BP61-01584A 1 SPA800, SECC, T1.0
37 INLAT-POWER - 1 -
COVER-REAR+BRACKET-
38 SCREW-TAPTITE 6003-001003 2 BH, M4, L12, BLK
SUPPORT
39 SCREW-TAPTITE 6003-000282 2 BH, M3, L8, BLK COVER-REAR+COVER-BOT
40 SCREW-TAPTITE 6003-000282 1 BH, M3, L8, BLK COVER-REAR+MAIN-PCB
41 SCREW-TAPTITE 6003-000282 3 BH, M3, L8, BLK SHIELD-PCB SMPS BOT+COVER-BOT
INLAT WIRE+SHIELD-PCB SMPS
42 SCREW-MACHINE 6006-00245 1 PH, WSP, M4, L8, WHT
BOT
5-3
5. Exploded View & Part List
5-2. Parts List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
SPA400BX/XAA SP-A400B,H4VA,,PROJECTOR,UNITED STATES
0.1 BP90-00424A ASSY COVER TOP;SPA400BX/XAA 1 S.N.A
..2 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
..2 T0265 BP96-01988A ASSY COVER P-TOP;SPA400,,PC,V0,,BLK, 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 4 S.A
...3 M0114 AA61-20129A HOLDER-WIRE;-,NYLON-66,-,-,-,NTR,DAFC-25 1 S.N.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.5 S.N.A
...3 T0514 BP61-01572A BRACKET-SUPPORT;SPA400,SECC,T1.0 2 S.N.A
...3 T0501 BP63-00979A COVER-TOP;SPA400,PC,V0,BLK 1 S.N.A
...3 T0056 BP63-00982A COVER-DECORATION;SPA400,AL,BLK 1 S.N.A
...3 T0603 BP64-00652A WINDOW-RMC;SPA400,PC,VIOLET 1 S.N.A
...3 T0069 BP60-00102A SPACER-FELT;SP-A400,FELT,BLK,0.5mm 1 S.N.A
0.1 BP90-00425A ASSY COVER BOTTOM;SPA400BX/XAA 1 S.N.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 1 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
..2 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 3 S.A
..2 T0081 6006-000245 SCREW-MACHINE;PH,+,WSP,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 BP61-01584A BRACKET-GUIDE POWER;SPA800,SECC,T1.0 1 S.N.A
..2 M0013 BP96-01989A ASSY COVER P-REAR;SPA400,,PC+ABS,V0(NT), 1 S.A
...3 CCM1 BN63-02183D COVER-SHEET;Rhcm,PE Vinyl,T0.05,680mm,20 0.15 S.N.A
...3 M0006 BP63-00972A COVER-REAR; 1 S.N.A
...3 BP64-00653A WINDOW-REAR;SPA400,PC,VIOLET 1 S.N.A
...3 T0071 BP64-00658A INLAY-TERMINAL;SPA400,PS SHEET,T0.5,BLK 1 S.N.A
..2 T0145 BP96-01992A ASSY COVER P-BOTTOM;SPA400,,PC+ABS,V0(NT 1 S.A
...3 T0570 4712-001041 THERMOSTAT;220VAC,7A,95+-5C,62+-10C 1 S.A
...3 T0081 6001-000116 SCREW-MACHINE;BH,+,M3,L12,NI PLT,SWRCH18 2 S.N.A
...3 T0081 6001-000581 SCREW-MACHINE;PH,+,M4,L12,NI PLT,SWRCH18 1 S.A
...3 T0081 6001-000677 SCREW-MACHINE;RH,+,-,M3,L6,ZPC(WHT),SM20 2 S.A
...3 T0081 6001-000677 SCREW-MACHINE;RH,+,-,M3,L6,ZPC(WHT),SM20 2 S.A
...3 T0081 6001-000677 SCREW-MACHINE;RH,+,-,M3,L6,ZPC(WHT),SM20 1 S.A
...3 T0081 6001-000781 SCREW-MACHINE;PH,+,M3,L8,ZPC(BLK),SWRCH1 3 S.N.A
...3 T0081 6001-001921 SCREW-MACHINE;PH,+,WWP,M3,L8,NI PLT,SWRC 4 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 3 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 1 S.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 2 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 1 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 3 S.N.A
...3 M0081 6003-001003 SCREW-TAPTITE;BH,+,B,M4,L12,ZPC(BLK),SWR 1 S.N.A
...3 M0081 6003-001070 SCREW-TAPTITE;BH,+,-,B,M2,L4,ZPC(BLK),SW 1 S.N.A
...3 M0963 6104-001010 FOOT;SJ-5017,-,BLACK,POLYURETHANE,- 1 S.A
...3 M2893 BP39-00292A LEAD CONNECTOR;SP-A400B,UL1061#28,3,100m 1 S.A
5-4
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
...3 T0049 BP47-00039A LAMP-BALLAST;EUC 200W TOPPREMIUM,300mm,1 1 S.A
...3 BP60-00041A FASTENER-FIX_NUT;SP-H700,C3604BD,M6.5,L4 2 S.N.A
...3 T0915 BP61-01480A HOLDER-MODULE; 1 S.N.A
...3 T0603 BP61-01573A HOLDER-LED; 1 S.N.A
...3 BP63-00932A COVER-DUCT TOP;A400,PC G/F20,T2.0,-,-,-, 1 S.N.A
...3 T0531 BP63-00980A COVER-BOTTOM; 1 S.N.A
....4 BP60-00038A FASTENER-PEM NUT;SP-H700,SUM24L,M4,L10,Y 1 S.N.A
....4 BP60-00039A FASTENER-PEM NUT;SP-H700,SUM24L,M6,L10,Y 1 S.N.A
....4 BP60-00100A FASTENER-PEM NUT;SP-A800,SUM24L,M6,L19,Y 4 S.N.A
...3 T0530 BP63-00981A COVER-LAMP; 1 S.N.A
....4 BP60-00039A FASTENER-PEM NUT;SP-H700,SUM24L,M6,L10,Y 1 S.N.A
...3 BP67-00318A CAP-ZOOM LENS;A400,PC+ABS,T3.5,BLACK 1 S.N.A
...3 T0597 BP94-02320A ASSY PCB MISC-DETECTOR;SP-A400B,H4VA,BP4 1 S.A
....4 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.01 S.N.A
....4 SW001 3409-000178 SWITCH-LEVER;12V,100mA,SPDT,-,27deg 1 S.A
....4 SUB007 AA61-01140F CASE-PS BOX;ANTISTATIC,PS,310,245,40 0.024 S.N.A
....4 M2893 BP39-00100A LEAD CONNECTOR;SP-H700AK,UL1007#26,UL/CS 1 S.A
....4 MP00 BP41-00059B PCB SUB-BOARD;SP-H700,FR-4,2,0,1.6mm,29x 1 S.N.A
...3 T0362 BP94-02324B ASSY PCB MISC-DMD;SPA400BX/XAA,H4VA,WOLP 1 S.A
....4 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.003 S.N.A
....4 M0013 BP97-01277B ASSY SMD-DMD;SPA400BX/XAA,H4VA,WOLPHIN 1 S.N.A
.....5 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45,96.5Sn/ 0.368 S.N.A
.....5 IC112 1103-000129 IC-EEPROM;24C02,2Kbit,256x8Bit,SOP,8P,5x 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
.....5 R110 2007-000113 R-CHIP;33ohm,5%,1/10W,TP,1608 1 S.A
.....5 C120 2203-000440 C-CER,CHIP;1nF,10%,50V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
5-5
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C120 2203-005005 C-CER,CHIP;100nF,10%,16V,X7R,1608 1 S.A
.....5 C103 2402-001158 C-AL,SMD;1UF,20%,50V,WT,TP,4X5.2MM 1 S.A
.....5 C104 2402-001158 C-AL,SMD;1UF,20%,50V,WT,TP,4X5.2MM 1 S.A
.....5 C106 2402-001158 C-AL,SMD;1UF,20%,50V,WT,TP,4X5.2MM 1 S.A
.....5 C105 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
.....5 C121 2402-001178 C-AL,SMD;10uF,20%,16V,WT,TP,4.3x4.3x5.8m 1 S.A
.....5 C120 2409-001123 C-POLYMER ,LEAD;10uF,20%,6.3V,WT,REEL,20 1 S.A
.....5 T0568 3301-001393 BEAD-SMD;60ohm,3216,1500mA,TP,41ohm/40MH 1 S.N.A
.....5 T0568 3301-001393 BEAD-SMD;60ohm,3216,1500mA,TP,41ohm/40MH 1 S.N.A
.....5 T0568 3301-001393 BEAD-SMD;60ohm,3216,1500mA,TP,41ohm/40MH 1 S.N.A
.....5 T0568 3301-001412 BEAD-SMD;60ohm,2012,800mA,TP,65ohm/110MH 1 S.N.A
.....5 CN102 3708-001709 CONNECTOR-FPC/FFC/PIC;4P,1MM,SMD-A,SN,NO 1 S.A
.....5 CN330 3711-000922 HEADER-BOARD TO CABLE;BOX,4P,1R,1.25mm,S 1 S.A
.....5 PCB BP41-00323A PCB-DMD BOARD;SP-A400B,FR-4,6,88*62 1 S.N.A
....4 CN103 3710-002488 SOCKET-BOARD TO BOARD;140P,2R,0.8mm,STRA 1 S.A
...3 BP96-01741A ASSY HOLDER P-FOOT;SPA400,ABS FOOT SHAFT 2 S.N.A
....4 BP61-01484A HOLDER-FOOT; 1 S.N.A
....4 BP61-01485A HOLDER-SHAFT;SPA400,ABS HB,BLK,M6 FOOT-A 1 S.N.A
...3 BP98-00698A ASSY K/D-OPTIC MODULE;SPA400 1 S.N.A
....4 T0081 6001-000125 SCREW-MACHINE;BH,+,-,M3,L4,ZPC(WHT),SWRC 2 S.N.A
....4 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
....4 6031-000570 WASHER-PLAIN;SCP-1,M3,ID3.2,OD10,T1.0,ZP 2 S.N.A
....4 BP61-01440A HOLDER-ZOOM LENS;A400,PC+ABS,T2.5,-,-,BL 1 S.N.A
....4 BP61-01599A PLATE-HEAT SINK;SP-A400B,AL,T2.0,NAT 1 S.N.A
....4 BP63-00926A COVER-ZOOM RING;A400,PC+ABS,T2.5,-,-,-,- 1 S.N.A
....4 BP63-00927A COVER-FOCUS RING;A400,PC+ABS,T2.5,-,-,-, 1 S.N.A
....4 BP73-00132A RUBBER-OPTICS;A400,RUBBER,-,-,-,BLACK,-, 1 S.N.A
....4 T0652 BP96-01941A ASSY LENS P;0.65" WXGA Optical Module-AV 1 S.A
...3 T0362 BP98-00699A ASSY K/D-DMD BOARD;SPA400 1 S.N.A
....4 T0268 4719-001982 DLP;1280x768 DC2,0.65",Type A 1 S.A
....4 M0081 6003-000264 SCREW-TAPTITE;PWH,+,-,B,M3,L6,ZPC(WHT),S 4 S.A
....4 BP61-01031A HOLDER-SOCKET DMD;LCP,T3.0,BLACK,203pin 1 S.N.A
....4 T0212 BP61-01431A BRACKET-PANEL;A400,AL D/C,T3.0,-,-,NAT,- 1 S.N.A
....4 BP61-01433A SPRING ETC-HEAT SINK;A400,SUS301,-,-,-,- 1 S.N.A
....4 BP63-00923A SHIELD-DMD BOT;A400,SPTE,T0.5,-,-,NAT,- 1 S.N.A
....4 BP63-00924A SHIELD-DMD TOP;A400,SPTE,T0.3,-,-,NAT,- 1 S.N.A
...3 BP98-00700A ASSY K/D-COVER-DUCT IN;SPA400 1 S.N.A
....4 M0081 6003-001070 SCREW-TAPTITE;BH,+,-,B,M2,L4,ZPC(BLK),SW 1 S.N.A
....4 T0286 BP31-00028A FAN-DC;G8025L12B2-AE-OC 1 S.A
....4 T0136 BP31-00030A FAN;BFB0612H-7S11 1 S.N.A
....4 BP61-00308A BRACKET-FILTER;SP-H700,SUS,T0.2 1 S.N.A
....4 T0032 BP61-01439A BRACKET FAN;A400,SUS,T0.2,NAT 2 S.N.A
....4 T0130 BP63-00928A COVER DUCT;A400,PC G/F20,T2.0,-,-,-,-,BL 1 S.N.A
....4 BP63-00931A COVER-DUCT IN(SUB);A400,PC G/F20,T2.0,-, 1 S.N.A
....4 BP73-00112A RUBBER-FAN;HLS5679W,SILICONE,40,BLK,V0 2 S.N.A
...3 BP98-00701A ASSY K/D-COVER-DUCT OUT TOP;SPA400 1 S.N.A
....4 M0081 6003-001023 SCREW-TAPTITE;PWH,+,-,B,M3,L10,ZPC(WHT), 2 S.N.A
....4 BP63-00933A COVER-DUCT,OUT(TOP);A400,PPS G/F30,T2.0, 1 S.N.A
...3 T0128 BP98-00702A ASSY K/D-LAMP CASE;SPA400 1 S.N.A
5-6
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 T0081 6001-000677 SCREW-MACHINE;RH,+,-,M3,L6,ZPC(WHT),SM20 3 S.A
....4 T0081 6001-000781 SCREW-MACHINE;PH,+,M3,L8,ZPC(BLK),SWRCH1 2 S.N.A
....4 M0081 6003-001023 SCREW-TAPTITE;PWH,+,-,B,M3,L10,ZPC(WHT), 2 S.N.A
....4 T0139 BP47-00038A LAMP;200W Philips fusion lamp,200mm,51*5 1 S.A
....4 BP61-01434A HOLDER-BASE LAMP;A400,SECC,0.5,NAT 1 S.N.A
....4 BP61-01436A HOLDER-LAMP;A400,SUS301,T0.5,-,-,NAT,- 2 S.N.A
....4 BP61-01437A GUIDE-LAMP;A400,MG D/C,T2.5,-,-,NAT,- 1 S.N.A
....4 BP61-01438A SPRING ETC-LAMP;A400,SUS301,-,-,-,-,-,T0 2 S.N.A
....4 T0530 BP63-00929A COVER LAMP;A400,PPS G/F30,T2.5,BLACK 1 S.N.A
...3 BP98-00703A ASSY K/D-ENGINE BASE;SPA400 1 S.N.A
....4 T0081 6001-001707 SCREW-MACHINE;BH,+,M2,L4,ZPC(BLK) 2 S.A
....4 T0081 6001-001707 SCREW-MACHINE;BH,+,M2,L4,ZPC(BLK) 2 S.A
....4 BP61-00308A BRACKET-FILTER;SP-H700,SUS,T0.2 2 S.N.A
....4 BP61-01429A BRACKET-ENGINE BASE;A400,MG D/C,T2.0,-,- 1 S.N.A
....4 BP64-00607A GLASS-UV FILTER;UV filter,glass,2,32,32 1 S.N.A
....4 BP61-01430A BRACKET-COOLER;A400,SPTE,T0.3,NAT 1 S.N.A
...3 ETC03 BP98-00704A ASSY K/D-COLOR WHEEL;SPA400 1 S.N.A
....4 T0081 6001-000125 SCREW-MACHINE;BH,+,-,M3,L4,ZPC(WHT),SWRC 2 S.N.A
....4 T0081 6001-001708 SCREW-MACHINE;BH,+,M2,L5,ZPC(BLK) 3 S.A
....4 BP61-00815A BUSH-SPACER RUBBER;SVP-50L7HX,BRASS,3.5, 2 S.N.A
....4 BP61-01598A HOLDER-COLORWHEEL;SP-A400B,AL D/C,T2.0,N 1 S.N.A
....4 T0593 BP64-00679A GLASS-COLOR WHEEL;AIR,GLASS,T0.7,55mm,RY 1 S.N.A
....4 BP73-00024A RUBBER-WHEEL TOP;shp-700,silicon,blk 2 S.N.A
...3 BP98-00705A ASSY K/D-DUCT BALLAST;SPA400 1 S.N.A
....4 T0081 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, 2 S.N.A
....4 T0286 BP31-00025C FAN-DC;G6015S12B2-BA-OC 1 S.A
....4 T0453 BP61-01587A HOLDER-BALLAST; 1 S.N.A
..2 M0102 BP96-02006A ASSY BLU P;WOLPHIN,BACK LIGHT UNIT,MB-M0 1 S.N.A
0.1 M0017 BP91-02103A ASSY MISC-CHASSIS;SPA400BAX/XAA,H6HA,STE 1 S.N.A
..2 T0132 BP94-02324A ASSY PCB MISC-DIGITAL;SPA400BX/XAA,H4VA, 1 S.A
...3 T0245 0202-001492 SOLDER-WIRE FLUX;HSE-02 LFM48 SR-34 S,-, 0.25 S.N.A
...3 T0016 0604-001252 PHOTO-INTERRUPTER;TR,-,100mW,DIP,ST 1 S.A
...3 OP102 0609-001200 Module Remocon;VERTICAL,9.6MM,TR 1 S.A
...3 OP107 0609-001204 Module Remocon;HORIZONTAL,6.5mm,TR 1 S.A
...3 CN330 3711-003843 HEADER-BOARD TO CABLE;BOX,8P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004349 HEADER-BOARD TO CABLE;BOX,3P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004352 HEADER-BOARD TO CABLE;BOX,15P,1R,2mm,STR 1 S.A
...3 CN330 3711-004386 HEADER-BOARD TO CABLE;BOX,3P,1R,2mm,ANGL 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 JA330 3722-000143 JACK-PHONE;1P(VER),AG,BLK,ANGLE 1 S.A
...3 JA333 3722-002597 JACK-PIN;3P,SN,Ni,GRN/BLU/RED,ANGLE 1 S.A
...3 JA333 3722-002602 JACK-PIN;1P(PIN+SVHS),Ni,YELLOW,ANGLE 1 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 5 S.A
...3 M0081 6003-000282 SCREW-TAPTITE;BH,+,-,B,M3,L8,ZPC(BLK),SW 2 S.A
...3 SUB09(XDR_ BN73-00026A SILICON/RUBBER-GAP PAD;AL29NO,SILICON,12 1 S.N.A
...3 SUB10(DAD2 BN73-00026A SILICON/RUBBER-GAP PAD;AL29NO,SILICON,12 1 S.N.A
...3 T0066 BP62-00016B HEAT SINK-ES;SUNRAY,A6063,T2.0,36.2,36.2 1 S.N.A
...3 T0066 BP62-00047A HEAT SINK-ES;DLP,A6063S,T2.5,13,13,TAPE 1 S.N.A
...3 T0066 BP62-00047A HEAT SINK-ES;DLP,A6063S,T2.5,13,13,TAPE 1 S.N.A
5-7
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
...3 SHIELD-BOT BP63-01047A SHIELD-PCB MAIN BOT;SPA400,SPTE,T0.5 1 S.N.A
...3 SHIELD-TOP BP63-01048A SHIELD-PCB MAIN TOP;SPA400,SECC,T0.5 1 S.N.A
...3 T0141 BP97-01277A ASSY SMD-DIGITAL;SPA400BX/XAA,H4VA,WOLPH 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45,96.5Sn/ 2.514 S.N.A
....4 D118 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D119 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D120 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D121 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D134 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D135 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D136 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D137 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D174 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D175 0401-000008 DIODE-SWITCHING;DAN217,80V,100MA,SOT-23, 1 S.A
....4 D138 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D139 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D140 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D141 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D111 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D112 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D116 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D117 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D123 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D126 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D127 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D129 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D130 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D131 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D132 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D133 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D143 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D144 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D145 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1453 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1454 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1455 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1456 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1457 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1458 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D146 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1466 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1467 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1468 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D147 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D148 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D149 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D151 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D154 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D155 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D166 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
5-8
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 D170 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D171 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D172 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D142 0402-001098 DIODE-RECTIFIER;SK34,40V,3A,SMC,TP 1 S.A
....4 D161 0402-001098 DIODE-RECTIFIER;SK34,40V,3A,SMC,TP 1 S.A
....4 D162 0402-001669 DIODE-RECTIFIER;ES3D,200V,3A,DO-214AB(SM 1 S.A
....4 D124 0403-000314 DIODE-ZENER;RLZJ9.1B,8.8-9.3V,500MW,LL-3 1 S.A
....4 D125 0403-000314 DIODE-ZENER;RLZJ9.1B,8.8-9.3V,500MW,LL-3 1 S.A
....4 D167 0403-001282 DIODE-ZENER;BZT52-C15,13.8-15.6,410mW,SO 1 S.A
....4 D176 0403-001282 DIODE-ZENER;BZT52-C15,13.8-15.6,410mW,SO 1 S.A
....4 D0254 0404-001152 DIODE-SCHOTTKY;BAT54SW,30V,200MA,SOT-323 1 S.A
....4 D0254 0404-001152 DIODE-SCHOTTKY;BAT54SW,30V,200MA,SOT-323 1 S.A
....4 D0254 0404-001152 DIODE-SCHOTTKY;BAT54SW,30V,200MA,SOT-323 1 S.A
....4 D0254 0404-001152 DIODE-SCHOTTKY;BAT54SW,30V,200MA,SOT-323 1 S.A
....4 D0254 0404-001219 DIODE-SCHOTTKY;SS29,90V,1500mA,DO-214AA, 1 S.A
....4 D0254 0404-001219 DIODE-SCHOTTKY;SS29,90V,1500mA,DO-214AA, 1 S.A
....4 D0254 0404-001219 DIODE-SCHOTTKY;SS29,90V,1500mA,DO-214AA, 1 S.A
....4 D0254 0404-001219 DIODE-SCHOTTKY;SS29,90V,1500mA,DO-214AA, 1 S.A
....4 D0254 0404-001219 DIODE-SCHOTTKY;SS29,90V,1500mA,DO-214AA, 1 S.A
....4 D0254 0404-001219 DIODE-SCHOTTKY;SS29,90V,1500mA,DO-214AA, 1 S.A
....4 D100 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D101 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D107 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D108 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D109 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D110 0406-001172 DIODE-TVS;CDS3C30GTH,48V,SMD 1 S.A
....4 D122 0407-000123 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT- 1 S.A
....4 Q103 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q104 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q109 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q110 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q111 0501-000434 TR-SMALL SIGNAL;KTC3875S-GR,NPN,150mW,SO 1 S.A
....4 Q102 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q105 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q106 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 1 S.A
....4 Q409 0505-001905 FET-SILICON;2N7002,N,60V,115mA,7.5ohm,0. 1 S.A
....4 Q409 0505-001916 FET-SILICON;Si4800BDY,N,30V,9A,0.03ohm,2 1 S.A
....4 Q409 0505-001916 FET-SILICON;Si4800BDY,N,30V,9A,0.03ohm,2 1 S.A
....4 Q409 0505-002169 FET-SILICON;Si4435BDY-T1-E3,P,-30V,-9.1A 1 S.N.A
....4 L0405 0601-001313 LED;SMD,GRN,2X1.8MM,565NM,3.16X1.6X1.1MM 1 S.A
....4 L0405 0601-001313 LED;SMD,GRN,2X1.8MM,565NM,3.16X1.6X1.1MM 1 S.A
....4 L0405 0601-001313 LED;SMD,GRN,2X1.8MM,565NM,3.16X1.6X1.1MM 1 S.A
....4 L0405 0601-001896 LED;SMD,BLUE,1.6x0.8x0.4mm,470,1.6x0.8x0 1 S.A
....4 L0405 0601-001896 LED;SMD,BLUE,1.6x0.8x0.4mm,470,1.6x0.8x0 1 S.A
....4 L0405 0601-001915 LED;SMD,RED,1.6x0.8x0.6mm,660nm,1.6x0.8x 1 S.A
....4 IC104 0801-002198 IC-CMOS LOGIC;74LVC14,INVERTER,SOP,14P,1 1 S.A
....4 IC104 0801-002198 IC-CMOS LOGIC;74LVC14,INVERTER,SOP,14P,1 1 S.A
....4 IC104 0801-002765 IC-CMOS LOGIC;74LVC1G07,SINGLE BUFFER/DR 1 S.A
....4 IC104 0801-002765 IC-CMOS LOGIC;74LVC1G07,SINGLE BUFFER/DR 1 S.A
....4 IC104 0801-002765 IC-CMOS LOGIC;74LVC1G07,SINGLE BUFFER/DR 1 S.A
5-9
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 IC104 0801-002779 IC-CMOS LOGIC;74LVC1G125,BUS BUFFER,SOT- 1 S.A
....4 IC104 0801-002780 IC-CMOS LOGIC;74LVC1G17,SCHMITT-TRIGGER 1 S.A
....4 IC104 0801-002780 IC-CMOS LOGIC;74LVC1G17,SCHMITT-TRIGGER 1 S.A
....4 IC104 0801-002858 IC-CMOS LOGIC;74HCT1G126GV,1 GATE BUFFER 1 S.A
....4 IC104 0801-002899 IC-CMOS LOGIC;4069,INVERTER,SOIC,14P,8.7 1 S.A
....4 IC129 1003-001891 IC-MOTOR DRIVER;PMD1000,QFP,48P,7.0x7.0m 1 S.A
....4 IC130 1003-001892 IC-POWER DRIVER;DAD2000,PQFP,80P,12x12mm 1 S.A
....4 IC101 1006-001266 IC-LINE TRANSCEIVER;SP3232EEY,TSSOP,16P, 1 S.A
....4 IC112 1103-001195 IC-EEPROM;24C64,64Kbit,8Kx8,SOP,5x4mm,2. 1 S.A
....4 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 1 S.N.A
....4 IC112 1103-001310 IC-EEPROM;24LC02B,256X8BIT,SOIC,8P,3.91X 1 S.N.A
....4 IC113 1105-001585 IC-DRAM;M12L64164, K4S641632,-,64Mbit,4x 1 S.A
....4 IC113 1105-001819 IC-DRAM;K4Y50084UE,XDR,512Mbit,64Mx8,FBG 1 S.A
....4 IC115 1107-001415 IC-FLASH MEMORY;29W320D,4Mx8/2Mx16Bit,TS 1 S.N.A
....4 IC131 1202-000164 IC-VOLTAGE COMP.;393,SOP,8P,150MIL,DUAL, 1 S.A
....4 T0087 1203-001488 IC-POSI.FIXED REG.;7805,T0-252,3P,-,PLAS 1 S.A
....4 IC012 1203-002387 IC-POSI.ADJUST REG.;39102,SOP,8P,153MIL, 1 S.A
....4 T0170 1203-003059 IC-SWITCH VOL. REG.;MP1583,SOIC,8P,4.9x3 1 S.A
....4 IC062 1203-003183 IC-MULTI REG.;SI-3002KWM-TL,DPAK,5P,6.6X 1 S.A
....4 T0087 1203-004893 IC-POSI.FIXED REG.;G994F1U,SOP,8P,4.9x3. 1 S.A
....4 IC118 1204-002772 IC-VIDEO PROCESS;DDP2230(2507605),EPBGA, 1 S.A
....4 IC116 1204-002776 IC-VIDEO DECODER;TVP5146M2PFPR,HTQFP,80P 1 S.A
....4 IC128 1205-003284 IC-CLOCK GENERATOR;CDCD5704PWR,TSSOP,28P 1 S.A
....4 IC117 1205-003302 IC-RECEIVER;MST3385M-LF-140,PQFP,128P,20 1 S.A
....4 IC115 1205-003320 IC-CONTROLLER;G795S1UF,SSOP,16P,5x4mm,PL 1 S.A
....4 IC126 1209-001747 IC-PLL/SYNTHESIZER;CDCDLP223PWR,TSSOP,20 1 S.A
....4 R110 2007-000040 R-CHIP;150ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000041 R-CHIP;475ohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000043 R-CHIP;1Kohm,1%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
5-10
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
5-11
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
5-12
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000071 R-CHIP;22ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000072 R-CHIP;47ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000074 R-CHIP;100ohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
5-13
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000078 R-CHIP;1Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000080 R-CHIP;2Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000082 R-CHIP;3.3Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
5-14
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q'ty SA/SNA Remark
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000087 R-CHIP;6.8Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000090 R-CHIP;10Kohm,5%,1/10W,TP,1608 1 S.A
....4 R110 2007-000093 R-CHIP;20Kohm,5%,1/10W,TP,1608 1 S.A
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
