Image preview - the first page of the document
>> Download samsung_sp-a600b_chassis_h6kb_sm documenatation <<
Text preview - extract from the document
DLP Projector
Chassis :H6KB
Model :SP-A600B
SERVICE Manual
DLP Projector Contents
1.Precautions
2. Product specifications
3.DisassemblyandReassemble
4.Troubleshooting
5.ExplodedView&PartList
6.WiringDiagram
SP-A600B
Refer to the service manual in the GSPN (see the rear cover) for the more information.
Contents
1.Precautions.............................................................................................................. 1-1
1-1. Safety Precautions ......................................................................................................... 1-1
1-2. Servicing Precautions ..................................................................................................... 1-2
1-3. Static Electricity Precautions .......................................................................................... 1-2
1-4. Installation Precautions .................................................................................................. 1-3
2. Features and Specifications .................................................................................. 2-1
.
2-1. Features and Specifications ........................................................................................... 2-1
2-2. Spec Comparison to the Old Models .............................................................................. 2-2
2-3. Accessories .................................................................................................................... 2-3
2-4. Key service components ................................................................................................ 2-4
3.DisassemblyandAssembly................................................................................... 3-1
3-1. Disassembly ................................................................................................................... 3-1
4.Troubleshooting...................................................................................................... 4-1
4-1. LED Indications .............................................................................................................. 4-1
4-2. Actions to Take according to the 1LED Indications (Users) ............................................ 4-2
4-3. Actions to Take for Issues that may Arise due to New Functions ................................... 4-3
4-4. Troubleshooting .............................................................................................................. 4-4
4-5. When the Standby LED Does Not Turn On .................................................................... 4-5
4-6. When the Power Does Not Turn On ............................................................................... 4-6
4-8. Troubleshooting 2. The LAMP and TEMP LEDs Blink .................................................... 4-8
4-9. Troubleshooting 3. The TEMP LED Blinks ..................................................................... 4-9
4-10. Troubleshooting 4. The Standby LED Is Turned On and the LAMP and
TEMP LEDs blink............................................................................................ 4-11
4-11. Troubleshooting 5. The Standby, LAMP, and TEMP LEDs blink ................................. 4-13
4-12. When a Blank Screen Is Displayed ............................................................................ 4-15
4-13. When an Input Screen Error occurs ........................................................................... 4-16
4-14. Adjustments ................................................................................................................ 4-17
5.ExplodedView&PartList...................................................................................... 5-1
5-1. Exploded View ................................................................................................................ 5-1
5-2. Parts List ......................................................................................................................... 5-4
6.WiringDiagrams...................................................................................................... 6-1
6-1. Wiring Diagrams ............................................................................................................. 6-1
6-1-1. Engine Part Wiring Diagram ........................................................................................ 6-2
6-2. Connector Functions and their Connection Errors ................................................................6-5
1. Precautions
1. Precautions
1-1. Safety Precautions
Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
1. Do not modify the circuits of the product for safety reasons.
2. Do not supply power to your product before a service engineer has serviced it.
3. When the monitor is operating, the product may receive a shock due to the semiconductor heat sink.
1-1-2. Servicing the LCD Monitor
1. When servicing the LCD Monitor, Disconnect the AC line cord from the AC outlet.
2. It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of
this meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
1. Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the
chassis and other metal parts in the monitor.
2. Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
3. Leakage Current Hot Check (Figure 1-1):
WARNING : Do not use an isolation transformer during this test.
(READING SHOULD)
NOT BE ABOVE 0.5mA
LEAKAGE
DEVICE
CURRENT
UNDER
TESTER
TEST
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
*ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
Figure 1-1. Leakage Current Test Circuit
Use a leakage current tester or a metering system that complies with American National Standards Institute (ANSI
C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL Publication UL1410, 59.7).
4. With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit's AC switch
first in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit,
etc.) and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identified by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, fire and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.
1-1
1. Precautions
1-2. Servicing Precautions
WARNING: An electrolytic capacitor installed with the wrong polarity might explode.
Caution: Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
Note: If unforeseen circumstances create conflict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1 General Servicing Precautions
1. Always unplug the unit's AC power cord from the AC power source and disconnect the DC Power Jack before
attempting to:
(a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect a test
component in parallel with an electrolytic capacitor.
2. Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes
used. The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such
elements to their original position.
3. After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that
the area around the serviced part has not been damaged.
4. Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels,
input terminals and earphone jacks).
5. Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON.
Connect an insulation resistance meter (500 V) to theblades of the AC plug.
The insulation resistance between each blade of the AC plug and accessible conductive parts (see above) should be
greater than 1 megohm.
6. Always connect a test instrument's ground lead to the instrument chassis ground before connecting the positive lead;
always remove the instrument's ground lead last.
1-3. Static Electricity Precautions
Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some field-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
1. Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
2. After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent
accumulation of an electrostatic charge.
3. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ESDs.
4. Use only a grounded-tip soldering iron to solder or desolder ESDs.
5. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static" can generate
electrical charges sufficient to damage ESDs.
6. Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
7. Immediately before removing the protective material from the leads of a replacement ESD, touch the protective
material to the chassis or circuit assembly into which the device will be installed.
Caution: Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
8. Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together,
or lifting your foot from a carpeted floor can generate enough static electricity to damage an ESD.
1-2
1. Precautions
1-4. Installation Precautions
1. For safety reasons, more than two people are required for carrying the product.
2. Keep the power cord away from any heat emitting devices, as a melted covering may cause fire or electric shock.
3. Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal
temperature may cause fire.
4. Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed
to moisture. Otherwise, it may cause a fire or electric shock.
5. Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause fire or electric
shock.
6. Keep the antenna far away from any high-voltage cables and install it firmly. Contact with the highvoltage cable or the
antenna falling over may cause fire or electric shock.
7. When installing the product, leave enough space (10cm) between the product and the wall for ventilation purposes.
A rise in temperature within the product may cause fire.
1-3
2. Product specifications
2. Features and Specifications
2-1. Features and Specifications
Model SP-A600B
Features
1080p Model-adopted entry-level full HD product (AV Hi-end 720p, entry-level 1080p market)
Entry-level 1080p full HD AV projector with excellent price competitiveness
Provides outstanding color reproduction, complying with the 1080p resolution standards
Implements film-like pictures with excellent color reproduction
Refined whale-shaped new design
Supports full HD pictures
AV-level high brightness (1000 ANSI)
Low noise under 26dB satisfying advanced quality standards
2*HDMI, D-Sub, 1*Component, Composite, S-VHS, RS-232C
Manual Lens Focus, Zoom control
HDMI-applied user-friendly interface
Major Specifications
Items Specifications
Panel Diagonal Size 0.65"
Deflection Frequency Panel
1080P (1920 X 1080)
Resolution (Width X Height)
Panel Manufacturer Texas Instrument
Optimal Resolution 1920 X 1080 @ 60Hz
Lamp Type 220W UHP
Guaranteed Lamp Lifetime 3,000 Hours
Lamp Manufacturer Philips
Screen Color 49.8M Colors (1920 x 1080 x 3 x 8Bit)
Max. Resolution 1920 x 1080
Brightness Max 1,000
Contrast Ratio 3,000:1
Lens Specifications Manual focus and manual zoom
Diagonal Screen Size 40" ~ 300" (diagonal)
Projection Distance 1.3m ~ 13m
Keystone Vertical direction
Input Video Signal Video, S-Video, Component, Analog PC, HDMI 1,2
Input Frequency Hor. Freq. : 30 ~ 80KHz / Ver. Freq. : 56 ~ 85Hz
Voltage 110/220Vac +/-10%, 50/60Hz +/-3Hz
Rated Power Consumption 275W (Standby power of 1W or less)
Noise Level Eco mode: 22dB, Theater mode: 24dB
Dimensions 343.1mm(W) x 162.4mm(H) x 347.2mm(D)
Weight 4.7Kg
Operating temperature: 0~ 40
Operating humidity: 10% ~ 80%
Ambience
Storage temperature: -20~ 45
Storage humidity: 5% ~ 95%
Note: The design and specifications of the product are subject to change without prior notice.
2-1
2. Product specifications
2-2. Spec Comparison to the Old Models
Model SP-A600B SP-A800B
Design
Panel 1920 x 1080 1920 x 1080
Brightness 1000 1000
Contrast 3000 : 1 10000 : 1
Colors Glossy black High glossy black
HDMI O O
Dynamic Black X O
2-2
2. Product specifications
2-3. Accessories
Product Description Ccde. No Remark
Quick Setup Guide BP68-00689B
Warranty Card
BP68-00570D
(Not available in all locations)
User's Guide,
BP59-00137A
Monitor Driver
Power Cord 3903-000212
Samsung Electronics
Service center
Cleaning Cloth BN63-01798B
Remote Control/
BP59-00132A
Batteries
2-3
2. Product specifications
2-4. Key service components
NO Description Code No. shape
1 DMD PANEL 4719-002082
2 DMD Board BP94-02362A
3 COLOR WHELL BP64-00727A
4 Cooling Fan1 BP31-00042A
5 Cooling Fan2 BP31-00042A
6 Cooling Fan3 BP31-00041A
7 BALLAST BP47-00056A
2-4
2. Product specifications
NO Description Code No. shape
8 SMPS BP44-01009A
9 Digital Board BP94-02361A
10 Lamp BP98-00760A
11 Rear Panel BP96-02175A
12 TOP Case BP96-01988A
13 BOTTOM Case BP90-00451A
14 Touch Pad BP96-01964A
2-5
2. Product specifications
NO Description Code No. shape
15 TEMP SENSOR 4712-001041
2-6
3. Disassembly and Assembly
3. Disassembly and Assembly
This section describes the disassembly and reassembly sequences for this projector.
Warning: As this projector has parts that are sensitive to static electricity, be careful when handling them.
3-1. Disassembly
Caution: 1. Turn the projector off before beginning the disassembly.
2. Carefully disassemble the projector as described in the following procedures.
3. When disassembling the projector, do not use any metal tools except for the provided jig.
Item Description Photo Screws
1. Remove the only screw that holds the
lamp cover.
Removing
the Cover for
separating
the Lamp
2. Push the cover to the left-hand side to
remove it.
3-1
3. Disassembly and Assembly
Item Description Photo Screws
3. Remove the only screw that holds the
lamp cover.
Removing
the Lamp
4. Lift up the grip to pull out the lamp.
3-2
3. Disassembly and Assembly
Item Description Photo Screws
5. Push both the hooks on each side of
the projection lens cap on the front of
the product.
Caution : Make sure to completely
disconnect the power before
starting any disassembly.
6. Remove both the left and right screws
located on the rear of the product.
Removing
the Top
Cover
7. Lift up the hook located in the center of
the rear of the product.
Slightly push the bottom cover in the
direction of the arrows to unfasten the
four hooks on both sides of the cover.
When a `clicking' sound is heard, lift up
the top cover.
8. Unfasten the remaining hooks on the
Removing
front of the cover in order to lift up the
the Top
cover, paying careful attention not to
Cover
damage the projection lens.
3-3
3. Disassembly and Assembly
Item Description Photo Screws
9. Remove the two screws on the top left
and right of the rear panel.
10. Remove the only ground-connecting
Removing
screw of the inlet attached to the rear
the Rear
panel.
Panel
11. Remove the rear panel from the
bottom assembly.
Separating 12. Separate the main harness from the
the Harness board.
Removing
13. Remove the four screws that hold the
the Duct
duct cover.
Cover.
3-4
3. Disassembly and Assembly
Item Description Photo Screws
14. Separate the connector connecting
the main frame and the circuit
assemblies.
Removing
the Circuit
Remove the three screws that hold
Assemblies
the circuit assemblies.
Pull out the circuit assemblies.
Separating
the Inlet from 15. Remove the two screws connected to
the Rear the rear panel.
Panel
3-5
3. Disassembly and Assembly
Item Description Photo Screws
Removing 16. Separate the connector connected to
the Inlet the circuit assemblies.
Separation
between 17. Remove the two harnesses
circuit connecting the circuit assemblies.
assemblies
3-6
3. Disassembly and Assembly
Item Description Photo Screws
Removing 18. Remove the only screw to separate
the Ballast the shield from the circuit assemblies.
19. Remove the four screws to separate
Removing
the circuit assemblies from the
the SMPS
insulator and the shield.
Removing
20. Remove the four screws that hold the
the Main
main-board and shield together.
Board
3-7
3. Disassembly and Assembly
Item Description Photo Screws
21. Remove the three screws fixing the
three types of sub-boards.
Push the LED assembly out and
separate the remaining boards
upwards.
Removing
the Sub-
boards
22. Remove the sub-board assembly.
Removing 23. Remove the two screws fixing the
the thermostat to separate the thermostat
Thermostat upwards.
3-8
3. Disassembly and Assembly
Item Description Photo Screws
Removing
24. Remove the two screws that hold the
the right-side
fan duct.
Fan Duct
25. Lift up the fans located on the left and
right sides.
Removing
the left and Caution : During insertion, the fan's
right-side direction, which is marked
Fans on top of the fan taking into
account the wind direction,
should be considered.
3-9
3. Disassembly and Assembly
Item Description Photo Screws
Removing 26. Remove the two screws that hold
the Intake the duct and then separate the duct
Duct upwards.
27. Remove the three screws that hold
Removing
the color wheel and separate the
the Color
connector connecting the color wheel
Wheel
to the DMD board.
Removing
the Color 28. Remove the three screws connecting
Wheel from the color wheel to the frame.
the Frame
3-10
3. Disassembly and Assembly
Item Description Photo Screws
29. Remove the four screws on the heat
sink that sticks fast to the DMD board.
Removing
the DMD
board
30. It is separated into three parts as
shown in the picture.
Removing
31. Push the center of the interposer
the Panel
forward with your hand to separate the
from the
panel.
Interposer
Removing
32. Remove the three screws that hold
the Optical
the optical engine.
Engine
3-11
3. Disassembly and Assembly
Item Description Photo Screws
33. Release the fan blower's lead wire to
the left-hand side from the holder.
Removing
the Fan
Blower
34. Remove the three screws fixing the
blower.
Removing 35. Remove the three screws that hold
the Optical the engine base and then separate
Engine Base the base upwards.
3-12
3. Disassembly and Assembly
Item Description Photo Screws
36. Remove the only screw that holds the
Removing
detector switch.
the Detector
Remove the detector switch held by
Switch
the holder upwards.
The assembly is in the reverse order of the disassembly.
3-13
4. Troubleshooting
4. Troubleshooting
4-1. LED Indications
Item TEMP LAMP Standby
LED Color
Red Blue Blue
-On,-Blinking,-Off
No. TEMP LAMP STANDBY Description
Ifoneofthepowerbuttonsontheremotecontrolorprojectorispressedfor
1 projectoroperationinastateofnormalpowersupply,thenthescreenwillbe
displayedinabout30seconds.
2 Theprojectorisinnormaloperation.
Oneofthepowerbuttonsontheremotecontrolorprojectorhasbeen
3
pressedtoturntheprojectoron,andtheprojectorisreadyforoperation.
Oneofthepowerbuttonsontheremotecontrolorprojectorhasbeen
pressedtoturntheprojectoroff,andthecoolingsystemisoperatingto
4
cooldowntheairinsidetheprojector(Carriedoutforaboutoneandahalf
minutes).
Oneofthecoolingsystems,suchasthecoolingfaninsidetheprojector,is
5
inabnormaloperation.Refertotheaction1below:
Thelampcovercoveringthelampisnotproperlyclosed.Refertotheaction
6
2below:
Thetemperatureinsidetheprojectorhasincreasedbeyondthemaximum
7 maintenancetemperaturelimitduetoacertainreason.Thepowerwillbe
turnedoffautomatically.Refertotheaction3below:
Astart-uperrorispresentintheDDPICinsidetheproduct.Refertothe
8
action4below:
9 Anoperationerrorispresentinthelamp.Refertotheaction5below:
10 Thelamp'slifespanhasexpired.Refertotheaction6below:
Theproduct'sinternalmemorydoesnotseemtobeworkingproperly.
11
Contactyourlocalservicecenter.
Theproduct'sinternalpowerdoesnotseemtobeworkingproperly.Contact
12
yourlocalservicecenter.
Astart-uperrorispresentinthecolor-wheelinsidetheproduct.Refertothe
13
action4below:
4-1
4. Troubleshooting
4-2. Actions to Take according to the 1LED Indications (Users)
Action Status Description
Thecoolingfansysteminside Ifthesamesymptompersistsevenwhentryingtore-operate
Action1 theprojectorisinabnormal theprojectorafterunpluggingandpluggingthepowercable,
conditions contactyourdistributororlocalservicecenter.
Thelampcovercoveringthe
Checktomakesurethatthescrewsonthebottomofthe
lampisnotproperlyclosed
Action2 projectoraretightlysecureandifnoproblemisfound,contact
oranerrorispresentinthe
yourdistributororlocalservicecenter.
sensorsystem
Changethearrangementoftheprojectorreferringtothe
Thetemperatureinsidethe installationprecautionsprovidedearlier,lettheprojectorcool
Action3 projectorhasincreased downsufficientlyandthenre-operatetheprojector.
abnormally Ifthesamesymptompersists,contactyourdistributororlocal
servicecenter.
Ifthesamesymptompersistsevenwhentryingtore-operate
Thestart-upoftheDDPICor
Action4 theprojectorafterunpluggingandpluggingthepowercable,
colorwheelhasfailed
contactyourdistributororlocalservicecenter.
Theprojector'spowerwas
notproperlyturnedoff,the Turnoffthepower,andthentakeasufficientamountoftime
projectoristurnedonagain tolettheprojectorcooldownbeforeturningitonagain.If
Action5
shortlyafteritwasturnedoff thesamesymptompersists,contactyourdistributororlocal
oranerrorispresentinthe servicecenter.
operationofthelamp
Checkhowlongthelamphasbeenusedintheinformation
Thescreenbrightnessor
Action6 displayscreenandthencontactyourdistributororlocal
imagequalityhasdegraded
servicecentertoreplacethelamp.
4-2
4. Troubleshooting
4-3. Actions to Take for Issues that may Arise due to New Functions
Installation
Problems Actions
Thepowerdoesnotturnon. Checkwhetherthepowercableisconnectedcorrectly.
Thepoweristurnedonimmediatelywhenthe
Thisisanormaloperation..
powercableisconnected.
Adjustthepositionsoftheprojectorandthescreensothattheprojectedlightfrom
theprojectorisperpendiculartothescreen.Thenadjustthefocusring.
Thescreenisdistortedorisdisplayedina
trapezoidform. WerecommendthatyoudonotusetheMenu>Setting>VerticalKeystone
function,ifpossible.
(Thescreenmaybedistorted.)
Checkwhetherthevideocableisconnectedtothecorrectsignalterminaland
Theexternaldevicescannotbeselectedora checktheconnections.
blankscreenisdisplayed.
Iftheconnectionisnotcorrect,nodevicecanbeselected.
ScreenandExternalDevice
Problems Actions
Checkthepowerconnectionstatusoftheprojector.
Checkwhethertheinputselectioniscorrect.
Ablankscreenisdisplayed.
Checkwhethertheprojectorcablesareconnectedcorrectly.
CheckwhethertheBrightnessissettotheminimum.
CheckwhethertheadjustmentoftheMenu>Screen>ScreenUser
Thecolorisnotgood.
Adjustment>Contrastiscorrect.
Adjustthefocus.
Theimageisfaint.
Checkwhethertheprojectiondistanceistoocloseortoofaraway.
Astrangesoundisheardintheprojector. Ifthesoundoccurscontinuallyduetoafaultypart,contactaservicecenter.
Whennoiseoccurswhileusingyourcomputer,adjustthefrequencyinthe
AWaterfalloccursonthescreen.
Menu>Setting>PC>FrequencyAdjustment.
Checkwhethertheexternaldeviceisoperating,andcheckwhetherthe
Thescreenfortheexternaldeviceisnot
BrightnessandContrasthavebeenchangedintheMenu>Screen>
displayed.
ScreenUserAdjustmentoftheprojectormenu.
Checktheconnectionstatusoftheexternaldevice,andrecheckthecable
Abluescreenisdisplayed.
connections.
Thescreenisdisplayedinblackandwhiteor ChecktheBrightnessandContrast.
thecolorisstrange.Thescreenisdarkorvery
bright. Toresetthesettingstothefactorydefaults,runtheResetmenuitem.
4-3
4. Troubleshooting
4-4. Troubleshooting
1. etthecustommodeasfollowsbeforebeginningarepair.
S
-Nosoundinputissupported.
1)Videoinput
-Broadcastingtype:NTSC,NTSC-4.43,PAL,PAL-N,PAL-M,PAL-60,andSECAMinaworld-widescale
2)S-Videoinput
-Broadcastingtype:NTSC,NTSC-4.43,PAL,PAL-N,PAL-M,PAL-60,andSECAMinaworld-widescale
3)Componentinput
-Resolution: 80p@60Hz,576p@50Hz,720p@60Hz,720p@50Hz,1080i@60Hz,1080i@50Hz,1080p@60Hz,
4
1080p@50Hz
4)PCinput
-Resolution:1280X768,1280X1024
5)HDMIinput
-Resolution: 80i@60Hz,576i@50Hz,480p@60Hz,576p@50Hz,720p@60Hz,720p@50Hz,1080i@60Hz,
4
1080i@50Hz,1080p@60Hz,1080p@50Hz
4-4
4. Troubleshooting
4-5. When the Standby LED Does Not Turn On
Symptom -TheStandbyLEDdoesnotturnoneventhoughthepowercableisconnected.
-Checkthepowercableconnections.
- hecktheconnectionsbetweentheSMPSboardandtheinlet(thepartwherethepowercableis
C
connected).
- heckwhethertheconnectioncable(8-pin)betweentheSMPSandtheMainboardisconnected
C
MajorCheckpoints correctly.
-CheckwhethertheLED(OP101)oftheMainboardturnson.
-ChecktheIC1601outputoftheMainboard.
-Youcanmeasure5voltagethroughOP101(S5V_A).
-Youcanmeasure13voltagethroughOP102(P13V).
No
Isthepowercableconnectedcorrectly? Connectitcorrectly.
Diagnostics
Yes
No
IstheSMPSconnectedcorrectly? Connectitcorrectly.
Yes
IstheLEDoftheMainboardturnedon? No
ReplacetheMainboard.
(Checkthisthroughtheholesontheshieldcase.)
Yes
No CheckIC1601anditsrelated
IstheoutputpowerofIC1601normal?
circuits.ReplacetheMainboard.
CircuitDiagrams
andWaveforms
MakesuretoturnoffthepowerbeforeworkingontheSMPS.
Cautions
Becarefulofresidualcurrent.
4-5
4. Troubleshooting
4-6. When the Power Does Not Turn On
- heprojectordoesnotoperateviathePowerbuttonontheremotecontrolorthetopofthe
T
Symptom
projectorwheninstandbymode(StandbyLEDON,LAMP/TEMPLEDOFF).
-Checkthepowercableconnections.
- hecktheconnectionsbetweentheSMPSboardandtheinlet(thepartwherethepowercableisconnected).
C
-Checkwhethertheconnectioncable(8-pin)betweentheSMPSandtheMainboardisconnectedcorrectly.
MajorCheckpoints -CheckwhethertheLED(OP101)oftheMainboardturnson.
-ChecktheIC1601outputoftheMainboard.
-CheckwhetherthekeypadattachedinsidethetopcoverisconnectedtotheMainboardcorrectly.
-CheckwhethertheLEDboardandtheMainboardintheprojectorareconnectedcorrectly.
IR/KEY
connections
(12P) InletandSMPS
connectioncheck
InletandSMPS
connectioncheck
Diagnostics
No
Isthepowercableconnectedcorrectly? Connectitcorrectly.
Yes
No
IstheSMPSconnectedcorrectly? Connectitcorrectly.
Yes
PressthePowerbuttonontheremote
No
controltoturntheprojectoron.Isthe ReplacetheMainboard.
voltageofpin7(SW_POWER)of
CN101measuredasbeingbetween3
to3.3V?
Yes
ReplacetheSMPS.
CircuitDiagrams
andWaveforms
MakesuretoturnoffthepowerbeforeworkingontheSMPS.
Cautions
Becarefulofresidualcurrent.
4-6
4. Troubleshooting
4-7. Troubleshooting 1. The Standby and TEMP LEDs blink
Symptom Troubleshooting1.TheStandbyandTEMPLEDsblink.
-Thisindicatesthatthecoolingfaninsidetheprojectorisnotoperatingnormally.
-Checkwhetherallthree(3)fansareconnectedcorrectlytotheMainboard.
MajorCheckpoints -Checkwhetherthefanisoperating.
-Checktheoperatingvoltageofthefan.
-ChecktheTachosignalsofthefan.
Areallthree(3)fansconnectedcorrectly Connectthefanconnectioncablescorrectly.
No (Sincetherearemanycablesconnectedtothe
totheMainboard?
Mainboard,takecarewhenconnectingthem.)
Yes
Istheoperatingvoltageofthefannormal? No
Isthefanrotating? No
(Approx.8.5V,11Vand11Vrespectivelyforthe
pinsCN107,110and114ofthemainboard)
Yes
Yes
Diagnostics AretheTachosignalsofthefannormal? No
(Pin1ofCN107) Replacethefan.
Yes
CheckIC601,602,603,604related
CheckIC604andrelatedcircuits.
circuits.
ReplacetheMainboard..
CircuitDiagrams
andWaveforms
-Thefrequencymaychange.Checkthewaveformsonly.
Checkwhetherallthree(3)fansareoperatingnormally.
Cautions Checkalltheconnectioncablesofthethree(3)fans.
Becarefulofresidualcurrent.
4-7
4. Troubleshooting
4-8. Troubleshooting 2. The LAMP and TEMP LEDs Blink
Symptom Troubleshooting2.TheLAMPandTEMPLEDsblink.
-Thisindicatesthatthelampreplacementcoverinsidetheprojectorisopen.
MajorCheckpoints -Checkwhetherthelampreplacementcoverisclosed.
-CheckwhethertheCoverdetectionswitchisoperatingnormally.
ispressed>
Isthelampreplacementcoverclosed No
Closethecovercorrectly.
Diagnostics correctly?
Yes
IstheCoverdetectionswitchoperatingnormally? No
(Ashort-circuitoccurswhentheswitchis Replacetheswitch.
pressed.)(Theswitchisopenwhentheswitchis
inthemiddle.)
Yes
CheckIC902andrelatedcircuits.
ReplacetheMainboard.
CircuitDiagrams
andWaveforms
MakesuretoturnoffthepowerbeforeworkingontheSMPS.
Cautions
Becarefulofresidualcurrent.
4-8
4. Troubleshooting
4-9. Troubleshooting 3. The TEMP LED Blinks
Symptom Troubleshooting3.TheTEMPLEDblinks.
-Thisindicatesthatthethermostatinsidetheprojectorhasbeenactivated.
Checkpoints -Checktheheatradiationstatusoftheprojector.
-Checkthethermostat.
Drainhole Inlet hole
Checkifthedrainandinletholesofthe
projectareclogged,andcooltheprojector
forasufficientamountoftime.
Checkwhetherthethree(3)fansare No
Connectitcorrectly.
connectedcorrectly.
Yes
Checkwhetheranyforeignmaterialhas
enteredthefanandisobstructingthe
operationofthefan
Yes
Diagnostics
DoestheTempLEDstillblink?
Yes
Isthethermostatoperatingnormally?
(Removethethermostatandleaveit No
Replacethethermostat.
atroomtemperature.Checkwhethera
short-circuithasoccurred.)
Yes
CheckD601andrelatedcircuits.
ReplacetheMainboard.
4-9
4. Troubleshooting
CircuitDiagrams
andWaveforms
MakesuretoturnoffthepowerbeforeworkingontheSMPS.
Cautions
Becarefulofresidualcurrent.
4-10
4. Troubleshooting
4-10. Troubleshooting 4. The Standby LED Is Turned On and the LAMP
and TEMP LEDs blink
Symptom Troubleshooting4.TheStandbyLEDisturnedonandtheLAMPandTEMPLEDsblink.
-Thisindicatesthatthecolorwheelinsidetheprojectorisnotrotatingnormally.
Checkpoints -Checkthecolorwheel.
-Checkthecolorwheelsensor.
Isthecolorwheelrotating? No
(Thiscanbecheckedbythehighnoise No
CheckTP_CWOUTATP_
thatcanbeheardwhilethecoolingfanis CWOUTBTP_CWOUTCTP_
rotatingwhentheproductisoperating.) CWCTRonCN201oftheDMD
Yes boardandontheIC1601circuit
ofthemainboard.
CheckIC802andrelatedcircuits. No
(Colorwheelsensorsignal)
Diagnostics Yes
Yes
Replacetheboardwiththe
problem.
Replacethesensorboard.
(DMDboardorMainboard)
Replacethecolorwheel.
ReplacetheMainboard.
CircuitDiagrams
andWaveforms
4-11
4. Troubleshooting
OUTA(TP187) OUTB(TP189)
OUTC(TP188) CWCTR(TP190)
CircuitDiagrams
andWaveforms
CW_SENSOR(TP184)
MakesuretoturnoffthepowerbeforeworkingontheSMPS.
Becarefulofresidualcurrent.
Cautions Whenworkingonthecolorwheel,takecarenottotouchit.
WhenworkingontheDMDboard,takecarethattheopticalpartsandtheDMDboardarenot
stainedbyforeignmaterialsandthattheyarenottouched.
4-12
4. Troubleshooting
4-11. Troubleshooting 5. The Standby, LAMP, and TEMP LEDs blink
Symptom Troubleshooting5.TheStandby,LAMP,andTEMPLEDsblink.
-Thisindicatesthatthelampdoesnotturnon.
-Checkthelamp
MajorCheckpoints -ChecktheDMDpanel
-ChecktheDMDboard
-Checkthedigitalboard
Checkthelamp.
No
Doesthelamphaveaproblem? Replacethelamp.
(RefertoLampError.)
Yes
Isthecableconnectedcorrectly? No Replacethecable.
Yes
IspowersuppliedtotheMainboard
normally? No ReplacetheSMPS.
Pins2,3and5ofCN101oftheMain
board:13V
Yes
Isthecolorwheelrotating? No
(Checkthecolorwheelsensorsignalson PerformAction4
theIC802circuitoftheMainboard.
Yes
Diagnostics
Ispowersuppliedtotheballastboard
No
normally? ReplacetheSMPS.
Becarefulofhighvoltage:380V
Yes
Istheoperatingsignalsuppliedtothe No ReplacetheMainboard.
ballastnormally?
Yes
Replacetheballast.
No ReplacetheDMDboard.
Isthelampoperatednormally?
Isthelampoperatingnormally? No ReplacetheDMDboard.
4-13
4. Troubleshooting
LAMPCTRL(CN110pin4) UART1_TXD(CN110pins3and5)
CircuitDiagrams
andWaveforms
MakesuretoturnoffthepowerbeforeworkingontheSMPS.
Makesuretoturnoffthepowerbeforeworkingontheballast.
Becarefulofresidualcurrent.
Cautions WhenworkingontheDMDboard,takecarethattheopticalpartsandtheDMDboardarenot
stainedbyforeignmaterialsandthattheyarenottouched.
Makesuretocoolthelampforasufficienttimebeforeworkingonthelamp.
Whenworkingonthelamp,takecarethattheinsideofthelampisnotstainedbyforeignmaterials
andthatitisnottouched.
4-14
4. Troubleshooting
4-12. When a Blank Screen Is Displayed
Symptom -Whenablankscreenisdisplayed.
-ChecktheconnectionsbetweentheDMDboardandtheMainboard.
MajorCheckpoints -ChecktheMainboardoutput
-ChecktheDMDpanel
ChecktheconnectionsbetweentheDMD No
Connectthemcorrectly.
boardandtheMAINboard.
Yes
No
Diagnostics CheckthevideooutputoftheMainboard. ReplacetheMainboard.
Yes
ReplacetheDMDpanel.
MakesuretoturnoffthepowerbeforeworkingontheSMPS.
Becarefulofresidualcurrent.
Cautions
WhenworkingontheDMDboard,takecarethattheopticalpartsandtheDMDboardarenot
stainedbyforeignmaterialsandthattheyarenottouched.
4-15
4. Troubleshooting
4-13. When an Input Screen Error occurs
Symptom -Whenaninputscreenerroroccurs
-Checkthescreenstatusbytheinputscreen.
-ChecktheOSDmenuscreenstatus.
MajorCheckpoints -ChecktheCCA.
-ChecktheAutoColor.
-ChecktheAutoAdjustment.
Isthereaninputscreenwithnoscreen No ChecktheOSDscreen.
error? Doesanerroroccur?
Yes Yes
No
ReplacetheMAINboard.
Diagnostics
CheckthetestpatternoftheDDPin No
Factorymode.Doesanerroroccur?
Yes
ChecktheDMDboardandtheDMDpanel.
MakesuretoturnoffthepowerbeforeworkingontheSMPS.
Cautions
Becarefulofresidualcurrent.
4-16
4. Troubleshooting
4-14. Adjustments
4-14-1. Adjustment Items when Replacing a Part
1.BeforeReplacingtheMainBoard
- nterorrunFactoryMode-Service-EEPROMCopy-MaintoDMDtocopythewhitebalancedatatotheDMDboard,
E
andthenreplacetheMainboard.
2.AfterReplacingMainBoard
- nterorrunFactoryMode-Service-EEPROMCopy-DMDtoMaintocopythewhitebalancedatasavedontheDMD
E
boardtotheMainboard.
-EnterorrunFactoryMode-Service-UserResettoresettheitemsintheusermenutothefactorydefaults.
3.AfterReplacingtheLamp
-EnterorrunFactoryMode-Service-LampTimeCleartoresetthelamptime.
4-14-2. Entering Factory Mode
1. henusingthefactoryremotecontrolfortheprojectorprovided,
W
pressthefactorybuttonwithin3secondsofpressingthe..infobutton.
2. henusingtheremotecontrolforageneralprojector(TM95),
W
presstheMENU,RETURN,INFO,EXIT,andONbuttonssequentiallyinStandbymode.
4-14-3. Factory Mode
FirstScreeninFactoryMode
Hornet PC
1.OptionTable(Service) 034100000401332D0404
0000
2.WBAdjust
3.Information 4.AdvancedMenu
Checksum
P-HRNTAWWM-0023
P-HRNTAWWS-00B
EDID:A600_All_1.3
HDCPSuccess
DMDSWVersion001
May072009
17:32:40
4-17
4. Troubleshooting
4-14-4. Factory Mode - Service
1.OptionTable(Service)
FactoryReset ProtectionError
Language:English ProtectionClear
HotPlug:On MSTARTESTPATTERN:
HotPlugCtrl:On LampControl:0
HotPlugDelay:12 LAMPTEST
EEPROMCOPY HDMI1_EQ:MIDDLE
Control HDMI2_EQ:MIDDLE
SpreadSpectrum
DebugMode:Normal
TempProtection:Enable
LampTime:00Hour
LampTimeClear
ProjectorTime:00Hour
ProjectorTimeClear
Factorymodescreen
Factorymode Description
OptionTable(Service) Serviceoptionsmenu
WBAdjust Menuforadjustingthewhitebalancesetting
AdvancedMenu Dedicatedmenuusedduringproductdevelopment
Checksum Checksthecurrentsoftware'schecksum
P-HRNTAWWM-0023 Versionofthemainsoftwarecode
P-HRNTAWWS-000B Versionofthesub-softwarecode
EDID:A600_All_1.3 InformationabouttheinputtedEDID
HDCPSuccess ShowswhethertheHDCPinputispresent
DMDSWVersion001 VersionoftheDMDsoftware
FactoryReset ResetstheCustomsettingstodefault
Language Definesthedefaultlanguage
HotPlug DefinestheHotPlugoftheHDMI
HotPlugDelay DefinestheHotPlugoftheHDMI(Unit:100ms)
EEPROMCOPY BacksupyourEEPROMdata
Control ControlssettingsregardingEDID,EEPROMandJackIdentification
SpreadSpectrum Defaultvalueshouldbemaintained,ortheEMIwillbeaffected.
DebugMode DefinesRS-232C,etc.andshouldbekeptin"Normal"mode
TempProtection Defineswhethertousethetemperatureprotectionfeature
LampTime Displaysthelengthoftimethatthelamphasbeeninoperation
LampTimeClear Clearsthelengthoftimethatthelamphasbeeninoperation
ProjectorTime Displaysthelengthoftimethattheprojectorhasbeeninoperation
ProjectorTimeClear Clearsthelengthoftimethattheprojectorhasbeeninoperation
ProtectionError Checksdetailsonprotectionerrorsthathaveoccurred
ProtectionClear Clearsdetailsoftheabovemenu(Protection)
MSTARTESTPATTERN Testpattern
LampControl AdjusttheLampsettingstepsintheCustommenu
LAMPTEST Thisisatestmenuusedduringproductdevelopmentandshouldmaintainits
defaultvalue.
HDMI1_EQ DefinestheintensityforHDMI1input
HDMI2_EQ DefinestheintensityforHDMI2input
4-18
4. Troubleshooting
4-14-5. White Balance Data Backup
WhenthemainboardorDMDboardneedstobereplaced,backupthewhitebalancedatasavedintheEEPROMofthe
mainboardtotheEEPROMoftheDMDboardbeforereplacingthemainboard,andthencopytherelevantdatafromthe
DMDboardtothemainboardsothatthecurrentwhitebalancedatacanbemaintained.Thewhitebalancecanbenewly
adjustedduringafter-salesservice(CCAadjustment).
-DMDtoMain
-MaintoDMD
WhiteBalancedata:ColorWheelIndexDelayvalue.ColorTempvalue.
4-14-6. Auto Color
Compensatesfordeviationsoftheinputsignalsonthedigitalboard.
AutoColorComponent/PC
-CompensatesfordeviationsoftheComponent/PCinputsignalsontheMainboard.
- erformthisfunctionafterinputtinga1280x720@60HzsignalintotheComponent/PCInputandtheDLPAutocolor
P
gainpatternastheinputpattern.
DLPAUTOCOLORGAINPATTERN
AutoColorAV
-CompensatesfordeviationsoftheAVinputsignalsontheMainBoard.
-nputsNTSCsignalstotheAVinputandactivatesapatternafterinputtingDLPAYTOGAINPATTERN.
I
DLPAUTOCOLORGAINPATTERN
4-19
4. Troubleshooting
4-14-7. Color Wheel Index Adjustment
-Compensatesforthereferencepointoftherotatingcolorwheel.Ifdistorted,colorisdistortedforallinputsignals.
-nputa720PsignalintotheHDMIinputandthe16,32,or64stepgrayrampasthepatternsothatachangeof
I
brightnessisnaturalandsmooth.
-ItisgoodpracticetoadjustusingRedandthenchecktheGreen,Blue,andGraypatterns.
64stepGrayRamppattern
4-14-8. CCA
CCA(ON/OFF)
-SelectswhethertoapplythewhitebalanceadjustedusingtheCCA.
-ON:AppliestheCCA
-OFF:CCAisnotapplied.
ColorStandard
-Definesthestandardstobeusedintheusermenu.
-SMPTE-C:Thecolorcoordinatestandardforanalogsignals.
-EBU:ThecolorcoordinatestandardforD-TVsignalsusedinEurope.
-HD:ThecolorcoordinatestandardforD-TVsignalsusedintheUSA.
BrightnessandColorCoordinatesforPrimaryColors
- easureandinputthebrightnessandcolorcoordinatevaluesforRed,Green,Blue,andWhiteofthetestpatterninthe
M
usermenu.
-Themeasurementshouldbeperformedinadarkroomwithnooutsidelight.
-UseameasurementinstrumentsuchasaCL-200(illuminometer)orCS-1000(luminancemeter),etc.
-Measurethecenterofthescreenwithameasurementdistanceofabout1.5to2mandascreensizeof40".
- nterthemeasuredvaluesandthenmeasurethecolorcoordinatesof6500KWhiteintheusermenu.Themeasured
E
colorcoordinatesaregoodiftheyarewithinx:0.313 ◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
