Image preview - the first page of the document
>> Download ASC20110411001 Revision 1-12-12 documenatation <<
Text preview - extract from the document
SERVICE BULLETIN
PRODUCT: Refrigerator
BULLETIN NUMBER: ASC20110411001
BULLETIN DATE: REVISED 1/12/2012
ELECTRONICS
RF series French Door
Models: RF2***, RFG2**
Background: New Refrigerator Door Handles
Beginning with February 2011 production the door handles and mounting hardware
have changed on the models listed above. Refrigerators will be shipped with the
handles inside the fridge, not attached. Models manufactured before February 2011
will have the older style handles and mounting hardware. The old style and the new
style handles are NOT interchangeable.
New style mounting hardware
DA61-03734A
New Handle design
Color Part Old Style Part Number New Style Part Number
Name
Handle DA64-02568A DA97-11081C
Real REF
Stainless Handle DA64-02550A DA97-11515C
FRE
Handle DA97-10686C DA97-11081C
Platinum REF
Handle DA97-11104C DA97-11515C
FRE
Handle DA97-10686A DA97-11081B
Black REF
Handle DA97-11104A DA97-11515A
FRE
Handle DA97-10686B DA97-11081A
White REF
Handle DA97-11104B DA97-11515B
FRE
Note: Consult the Samsung Service Website at (http://.service.samsungportal.com) for the Service Manual
and other information on this product.
This information is published for experienced repair technicians only and is not intended for use by the public. It does not contain
warnings to advise non-technical individuals of possible dangers in attempting to service a product. Only experienced professional
technicians should repair products powered by electricity. Any attempt to service or repair the product or products dealt with in this
information by anyone else could result in serious injury or death. Information provided in this bulletin is subject to change or update
without notice.
