Image preview - the first page of the document
>> Download ASC20110829001 documenatation <<
Text preview - extract from the document
SERVICE Bulletin
PRODUCT: Refrigerator
Bulletin DATE: 8/29/2011
Service Bulletin Number ASC20110829001
ELECTRONICS
Models-RF263AEPN/XAA ,RF263AERS/XAA,
RF266AEPN/XAA, RF266AERS/XAA,
RF267AEPN/XAA, RF267AERS/XAA,
RF268ACPN/XAA, RF268ACRS/XAA,
RF26XAEPN/XAA, RF26XAERS/XAA,
RF4287HAPN/XAA, RF4287HARS/XAA,
RF4289HARS/XAA,
Issue Parts Change
Detail To reduce damages during installation and delivery, the handle design has been
changed from snap in type to a secure mount using a set screw. The new parts
are NOT compatible with the old parts. Please refer to the serial number
information to ensure the proper parts are ordered.
Old style New Style
Model Cap handle Cap handle Cap handle Cap handle Change
FRE L FRE R FRE L FRE R date
RF263AEPN/XAA
RF263AERS/XAA,
RF266AEPN/XAA,
RF266AERS/XAA,
RF267AEPN/XAA, DA67- May
DA67-02485A DA97-11891A DA97-11895A
RF267AERS/XAA, 02483A 2011
RF268ACPN/XAA,
RF268ACRS/XAA,
RF26XAEPN/XAA,
RF26XAERS/XAA
RF4287HARS/XAA
DA67- February
RF4289HARS/XAA DA67-02513A DA67-02785A DA67-02784A
02512A 2011
RF4287HAPN/XAA
Detail
This information is published for informational purposes only and intended for use only by personnel qualified for the specific tasks
depicted. Qualified personnel are those who, based on their training and experience, are capable of identifying risks and avoiding
potential hazards when handling or servicing a product. Only qualified personnel should repair products powered by electricity. Any
attempt to handle, service or repair the product or products by anyone other than qualified personnel could result in serious injury or
death. You agree that your use of and reliance on this information is at your sole risk. This information is subject to change or update
without notice. There are no warranties, either expressed or implied, regarding the accuracy or completeness of this information.".
Note: Consult the Samsung Service Website at (http://.service.samsungportal.com) for the Service Manual
and other information on this product.
