Image preview - the first page of the document
ASC20111201001


>> Download ASC20111201001 documenatation <<

Text preview - extract from the document
                                                                           PRODUCT:                              SBS Refrigerator
                                                                         Bulletin Number:                        ASC20111201001
                                 ELECTRONICS                             BULLETIN DATE:                            12/01/2011
                                                                         Models:
                                                                         RS263TDBP/XAA                         RS265TDRS/XAA
                                                                         RS263TDPN/XAA                         RS265TDWP/XAA
                                                                         RS263TDRS/XAA                         RS267TDBP/XAA
SUBJECT: COMPRESSOR AND RELATED                                          RS263TDWP/XAA                         RS267TDPN/XAA
PARTS CHANGES IN NEW PRODUCTION                                          RS265TDBP/XAA                         RS267TDRS/XAA
SBS REFRIGERATOR MODELS                                                  RS265TDPN/XAA                         RS267TDWP/XAA

BACKGROUND:
Compressors for the models RS263TD**, RS265TD**, and RS267TD** contained copper
wiring.

SOLUTION:
New compressors used in production beginning October 2011 contain Aluminum wiring.
The purpose of the change is to increase efficiency and to reduce energy consumption.
All production units will have a new compressor, a new Inverter, and a new EMI Filter.

Note: For a No-Cool condition only, an old style Compressor may be substituted for
a new style if the new style is not available. However, the Inverter and EMI Filter
must also be replaced with old style parts.

All production units will have a new compressor, a new inverter, and a new EMI
filter.

Parts Information
Material                           Parts used Pre-October 2011                                             Parts used
                                                                                                        beginning October
                                                                                                              2011
SxS              Part Name                                              Original Part                  New Part Number
compres                                                                 Number
sors             Compressor                                             BK190CL2C/SM2 MKV190CL2J/SM1
                                                                        (Cu-wire)     (Al-wire)


                 Inverter PBA                                           DA92-00047A                    DA92-00111B



                 Coil Filter EMI                                        DA27-00019D                    DA27-00019L




 Note: Consult the Samsung Service Website at (http://.service.samsungportal.com) for the Service Manual
                                 and other information on this product.
  This information is published for informational purposes only and intended for use only by personnel qualified for the specific tasks
   depicted. Qualified personnel are those who, based on their training and experience, are capable of identifying risks and avoiding
  potential hazards when handling or servicing a product. Only qualified personnel should repair products powered by electricity. Any
 attempt to handle, service or repair the product or products by anyone other than qualified personnel could result in serious injury or
 death. You agree that your use of and reliance on this information is at your sole risk. This information is subject to change or update
  without notice. There are no warranties, either expressed or implied, regarding the accuracy or completeness of this information.".
