3-1. Exploded view
32
cT3362v (BUYER : ANTARES, MABUHAY) : CKD MODEL
The items with "*'are usually out of stock since they are seldom required for the routine service.There may be some anticipated delaywhen you
order these items. l = S.NA e SERVICE NOT AVAILABLE. -
1 l 3Y90-33620-120 ASSY-CABINET,FRONT CT3362'//5ANMCX ANTARES 1
"3Y90-33620490 ASSY-CABINET.FRONT HIPSHBBLKfl66 MABUHAY 1
36001-715-152 CABINET-FRONT HlPSHBBLKfl66 ANTARES 1
36001-715-122 CABINET-FRONT HlPSHBBLKR066 MABUHAY 1
2 36463-102-110 BOSS-CABINET HIPSHBNATURAL 2
3 37712-120-220 GRILLE-WOOFER SECCT0.53R#O66 2
4 37643-171-710 DOOR-CONTROL HlPSHBBLK#O66 ANTARES 1
34013-0132-020 DOOR-CONTROL HlPSHBBLK#O66 MABUHAY 1
5 34043-0001-020 INLAY-CONTROL PSSHEETT0.3BLK 1
6 34533-0051-010 BADGE-BRAND ALFORGING
7 36698-100-110 CATCH-F'USH,DOOR KIFUCO.LA701
8 34073-0057-000 WINDOW-REMOTE PC3362VlOLET
9 37622-105-710 KNOB-VOL/CH,TACT ABSHBBLK
10 37148-530-101 SCREW-TAP,RH(KNOtCFj 2S3XlOFEFZY
11 36023-118-810 STOPPER-f'CB HIF'SHBNTR 1
12 34209-200-020 SPEAKER-GENERAL 05F14BRA.8R.3W ANTARES 2
34209-l 69-l 40 SPEAKER-GENERAL 5902BR,8R,2W MABUHAY 2
13 36635-001-910 CLAMPER-D,COIL NYLON6.6DAOH-460 2
14 37124-100-830 SCREW-CRT RH 5X35FEFZY ANTARES 4
37124-100-820 SCREW-CRT 5X40FEFZY MABUHAY 4
15 3201 g-400-083 CRT-COLOR A34KQV42X 1
16 A3047-0013 SOCKET--CRT ISMSOlS F114.3
17 33309-0020-000 SPACER-DY NEOPLENEVOBLKW12MM
18 36001-716-013 CABINET-BACK HIPSHBBLK
19 A1262-0002 ANTENNA-ROD.VHF 4SN/ULDlPOLE820MMBRN
20 37148-540-153 SCREW-TAP,RH(CBtCF) 2S4X15FEFZB
21 32199-411-002 MODULE-REMOCON SR-5CP 1
22 A1292-0040 TUNER TECC1880PAO9C(S)181CH 1
23 l 3H82-00530YOOl ASSY-H/S,VERT(HORI)(Q402) 2SD1711YD ANTARES 1
"3Y82-70059-010 ASSY-H/S,VERT(HORI)(tl402) 2SD1711YD MABUHAY 1
24 33609-101-025 SWITCH-TACT(SW902) KPT-2104-21 1
25 32859-153-410 TRANS-FLYBACK FCK-1415EL 1
26 33598-001-001 SWITCH-RUBBER(SW02) JTR-1104 1
27 32306-101-020 LED-GUIOE,ASSY OL-G2RA 1
28 33609-101-011 SWITCH-TACT(SW901) Km-1112 1
29 l 3H83-00780YOOO ASSY-H/S,POWER(Q801) STR50103A.LF501 ANTARES 1
"3Y83-70029-010 ASSY-H/S,F'CIWER(Q801) STR50103A,LF501 MABUHAY 1
30 l 3H82-00530YOOO ASSY-H/S,VERT(IQOl) KA2131 ANTARES 1
"3Y82-70058-010 ASSY-H/S,VERT(IQOl) KA2131 MABUHAY 1
31 *3X30-02481-080 ASSY-PWB,MAIN CT-3362WlANMCX ANTARES 1
"3X30-02481YO60 ASSY-PWB,MAIN CT-3362VflMACX MABUHAY 1
36029-0146-000 PWB-MAIN CKC5OZ S.N.A
32 37148-530-101 SCREW-TAP,RH (SPKtCF) 2S-3XlOFEFZY 8
33
3-3. Exploded view
Cl-5062V (BUYER : ANTARES, MABUHAY) : CKD MODEL
The items with "*' are usually out of stock since they are seldom required for the routine service. There may be some anticipated delay when You
order these items. - S.N.A = SERVICE NOT AVAILABLE. -
Na. CoihNa. / Diescripfion spacificofion Ronlarks WTY
1 l 3Y90-50620230 ASSY-CABINET,FRONT HlPSH88LK#'O66 ANTARES 1
l 3Y90-50620-100 ASSY-CABINET,FRONT HIPS H8 8LK#O66 YABUHAY 1
36001-697-042 CABINET-FRONT HIPS HB 8LK#O66 ANTARES 1
36001-697-102 CABINET-FRONT HlPSHBBLK#O66 MABUHAY 1
2 36463-102-110 BOSS-CABINET HIPSHBNATURAL
3 37712-118-620 GRILLE-WOOFER SECCT0.53RX066
4 37643-171-020 DOOR-CONTROL HlPSHBBLKkr066 ANTARES
34043-0002-010 DOOR-CONTROL HIPS H8 BLKd066 MABUHAY
5 34013-0130-020 INLAY-CONTROL PSSHEETT0.3BLK
6 34533-0052-010 BADGE-BRAND ALFORGING T1.7
7 36698-lOO-110. CATCH-PUSHDOOR KIFUCO.lA701
8 34073-0055-000 WINDOW-REMOCON PCGE21051CT-5062
9 37622-105-510 KNOB-VOL/CH.TACT ABSHBBLK
10 37148-530-101 SCREW-TAP,RH(KNOtCF) 2S-3X10 FEFZY 3
11 36023-118-810 STOPPER-PCB HIPSHBNTR 1
12 A1300-0033 SPEAKER-GENERAL 5902BR8R2W ANTARES 2
34209-169-140 SPEAKER-GENERAL 59028R8R2W MABUHAY 2
13 36635-112-110 CLAMPEFI-D,COIL NYLON6.6DADH-460 4
14 37124-100-820 SCREW-CRT(CRTtCF) I RH 5X40FEFZY 4
15 32019-255-113 CRT-COLOR A4BKRD82Xj51GGB95X
16 A3047-0010 SOCKET-CRT ISHSOSC P125.5
17 33309-0020-000 SPACER-DY NEOPLENEVOBLKW12MM 4
18 36001-698-014 CABINET-BACK HlPSVOBLK5062
19 A1262-0003 ANTENNA-ROD 4s NAJLDlPOLE620MM
20 37148-540-153 SCREW-TAP,RH(CBtCF) 2S-4X15FEFZB 6
21 32196-411-002 MODULE-REMOCON SR-5CP
22 A1292-0040 TUNER TECC1880PAO9C(S) 1
23 "3H82-00530602 ASSY-H/S,VERT(HORl)(Q402) KSD5072YO ANTARES 1
*3Y82-70060-010 ASSY-H/S,VERT(HORl)(Q402) KSD5072YD YABUHAY 1
24 33606-101-025 SWITCH-TACT(SW902) KF'T-2104-21 ST ANTARES 1
33609-101-025 SWITCH-TACT(SW902) KPT-2104-21 MABUHAY 1
25 32859-200-040 TRANS-FLYBACK FCM-20A025
26 33598-001-001 SWITCH-RUBBER(SW02) JTR-1104ST
27 32306-101-020 LED-GUIDE,ASSY DL-G2RA
28 33609-101-011 SWITCH-TACT(SW901) Km-1112
29 *3H83-00780YOOO ASSY-H/S,POWER(Q801) STR50103A ANTARES
l 3Y83-70029-010 ASSY-H/S,POWER(Q801) STR50103A MABUHAY
30 l3H82-00360YOOO ASSY-H/S,VERT(IC301) KA2131ST ANTARES
l 3Y82-70058-010 ASSY-H/S,VERT(IC301) KA2131 ST MABUHAY
31 *3X30-0248OYO20 ASSY-F'WB.MAIN ZZO/;TECNISOX ANTARES 1
"3X30-0248OY120 ASSY-F`WB,MAIN CT-5052WlMACX MABUHAY 1
36029-0146-000 PWB-MAIN CKC5OZ S.N.A
32 37148-530-101 SCREW-TAP,RH(SPKtCF) 2S3XlOFEFZY 8
