Image preview - the first page of the document
>> Download 07_Exploded View & Part List documenatation <<
Text preview - extract from the document
Exploded View & Parts List
6. Exploded View & Parts List
6-1 WS32W6
No Code No Description Specification Q'ty Remark
1 HA64-300074 CABINET-FRONT ;-,32W8,HIPS,HB,SV907P 1
1-1 HA64-00002A CABINET-MASK ;32W8,HIPS,HB,-DB-004P,PLANO 1
HA64-00913B CABINET-MASK ;32W8,HIPS,HB,LIGHT-GRAY 1
1-2 AA64-01062A BADGE-BRAND ;AL FORGING,FLAT SAMSUNG PI1.5, 1
1-3 HA64-00915B WINDOW-REMOCON ;32W8,PC,-,-,-,-VIOLET,- 1
1-4 HA64-00914B KNOB-POWER ;32W8,SV-907P,ABS,HB,BLK 1
1-5 AA61-60003T SPRING-CS ;-,SUS304,0.5,OD7,H13.5,N5,-,-, 1
1-6 HA64-00916B INDICATOR-LED ;32W8,ACRYL,-,CLR,-,-,-, 1
1-7 HA60-020003 SCREW-TAPPING ;RH,+,2,M4,L15,ZPC(BLK),SWRCH18 1
2 HA94-500028 ASSY-CRT ;W76ERF031X013,PHILIPS,FLAT 1
2-1 AA65-30113A CLAMP-D,COIL ;NYLON 66,V2,BLK,TVI 25~29,-,- 4
2-2 AA60-10050V SCREW-ASSY ;WC,HH,+,M6,L30,SWRCH18A,ZPC(S 4
2-3 3704-001032 SOCKET-CRT ;8P,29PI,35.5PI,AU30U 1
3 AA91-00150B ASSY-HOLDER,SPK ;DP,-,8OHM/15W,-,AA91-00150A DP 1
3-1 AA60-10050V SCREW-ASSY ;WC,HH,+,M6,L30,SWRCH18A,ZPC(S 4
4 HA64-00912B CABINET-BACK ;,32W8,HIPS,NH,GRY 1
4-1 6003-001025 SCREW-TAPTITE ;RH,M4,L20,BLK 8
4-2 AA96-00094A ASSY-POWER,CORD ;DP,CP2/NO(4.0),H/C350MM,KJP140 1
Samsung Electronics 6-1
