Image preview - the first page of the document
>> Download Exploded View & Part List documenatation <<
Text preview - extract from the document
Exploded View & Part List
5. ExplodedView&PartList
5-1 CS29B850F18XSVExplodedView
29BF0
M0006
M0014
T0063
T0569
T0156
olor Television
T0175
T0022
T0003
T0299
T0091
M0112
CIS7
T0066
T0023
5-1 Samsung Electronics
Exploded View & Part List
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
CIS7 AA61-60003J SPRING ETC-CS SUS304,OD6,N7,OD6 1 S.N.A
M0006 AA63-01622D COVER-REAR 29Z57(CIS,TSE),HIPS,HB,BK500, 1 S.A
M0014 AA94-16773B ASSY PCB MAIN CS29Z50M18XSHI,KSDB 1 S.A
M0112 AA63-01621S COVER-FRONT 29Z57,ABS+PMMA,HB,BK23,KSDB, 1 S.N.A
T0003 AA96-04912X ASSY COVER P-FRONT 29Z57,ABS+PMMA,HB,BK2 1 S.A
T0022 AA64-04460A KNOB CONTROL 29Z57,ABS,PC,BK25,H/GLOSSY 1 S.N.A
T0023 AA64-04467A KNOB POWER 29Z57,ABS,PMMA,HB,BK23,PAK, H 1 S.N.A
T0054 AA64-04462A KNOB-DECORATION 29Z57,ABS,HB,IV-16,AL 1 S.N.A
T0063 AA03-00598A CRT COLOR A68QGU820X 59,0mG,0.99,12.0,1. 1 S.A
T0066 AA96-20109A ASSY POWER CORD -,CP2/NO(4.0),H/C400,KKP 1 S.A
T0091 AA94-16572C ASSY PCB MISC-A/V XSV,KSDA 1 S.N.A
T0098 AA94-16571C ASSY PCB MISC-CONTROL 29Z50,URANUS,KSDA 1 S.A
T0156 AA61-01389A HOLDER-RAIL HIPS,V0,GRAY,NON-DECA 2 S.N.A
T0175 AA96-04414A ASSY SPEAKER P 8ohm,10W,L:YELLOW/BLAVK60 1 S.A
T0299 AA64-04468A WINDOW-RMC LED 29Z57,PC,CLEAR,PAL 1 S.N.A
T0569 AA61-01466A SUPPORT-CRT 29Z40,HIPS,V0,BLK,NON-DECA 2 S.N.A
Samsung Electronics 5-2
Exploded View & Part List
5-2 CS29B850F18XSVElectricalPartList
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
ASSYCHASSIS
M0017 AA91-11648A ASSY CHASSIS CS29B850F18XSV,KSDB 1 S.N.A
AA02-00012A TAPE ETC-RIBBON 54CM,250MT 0.02 S.N.A
M0014 AA94-16773A ASSY PCB MAIN CS29B850F18XSV,KSDB 1 S.A
C 2401-003391 C-AL 220uF,20%,450V,GP,BK,25x50,10 1 S.A
CB406 2301-001192 C-FILM,LEAD-PPF 820nF,5%,400V,BK,29x18.5 1 S.A
CIS 6003-000334 SCREW-TAPTYPE RH,+,-,2S,M3,L6,ZPC(WHT),S 1 S.N.A
CIS3 AA40-00025A TUNER-F/S TDQ-6F/125S,PAL,181CH,38.9MHZ, 1 S.A
CN330 3711-002647 HEADER-BOARD TO CABLE BOX,8P,1R,2.5mm,ST 1 S.A
CN330 3711-003043 HEADER-BOARD TO CABLE BOX,4P,1R,2.5MM,ST 1 S.A
CR402S 2301-001041 C-FILM,LEAD-PPF 15nF,5%,1.6KV,TP,29x14x2 1 S.A
CR406S 2306-000235 C-FILM,LEAD-PPF 560nF,5%,400V,BK,26x22.5 1 S.A
CX801S 2301-001220 C-FILM,LEAD-PPF 100nF,10%,275V,BK,18x6x1 1 S.A
CY802S 2201-000446 C-CERAMIC,DISC 3.3NF,20%,400V,Y5U,BK,15X 1 S.A
D404 0402-001599 DIODE-RECTIFIER DGP30L,1500,3A,DO-201AD( 1 S.A
D408 0402-001295 DIODE-RECTIFIER GUR460L-5700,600V,4A,DO- 1 S.A
D801S 0402-001477 DIODE-BRIDGE GSIB460,600V,4A,SIP-4,ST 1 S.A
D807 0402-001604 DIODE-RECTIFIER MUR420,200V,4A,DO-201AD, 1 S.A
D809A 0402-001604 DIODE-RECTIFIER MUR420,200V,4A,DO-201AD, 1 S.A
D811 0402-001603 DIODE-RECTIFIER MUR480E,800V,4A,DO-201AD 1 S.A
D813A 0402-001604 DIODE-RECTIFIER MUR420,200V,4A,DO-201AD, 1 S.A
FD802 3601-000414 FUSE-CARTRIDGE 250V,5A,SLOW-BLOW,GLASS,5 1 S.N.A
GT301 AA60-40012F PIN-GT 4P,2.36PI,6/12/14mm,NYLON66,LOCKI 1 S.N.A
GT801 AA60-40012G PIN-GT 3P,2.36PI,10/5mm,NYLON66,LOCKING 1 S.N.A
GT811 AA60-40012B PIN-GT,ASSY T1.6,10MM,NYLON66 1 S.N.A
H/S 6003-000335 SCREW-TAPTYPE RH,+,2S,M3,L8,ZPC(WHT),SWR 1 S.N.A
H/S AA61-01390A BRACKET CT-29A20HR,SECC,T1.0 1 S.N.A
IC063 AA13-00127A IC HYBRID STR-W6754F,CS29Z57,7,-20~115,T 1 S.A
IC112 1103-001213 IC-EEPROM 24C16,2Kx8,DIP,8P,9.2x6mm,2.5/ 1 S.A
IC301 AA96-00623F ASSY HEAT SINK P -,L,SCRE,AA62-00056,-,- 1 S.N.A
IC501 AA96-50311Q ASSY HEAT SINK P AA62-30175D,6003-000334 1 S.N.A
IC602 AA96-50398E ASSY HEAT SINK P TDA7297SA,-,-,AA62-3018 1 S.N.A
IC801S AA96-05571A ASSY HEAT SINK P AA62-30181V,6003-000333 1 S.N.A
JA333 3722-001596 JACK-PIN 3P/9P,NI,BLK(GRN/BLU/RED),ANGLE 1 S.A
JA333 3722-002593 JACK-PIN 9P,Ni,YEL/WHT/RED,ANGLE 1 S.A
LX801S AA29-00021A FILTER LINE NOISE SQE2222,18mH,0.25ohm,1 1 S.A
M0014 AA97-17939A ASSY AUTO-MAIN CS29B850F18XSV,KSDB 1 S.N.A
M0018 AA97-17882A ASSY MICOM T-UR2PMAS-1002.0,KSDB,TDA1212 1 S.N.A
P803T 1404-001264 THERMISTOR-PTC 4.5ohm,+30/-20%,220V,290V 1 S.A
PC801S 0604-001032 PHOTO-COUPLER TR,170-260%,300mW,DIP-4,ST 1 S.A
Q401 AA96-03778D ASSY HEAT SINK P AA62-00145A,6003-000333 1 S.N.A
Q404 AA96-00624R ASSY HEAT SINK P AA62-00057B,6003-000334 1 S.N.A
Q409 0505-001288 FET-SILICON KHB9D5N20P,N,200V,9.5A,0.4oh 1 S.A
Q804 AA96-05075C ASSY HEAT SINK P AA62-00045D,6003-000334 1 S.N.A
RL801S 3501-001053 RELAY-POWER 5Vdc,530mW,10000mA,1FormA,15 1 S.A
RM901 AA32-00015A Module Remocon 5 1 S.A
SF101S 2904-001143 FILTER-SAW AV 38.9MHz,SIP5K,ST,18.1dB,42 1 S.A
SF102S 2904-001195 FILTER-SAW AV 38.9MHz,SIP5K,ST,17.9dB 1 S.A
T0010 AA27-00308B COIL CHOKE 3mH,10%,1.8ohm,0.7,14X20 C6.0 1 S.A
T0010 AA27-00420A COIL CHOKE DR 14 x 20 (C:8.5),SHREK2,600 1 S.A
T0010 AA27-00425A COIL CHOKE DR 10 x 12 (C:6.0),I ROBOT2,2 1 S.A
T0066 AA62-30181V HEAT SINK-ES CT-29M16V,AL6063,T2.0,64,40 1 S.N.A
T0066 AA62-30182E HEAT SINK-ES A6063 EXTR 1 S.N.A
T0074 1201-002491 IC-VIDEO AMP TDA6107AJF/N1B,ZSIP,9P,21.6 1 S.A
T0085 1201-002118 IC-AUDIO AMP TDA7297SA,ZIP,15P,DUAL,32dB 1 S.A
T0087 1203-002018 IC-POSI.FIXED REG. 78R05,TO-220,4P,10MIL 1 S.A
T0087 1203-001944 IC-POSI.FIXED REG. 78RM33,TO-220,3P,PLAS 1 S.A
T0088 1204-002183 IC-VERTICAL PROCESSO LA78045,TO220,7P,15 1 S.A
T0098 AA96-30001C ASSY PCB P AA61-50055A,DL-G7RA 1 S.N.A
T0098 AA62-00057B HEAT SINK CT-29K12P,A1050S,1.0,41,60,WHI 1 S.N.A
T0098 AA62-00145C HEAT SINK A1050,T1.0,23,50,WHITE,TSE 1 S.N.A
T0105 AA60-30001A WASHER-PLATE M3,ID3.5,15X8.5,T1.0,SBHG 1 S.N.A
T0119 AA09-00563A IC MICOM TDA12120H/N300,80Pin,3.3/5/8V,2 1 S.N.A
5-3 Samsung Electronics
Exploded View & Part List
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
T0175 AA62-00056A HEAT SINK-PS D2,AL,T1.0,41*35*70 1 S.N.A
T0175 AA62-00045D HEAT SINK-PS EVOLUTION,AL,T1.0,20*20*35, 1 S.N.A
T0175 AA62-30175D HEAT SINK-PS SECC,T1.0,33X15X30 FT-2 1 S.N.A
T0245 0202-001608 SOLDER-WIRE FLUX LFC7-107,D0.8,99.3Sn/0. 0.025 S.N.A
T0245 AA39-20010D LEAD CONNECTOR-ASSY ,1P,400,YFH800-01,S, 1 S.A
T0245 AA39-20620C LEAD CONNECTOR-ASSY ,9P,500MM,YBNH250-09 1 S.A
T0296 AA27-00035D COIL LINEARITY 24,6,DR15X18,11.0,15,BK,1 1 S.A
T0313 3404-001004 SWITCH-TACT 12V,50mA,160gf,8.4x22.7mm,SP 1 S.A
T0510 AA97-17940A ASSY SMD-MAIN CS29B850F18XSV,KSDB 1 S.N.A
T0522 0205-001153 GREASE-SILICON SC102,JAPAN,- 0.1 S.N.A
T0522 0205-001153 GREASE-SILICON SC102,JAPAN,- 0.2 S.N.A
T0522 0205-001153 GREASE-SILICON SC102,JAPAN,- 0.1 S.N.A
T0522 0205-001153 GREASE-SILICON SC102,JAPAN,- 0.09 S.N.A
T0522 0205-001153 GREASE-SILICON SC102,JAPAN,- 0.2 S.N.A
T0522 0205-001153 GREASE-SILICON SC102,JAPAN,- 0.2 S.N.A
T0900 1404-001045 THERMISTOR-NTC 4.7ohm,4.565A,2900K,0mW/C 1 S.A
T401 AA26-50001M TRANS-H.DRIVE 80mH,520uH,EI19 1 S.A
T444 AA26-00321A TRANS FBT BSC29-0166E,URANUS,3.48mH,KV2, 1 S.A
T801S AA26-00228D TRANS SWITCHING 42B135-**,CORE,80V~280V, 1 S.A
V999S 3704-001197 SOCKET-CRT 8P+SEN,29PI,22.5PI,NI+SN 1 S.A
XD201 2801-003316 CRYSTAL-UNIT 24.576MHz,30ppm,28-AAM,20pF 1 S.A
6003-000334 SCREW-TAPTYPE RH,+,-,2S,M3,L6,ZPC(WHT),S 1 S.N.A
6003-000333 SCREW-TAPTYPE RH,+,-,2S,M3,L10,ZPC(WHT), 1 S.N.A
6003-000334 SCREW-TAPTYPE RH,+,-,2S,M3,L6,ZPC(WHT),S 1 S.N.A
6003-000334 SCREW-TAPTYPE RH,+,-,2S,M3,L6,ZPC(WHT),S 1 S.N.A
0502-001292 TR-POWER TT2206-YD,NPN,65000mW,TO-3PML,S 1 S.A
6003-000333 SCREW-TAPTYPE RH,+,-,2S,M3,L10,ZPC(WHT), 1 S.N.A
ASSYCPT
T0521 AA91-11650A ASSY CPT A68QGX793X701,0MG,KSDB 1 S.N.A
T0063 AA03-00589A CRT COLOR A68QGX793X601 M,0mG,0.985,1.85 1 S.A
T0089 AA27-00359A COIL DEGAUSSING CORSET,9.45mH,130Turns,4 1 S.A
T0527 AA65-00056A CLAMPER CORE-WIRE 32Z30,NYLON-66,V0,NTR 4 S.N.A
T0603 AA96-04062A ASSY TBC WIRE P K64A,29,NTSC,2P 1 S.N.A
ASSYBOX
M0003 AA92-12768G ASSY BOX CS29B850F18XSV 1 S.N.A
AA02-00013A TAPE ETC-RIBBON 101CM,250MT 0.28 S.N.A
AA69-04635E BOX-SET 29BF0,CB,DW,A1,YEL,W827,D459,H63 1 S.N.A
ASSYP/MATERIAL
M0113 AA92-12770A ASSY P/MATERIAL 29BF0 1 S.A
T0214 AA60-40006A PIN-STAPLE AUTO,33X17.8X2.4,H18,33X17.8X 12 S.N.A
T0524 6902-000005 BAG PE HDPE/NITRON/HDPE,T0.015/T0.5/T0.0 1 S.N.A
ASSYLABEL
M0019 AA92-12880A ASSY LABEL CS29B850F18XSV,KSDB 1 S.N.A
AA02-00012A TAPE ETC-RIBBON 54CM,250MT 0.03 S.N.A
AA02-00015A TAPE ETC-RIBBON 64CM,250MT 0.12 S.N.A
ASSYACCESSORY
M0045 AA92-12881A ASSY ACCESSORY CS29B850F18XSV,KSDB 1 S.N.A
T0524 6902-000009 BAG PE HDPE,T0.03,W240,L400,TRP,8,2,-,5. 1 S.N.A
AA02-00012A TAPE ETC-RIBBON 54CM,250MT 0.02 S.N.A
AA68-03242M MANUAL FLYER-MANUAL FLYER-06,S comm,Sams 1 S.N.A
AA68-03777A MANUAL USERS-CARD,09 comm,Samsung,Englis 1 S.N.A
Samsung Electronics 5-4
Exploded View & Part List
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
M0284 AA68-03973B MANUAL USERS-02 COMM,SAMSUNG,ENG,E.ASIA, 1 S.N.A
M0284 AA68-03973M MANUAL USERS-02 COMM,SAMSUNG,Arabic,M.E. 1 S.N.A
M0156 AA68-03973N MANUAL USERS-01 COMM,SAMSUNG,French,M.E. 1 S.N.A
T0074 BN59-00890A REMOCON CRT,TM930,SAMSUNG,20PIN,CIS,68g 1 S.A
ASSYCOVERFRONT
M0001 AA90-06002F ASSY COVER FRONT CS29B850F18XSV 1 S.N.A
T0081 6002-000514 SCREW-TAPPING RH,+,2,M4,L15,ZPC(BLK),SWR 7 S.A
T0081 6002-000514 SCREW-TAPPING RH,+,2,M4,L15,ZPC(BLK),SWR 2 S.A
T0238 AA60-10050V BOLT-HEX M6,L30,ZPC(S/BLU),WC 4 S.N.A
T0003 AA96-05594F ASSY COVER P-FRONT 29BF0,ABS+PMMA,HB,KSD 1 S.A
AV+CF 6003-001268 SCREW-TAPTYPE TH,+,B,M4,L12,ZPC(WHT),SWR 1 S.N.A
H/CRT+CF 6003-001268 SCREW-TAPTYPE TH,+,B,M4,L12,ZPC(WHT),SWR 20 S.N.A
KC+CF 6003-001268 SCREW-TAPTYPE TH,+,B,M4,L12,ZPC(WHT),SWR 1 S.N.A
PANNEL+CF 6003-001268 SCREW-TAPTYPE TH,+,B,M4,L12,ZPC(WHT),SWR 3 S.N.A
SPK+CF 6003-001268 SCREW-TAPTYPE TH,+,B,M4,L12,ZPC(WHT),SWR 4 S.N.A
WR+CF 6003-001268 SCREW-TAPTYPE TH,+,B,M4,L12,ZPC(WHT),SWR 1 S.N.A
T0156 AA61-01389A HOLDER-RAIL HIPS,V0,GRAY,NON-DECA 2 S.N.A
AA61-01463A HOLDER-MIDDLE 29Z50(TT,SEH,TSE,SAV,SEI,S 1 S.N.A
AA61-01523A HOLDER-CRT 29BF0 (TTSEC/TSE/SAVINA/SEIN/ 1 S.N.A
AA61-01523B HOLDER-CRT 29BF0 (TTSEC/TSE/SAVINA/SEIN) 1 S.N.A
AA61-01523C HOLDER-CRT 29BF0 (TTSEC/TSE/SAVINA/SEIN) 1 S.N.A
AA61-01523D HOLDER-CRT 29BF0 (TTSEC/TSE/SAVINA/SEIN) 1 S.N.A
CIS7 AA61-60003J SPRING ETC-CS SUS304,OD6,N7,OD6 1 S.N.A
M0112 AA63-01816F COVER-FRONT 29BF0,ABS+PMMA,HB,0505H,KSDB 1 S.N.A
AA64-04619A PANEL-DECO 29BF0 (TTSEC/TSE/SAVINA/SEIN) 1 S.A
T0299 AA64-04623A WINDOW-RMC,LED 29BF0 (TTSEC/TSE/SAVINA/S 1 S.N.A
T0022 AA64-04628A KNOB-CONTROL 29BF0 (TTSEC/TSE/SAVINA/SEI 1 S.N.A
T0023 AA64-04629A KNOB-POWER 29BF0 (TTSEC/TSE/SAVINA/SEIN) 1 S.N.A
T0091 AA94-16572C ASSY PCB MISC-A/V XSV,KSDA 1 S.A
T0245 0202-001608 SOLDER-WIRE FLUX LFC7-107,D0.8,99.3Sn/0. 0.003 S.N.A
JA333 3722-001663 JACK-PIN 3P,NI,RED/WHT/YEL,STRAIGHT 1 S.A
M2893 AA39-20068J LEAD CONNECTOR ,8P,600MM,YBNH250-08,6709 1 S.A
T0557 AA97-17620C ASSY AUTO-A/V XSV,KSDA 1 S.N.A
C701 2202-000121 C-CERAMIC,MLC-AXIAL 0.1nF,10%,50V,Y5P,-, 1 S.A
C702 2202-000121 C-CERAMIC,MLC-AXIAL 0.1nF,10%,50V,Y5P,-, 1 S.A
L701 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L702 2701-000114 INDUCTOR-AXIAL 10UH,10%,2534 1 S.A
L2514 3301-000287 BEAD-AXIAL ,3.5x1.0x6.0mm,3000mA,TP,,,50 1 S.A
L2514 3301-000287 BEAD-AXIAL ,3.5x1.0x6.0mm,3000mA,TP,,,50 1 S.A
PCB AA41-01216C PCB SUB-SIDE A/V CS29Z30,FR-1,1,C,1.6,33 1 S.N.A
T0175 AA96-05501A ASSY SPEAKER P 8ohm,URANUS,29AJ0,10W,600 1 S.A
BN61-03162A BOSS-PRIMER Tulip,PRIMER(IPA),Clear,AP-1 0.002 S.N.A
CCM1 BN63-02183F COVER-SHEET Rhcm,PE Vinyl,T0.05,900mm,20 1.1 S.N.A
T0569 AA61-01503B SUPPORT-CRT 29Z58,HIPS,HB,NTR,VXD Improv 2 S.N.A
ASSYCOVERREAR
M0002 AA90-06004F ASSY COVER REAR 29BF0,HIPS,HB,KSDB,M-EAS 1 S.N.A
T0081 6002-000512 SCREW-TAPPING RH,+,2,M4,L12,ZPC(BLK),SWR 1 S.N.A
AA61-00468A HOLDER-FBT TOOL,2939,MOLD 1 S.N.A
T0070 AA61-01471A HOLDER-CHASSIS 29Z57(SEH),HIPS,V0,GR503 1 S.N.A
M0006 AA63-01817B COVER-REAR 29BF0 (TTSEC/TSE/SAVINA/SEIN) 1 S.A
T0069 AA63-60131R SPACER-FELT 21Z57,FELT,325,T0.35,7 4 S.N.A
T0578 AA64-04297R INLAY AV 29K40,T0.3,BLK,GREEN 1 S.N.A
T0066 AA64-04387D INLAY-BACK Z50,PAL,PS,SHEET,T0.3,BLACK,S 1 S.N.A
T0186 AA64-04581A INLAY CS29K40MLNXXSE,PS SHEET,0.3,BLACK, 1 S.N.A
ASSYFIXING
T0892 AA91-11324A ASSY FIXING CS29Z50MH9XXSG,KSDA 1 S.N.A
T0527 AA65-30018A CLAMPER CORE-WIRE DONG-A,NYLON-66,DATL-6 2 S.N.A
T0066 AA96-20109A ASSY POWER CORD -,CP2/NO(4.0),H/C400,KKP 1 S.A
5-5 Samsung Electronics
Exploded View & Part List
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
T0268 AA39-10006X CBF-POWER CORD KKP419C,3P,BLK,KLCE-2F,VD 1 S.A
T0010 AA61-20284A HOLDER P-CORD,PP,BLK,VO,KE-002 1 S.N.A
T0522 AA65-30008A CLAMPER CORE-CORD PE,HB,BLK 1 S.N.A
Samsung Electronics 5-6
MEMO
5-7 Samsung Electronics
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
