Image preview - the first page of the document
>> Download Product Specification documenatation <<
Text preview - extract from the document
Product Specification
2. ProductSpecification
2-1 ProductSpecification
Features
Block Specification Major IC Remark
CRT 29" Slim CRT 29" Slim CRT
RF Part 1 TUNER F/S TUNER EWT-5F6T2-EW
Power Input Voltage : S.E.Asia: 220V W6754F
MULTI SYSTEM(NT/PAL/SECAM)
Video UOC TOP 12110
2H Comb Filter
Sound Output : 10W x 2 TDA7297SA
Cabinet 29BF0 Cabinet
Specification
Model CS29B850F1
Screen Size 29"
Dimensions (WxHxD) 775 x 407 x 599 mm
Weight 36.2 kg
Voltage S.E.Asia: 220V
Speaker Output 10W + 10W
Samsung Electronics 2-1
Product Specification
2-2 SpecificationsAnalysis
: application, : non-application
Model CS29B850F1 (KSDB) CS29A730EL (KS7C)
Design
Product Type Slim CRT Slim CRT
Digital TV Analog Analog
Basic Digital Display - -
Screen Size 29 29
Aspect Ratio 4:3 4:3
Progressive Scan O O
Digital Comb Filter X X
Screen Pitch 0.73 0.73
Visual
Digital Noise Reduction X X
Quality
AKB O O
DNIe Jr O O
3:2 Pull Down Support O X
Base/Treble/Balance X O
Equalizer O X
AVL X X
Audio
Surround X X
Speaker System Direct Direct
Sperker Output 10W + 10W 10W + 10W
Dual Screen Function X X
Double Screen X X
TTX X X
Function Still Picture X X
Auto Jack Recognition X X
EPG X X
Network X X
Antenna In Rear:1 Rear:1
Extermal In Rear:1 Rear:1, Side: 1
S-Video X O
Y/Pb/Pr Rear:1 Rear:1
Ports PC X X
DVI X X
HDMI X X
Digital Audio Out X X
Video Out Rear:1 Rear:1
Remote Controller TM930 TM85
the power supply and power consumption, refer to the label attached to the product.
For
2-2 Samsung Electronics
Product Specification
2-3 Accessories
2-3-1 SuppliedAccessories
Accessories Item Item code Remark
Remote Control BN59-00890A
Batteries 4301-000121
Power Cord AA39-10006X
Samsung Service center
Owner's Instructions AA68-03973B
Warranty Card -
Registration Card -
Safety Guide Manual AA68-03242M
2-3-2 Accessoriesthatcanbepurchasedadditionally
Accessories Item Item code Remark
RF Cable -
Video Cable -
Electronics Store/
Internal shopping mall
Audio Cable -
Component Cables (RCA) -
Samsung Electronics 2-3
