Image preview - the first page of the document
>> Download Wiring Diagram documenatation <<
Text preview - extract from the document
Wiring Diagram
6. WiringDiagram
6-1 OverallWiring
Signal
Signal
Samsung Electronics 6-1
Wiring Diagram
The code number of cable(Lead-connector) can be changed, see "5. Exploded View & Part List."
Use CRT Board Main Board Power Code AV Wire
Code AA39-20620C AA96-20109D AA39-20010D
Use Speaker Wire
Code AA96-05501A(CS29B850F2)
6-2 Samsung Electronics
Wiring Diagram
6-2 PinConnection
MAIN
B-IN
CN501A G-IN
TO CRT
R-IN
GND
AKB
GND
HEATER
200V
N.C R+
CN601 R-
CN701 VO TO SPK
TO AV L+
GND L-
VI
GND
LO
RO
LI
RI
CRT
BK
GK CN501
RK
TO MAIN
GND
AKB
GND
HEA
200V
N.C
Samsung Electronics 6-3
Wiring Diagram
6-2-1 MainBoardConnectorPin
CN601 CN701
Speaker connect AV connect
Pin No. Pin Name Pin No. Pin Name
1 R+ 1 VO
2 R- 2 GND
3 L+ 3 VI
4 L- 4 GND
5 LO
6 RO
7 LI
8 RI
6-2-2 Connectorrole
Loc. No. Description
CN501 Main Board and CRT Board connect
CN501A Main Board and CRT Board connect
CN601 Main Board and Speaker connect
CN701 Main Board and Side-AV connect
6-4 Samsung Electronics
