Image preview - the first page of the document
>> Download 20030527162455718_ks3a-50-exapl documenatation <<
Text preview - extract from the document
Exploded View & Parts List
6. Exploded View & Parts List
6-1 CS34Z4HPBX/TAW
No Code No Description;Specification Q'ty Remark S.N.A
1 AA91-00764P ASSY CABINET FRONT;,34Z4 NEW,SV012P KS3A 1
1* AA64-01974H CABINET-FRONT;34Z4,HIPS,HB,G4309,SV012P 1 S.N.A
1-1 AA64-01062B BADGE-BRAND;32Z5,AL FORGING,-,-,L65,-,SI 1 S.N.A
1-2 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 2 PCB+KC
1-3 AA41-00522A PCB-CONTROL;CS32Z4,FR-1,1L,A,1.6T,245X24 1 PCB S.N.A
1-4 AA64-03209A KNOB-CONTROL;Z4,ABS,HB,WHT,SVM3012 1 S.N.A
1-5 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR 2 KC+CF S.N.A
1-6 AA64-01203B INDICATOR LED;32Z5,ACRYL,-,CLR,-,-,- 1
1-7 AA64-03210A KNOB-POWER;Z4,ABS,HB,WHT,SVM3012 1
1-8 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, 1 S.N.A
1-9 AA64-03211A WINDOW-REMOCON;Z4,PC,VIOLET 1 S.N.A
1-10 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 3 WIN+CF S.N.A
1-11 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 2 HP+PCB
1-12 AA41-00521A PCB-MASTER S/W;CS32Z4,FR-1,1L,A,1.6T,245 1 PCB S.N.A
1-13 AA61-00450B HOLDER-POWER;32Z5,ABS,-,-,-,GRAY,HB 1 S.N.A
1-14 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR 2 HP+CF S.N.A
1-15 AA91-00738A ASSY HOLDER SPK;-,PP,8OHM,10W,-,ZEUS-2 F 2
1-16 6006-001096 SCREW-ASS'Y TAPT;WP,BH,+,M4.0,L12,BLK,SW 4 S.N.A
2 AA95-01863A ASSY SUB-PCB-MASTER;WS36Z48D,KS4A,PAL,AA 1
2-1 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZPC(BLK),SWR 2 DR+CF S.N.A
3 AA91-02217A ASSY CPT;CS34A7HPBX/TAW 1 * S.N.A
3-1 AA60-10050V SCREW-ASSY;-,SWRCH18A,M6,L30,HH,+,WC,-,Z 4 CRT+CF S.N.A
3-2 AA65-30113A CLAMPER CORE-D,COIL;-,NYLON 66,V2,-,BLK, 4 S.N.A
4 AA64-01977C CABINET BACK;34Z4,HIPS,HB,G4309 1
4-1 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, 8 CB+CF S.N.A
4-2 AA63-00463A COVER-WOOFER;TOOL,34Z4,-,-,-,-,-,-,MOLD 1 S.N.A
5 AA96-20109A ASSY POWER CORD;-,CP2/NO(4.0),H/C400,KKP 1 S.N.A
Samsung Electronics 6-1
Exploded View & Parts List
6-2 WS24V53NS8XXEC
No Code No Description;Specification Q'ty Remark S.N.A
1 AA96-01296A ASSY COVER P-FRONT;24V5,HIPS HB,SILVER 1
1* AA64-03190A CABINET-FRONT24V5,HIPS,FV2,G4309,SV012P 1
1-1 AA64-70117B BADGE-BRAND;-,AL,-,-,L65,R2000,SILVER,SS 1
1-2 AA64-03192A KNOB-POWER;24V5,ABS,HB,G3676,SVM3012 1
1-3 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, 1
1-4 AA64-03194A DECORATION-POWER;24V5,ABS,HB,G3676,SVM30 1
1-5 AA95-01522A ASSY ETC-PCB A/V BOARD;,21A8,KS3A 1
1-6 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 1 CF+AV
1-7 AA65-30105A CLAMPER CORE-WIRE;ALL MODEL,NYLON 66,V2, 1
1-8 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- 1
1-9 AA64-03191A KNOB-CONTROL;24V5,ABS,HB,G3676,SVM3012 1
1-10 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 1 KC+CF
1-11 AA64-03193A WINDOW-RMC,LED;24V5,PC,CLR 1
1-12 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 1 WR+CF
1-13 AA94-12331A ASSY PCB MISC-CONTROL;24V5,KS3A,PAL 1
1-14 SCREW-TAPTITE 3
1-15 3001-001005 SPEAKER;10W,8OHM,91DB,140HZ 2
1-16 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 8 SPK+CF
1-17 HOLDER-PFC
2 AA94-07275A ASSY CRT;,W56ECK001X04,24,PHILILPS-AK 1
2-1 AA65-30107A CLAMPER CORE-D,COIL;20~22 INCH,NYLON 66, 4 CRT
2-2 AA60-10050V SCREW-ASSY;-,SWRCH18A,M6,L30,HH,+,WC,-,Z 4 CRT
2-3 3704-001105 SOCKET-CRT;11P,20PI,26.5PI,NI,- 1 V999S
3 HA64-00439A CABINET-BACK;;24W6,HIPS,HB,BLK, 1
3-1 6002-000515 SCREW-TAPPING;RH,+,2,M4,L15,ZPC(WHT),SWR 6 CF+CB
3-2 AA96-01126A ASSY POWER CORD;DP,AA39-10001G,CP2,H/C25 1
6-2 Samsung Electronics
Exploded View & Parts List
6-3 CS29K3NTB/XSE
No Code No Description;Specification Q'ty Remark S.N.A
1 AA91-00622C ASSY CABINET FRONT;DP,29K3,SV012P EPP,HI 1
1* AA64-01432C CABINET FRONT;29K3,HIPS,HB,G4309,SV012P 1 S.N.A
1-1 AA64-01506D INLAY-AV;29K3,PVC-SHEET,T0.3,-,-,P/GRAY, 1 S.N.A
1-2 AA64-70117B BADGE-BRAND;-,AL,-,-,L65,R2000,SILVER,SS 1 S.N.A
1-3 AA64-01434F KNOB POWER;29K3,ABS,HB,G3676,SVM3012 NO- 1
1-4 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, 1 S.N.A
1-5 AA95-01788S ASSY SUB-PCB,A/V SIDE;DP,29K1,KS3APAL,AA 1
1-6 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 2 AJ+CF S.N.A
1-7 AA65-30104C CLAMPER CORE-WIRE;ALL MODEL,NYLON 66,V2, 1 CLAMP S.N.A
1-8 AA61-40113A STOPPER-PCB;501H,HIPS,-,-,HB,NTR,- 1 S.N.A
1-9 AA91-00507B ASSY HOLDER SPK;DP,-,8OHM/15W,-,29K1 CKD 1
1-10 6006-001095 SCREW-ASS'Y TAPT;WP,BH,+,M4,L12,ZPC(YEL) 4 SPK+CF S.N.A
1-11 AA64-01436B INDICATOR LED;29K3,ACRYL,-,CLR,-,-,- 1
1-12 AA64-01435B WINDOW REMOCON;29K3,PC,-,-,-,V0,VIOLET,- 1
1-13 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR 1 WR+CF S.N.A
1-14 AA64-01437F KNOB CONTROL;21,29K3,ABS,HB,G3676,SVM301 1
1-15 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR 1 KC+CF S.N.A
2 AA91-05169A ASSY CPT;CS29K3NTBS/XSE,INDONESIA,KS3A 1 * S.N.A
2-1 AA65-30017A CLAMPER CORE-D,COIL;-,NYLON-66,V0,-,NTR, 2 S.N.A
2-2 AA60-10050V SCREW-ASSY;-,SWRCH18A,M6,L30,HH,+,WC,-,Z 4 S.N.A
2-3 3704-000114 SOCKET-CRT;14P,29.1,35.5,SN,ISH09S/BK 1 VA999
3 AA64-01433P CABINET BACK;29K3,HIPS,HB,G4309 1
3-1 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, 7 CB+CF S.N.A
3-2 AA64-00892F INLAY-BACK;D2,D3,PS SHEET,T0.3,-,-,BLK,R 1 S.N.A
4 AA96-20109A ASSY POWER CORD;-,CP2/NO(4.0),H/C400,KKP 1 S.N.A
Samsung Electronics 6-3
