Image preview - the first page of the document



>> Download 20061023162847421_ks7c-p-evapl-4 documenatation <<

Text preview - extract from the document

                                                                                                                                                                                                 Exploded View & Part List



4. Exploded View & Part List
4-1 CS29Z45MQTXXSE
You can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr




                                                                                                      M0006   Loc.No.    Code No.           Description                  Specification           Q'ty   SA/SNA Remark
              T0074            T0066
                                                                                                               CIS7     AA61-60003J       SPRING ETC-CS           -,SUS304,-,-,OD6,N7,OD6,-,      1     S.N.A
                                                                                                              M0006     AA63-01509C        COVER-REAR         29Z45,HIPS,HB,BK500,KS7C,50HZ       1     S.N.A
                                                                                                              M0014     AA94-16067A       ASSY PCB MAIN           CS29Z45MQTXXSE,KS7C             1      S.A
                                                                                                              M0112     AA63-01510D       COVER-FRONT          29Z45,TSE,SAVINA,SEIN,HIPS,T       1     S.N.A
                                                                                                              T0003     AA96-04358F    ASSY COVER P-FRONT          29Z45,SAVINA,SEIN,TSE          1      S.A
                                                                                                              T0022     AA64-04406A       KNOB-CONTROL         29Z45,ABS,HB,GR515,SVM3012         1     S.N.A
                                                                              T0063
                                                                                                              T0023     AA64-04404A       KNOB POWER            29Z45,ABS,HB,GR515,BKN3576        1     S.N.A
                                                                                                              T0054     AA64-04405A     KNOB-DECORATION           29Z45,ABS,HB,GR515,AL           1     S.N.A
                                             T0003                                                            T0057     AA64-01062B       BADGE-BRAND            ALL,AL,T1.5,10.6,L65,BLK.SIL     1     S.N.A
                                                                                                              T0063     AA03-00487A        CRT COLOR           A68QFZ893X101,-300,1.10,13.3,1     1      S.A
                                                                                                              T0066     AA96-20109A     ASSY POWER CORD           -,CP2/NO(4.0),H/C400,KKP        1      S.A
      T0091                                                                                                   T0074     AA59-00399D         REMOCON           RAY,TM85,S3C1860XP0-SKT1,36,30mA    1      S.A
                                                                                                              T0091     AA94-15869A     ASSY PCB MISC-A/V         CS29Z30ZQTXBWT,KS7C             1      S.A
                                                                                                              T0098     AA94-16048A   ASSY PCB MISC-CONTROL        CS29Z45ZQTXBWT,KS7             1      S.A
                                        M0112
                                                                                                              T0175     AA96-02375A      ASSY SPEAKER P          8ohm,3001-001535,15W,250m        2      S.A
                                                            T0175                                             T0175     AA96-04450A      ASSY SPEAKER P          8ohm,10W,8ohm 10w,600/900        1      S.A
                                                                                                              T0299     AA64-04408A      WINDOW-RMC LED               29Z45,PC,CLEAR              1     S.N.A
                                                                                              M0014           T0607     AA61-40113A       STOPPER-PCB              501H,HIPS,-,-,HB,NTR,-         1     S.N.A
                                                           T0175


                                       T0607
                                                                   T0299




          T0057                                                            T0098



                                     T0054
                              CIS7                                                    T0022
                      T0023




Samsung Electronics                                                                                                                                                                                                   4-1
