Image preview - the first page of the document
>> Download Especificacoes documenatation <<
Text preview - extract from the document
Product Specification
2. ProductSpecification
2-1 ProductSpecification
Features
Block Specification Major IC Remark
CRT 21" Slim CRT 21" Ultra Slim CRT
RF Part 1 TUNER F/S TUNER TDQ-6F/125S
Input Voltage : CIS:AC 160~300V
Power Mexico:AC 110V 5Q0765RT
Other:AC 100~240V
NTSC ONLY
Video UOC TOP
1H Comb Filter
Sound Output : 5W x 2 TDA11145/N1, LA42032
Cabinet 21Z43 Cabinet Z43 Cabinet
Specification
Model CL-21Z43ML
Screen Size 21"
Dimensions (WxHxD) 604 x 472 x 360.5 mm
Weight 23.5 kg
CIS:AC 160~300V
Voltage Mexico:AC 110V
Other:AC 100~240V
Speaker Output 5W + 5W
Samsung Electronics 2-1
Product Specification
2-2 SpecificationsAnalysis
: application, : non-application
Model CL-21Z43ML (KSBE) CL-21Z43MJ (KSBA)
Design
Product Type Ultra Slim CRT Ultra Slim Fit CRT
Digital TV Analog Analog
Basic Digital Display 576i/480i 576i/480i
Screen Size 21 21
Aspect Ratio 4:3 4:3
Progressive Scan O O
Digital Comb Filter X X
Screen Pitch 0.73 0.73
Visual
Digital Noise Reduction X X
Quality
AKB O O
DNle O O
3:2 Pull Down Support X X
Base/Treble/Balance X X
Equalizer X X
AVL X X
Audio
Surround X X
Speaker System Direct Direct
Sperker Output 5W + 5W 5W + 5W
Dual Screen Function X X
Double Screen X X
TTX Caption Caption
Function Still Picture X X
Auto Jack Recognition X X
EPG X X
Network X X
Antenna In Rear:1 Rear:1
Extermal In Rear:1 Rear:1
S-Video X X
Y/Pb/Pr X X
Ports PC X X
DVI X X
HDMI X X
Digital Audio Out X X
Video Out Rear:1 Rear:1
Remote Controller TM85 TM85
the power supply and power consumption, refer to the label attached to the product.
For
2-2 Samsung Electronics
Product Specification
2-3 Accessories
2-3-1 SuppliedAccessories
Accessories Item Item code Remark
Remote Control AA59-00385C
Batteries 4301-000121
Power Cord AA39-10006X
Samsung Service center
Owner's Instructions AA68-03905V
Warranty Card -
Registration Card -
Safety Guide Manual AA68-03242L
2-3-2 Accessoriesthatcanbepurchasedadditionally
Accessories Item Item code Remark
RF Cable -
Video Cable -
Electronics Store/
Internal shopping mall
Audio Cable -
Component Cables (RCA) -
Samsung Electronics 2-3
