Exploded View & Part List
5. ExplodedView&PartList
5-1 CL21Z43MLAXXAOExplodedView
M0006
M0014
T0063
T0238
T0175
T0022
T0003
CIS7
M0112
T0607
T0023
T0066
T0057
T0074
5-1 Samsung Electronics
Exploded View & Part List
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
CIS7 AA61-60003J SPRING ETC-CS -,SUS304,-,-,OD6,N7,OD6,-, 1 S.N.A
M0006 AA63-01565B COVER-REAR 21Z43,HIPS,HB,BK500,K16B 1 S.A
M0014 AA96-05349A ASSY PCB P-MAIN CL21Z43MLAX,KSBE,XAO 1 S.A
M0112 AA63-01559C COVER-FRONT 21Z43,HIPS,HB,GE503,BKN1576+ 1 S.N.A
T0003 AA96-04962A ASSY COVER P-FRONT 21Z43, LATION-AME,,HI 1 S.A
T0022 AA64-04327A KNOB CONTROL 29Z40,SEH,ABS,-,-,-,HB,GR51 1 S.N.A
T0023 AA64-04334A KNOB POWER 21Z40,ABS,HB,GR515,SVM3012 1 S.N.A
T0057 AA64-70123A BADGE-BRAND NEW,AL,L50,FLAT,SILVER,SAMSU 1 S.N.A
T0063 AA03-00551A CRT COLOR A51QGV 991X301,0mG,0.915,14.0, 1 S.A
T0066 AA96-20109B ASSY POWER CORD -,CP2/NO(4.0),H/C250,KKP 1 S.A
T0074 AA59-00385C REMOCON TOMORROW,TM85,S3C1860XP0-SKT1,30 1 S.A
T0175 AA96-04766A ASSY SPEAKER P 8ohm,10W,R/B700mm,Y/B500m 1 S.A
T0238 AA64-04340A WINDOW REMOCON-LED Z40(SEH,TSE),PC,CLEAR 1 S.N.A
T0607 AA61-40113A STOPPER-PCB 501H,HIPS,-,-,HB,NTR,- 1 S.N.A
Samsung Electronics 5-2
Exploded View & Part List
5-2 CL21Z43MLAXXAOElectricalPartList
Loc. No. Code No. Description Specification Q'ty SA/SNA Remark
ASSYCHASSIS
M0017 AA91-11149C ASSY CHASSIS CL21Z43MLAXXAO 1 S.N.A
M0014 AA96-05349A ASSY PCB P-MAIN CL21Z43MLAX,KSBE,XAO 1 S.A
C 2401-000787 C-AL 220uF,20%,160V,GP,BK,16x31.5mm,7.5 1 S.A
C 2401-000025 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 1 S.A
C 2401-000025 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 1 S.A
C 2401-000025 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 1 S.A
C 2401-000025 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 1 S.A
C 2401-000025 C-AL 100uF,20%,16V,GP,TP,6.3x11,5 1 S.A
C 2401-000030 C-AL 22uF,20%,25V,GP,TP,5x11,5 1 S.A
C 2401-000262 C-AL 100uF,20%,160V,HR,TP,16x25,7.5 1 S.A
C 2401-000302 C-AL 100uF,20%,25V,GP,TP,6.3x11,5 1 S.A
C 2401-000302 C-AL 100uF,20%,25V,GP,TP,6.3x11,5 1 S.A
C 2401-000302 C-AL 100uF,20%,25V,GP,TP,6.3x11,5 1 S.A
C 2401-000360 C-AL 100uF,20%,50V,GP,TP,8x11.5,5 1 S.A
C 2401-000365 C-AL 100uF,20%,50V,WT,TP,10x12.5mm, 1 S.A
C 2401-000430 C-AL 10uF,20%,250V,GP,TP,10x16mm,5m 1 S.A
C 2401-000430 C-AL 10uF,20%,250V,GP,TP,10x16mm,5m 1 S.A
C 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 1 S.A
C 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 1 S.A
C 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 1 S.A
C 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 1 S.A
C 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 1 S.A
C 2401-000480 C-AL 10uF,20%,50V,GP,TP,5x11,5 1 S.A
C 2401-000620 C-AL 2.2uF,10%,50V,GP,TP,5x11,5 1 S.A
C 2401-000689 C-AL 2200uF,20%,16V,GP,TP,13x25,5 1 S.A
C 2401-000913 C-AL 22uF,20%,16V,GP,TP,5x11,5 1 S.A
C 2401-000962 C-AL 22uF,20%,50V,GP,TP,5x11,5 1 S.A
C 2401-001101 C-AL 330uF,20%,16V,GP,TP,8x11.5,5 1 S.A
C 2401-001397 C-AL 470uF,20%,25V,GP,TP,10x16,5 1 S.A
C 2401-001397 C-AL 470uF,20%,25V,GP,TP,10x16,5 1 S.A
C 2401-001989 C-AL 4.7uF,20%,50V,BP,TP,5x11,5 1 S.A
C 2401-001989 C-AL 4.7uF,20%,50V,BP,TP,5x11,5 1 S.A
C 2401-001989 C-AL 4.7uF,20%,50V,BP,TP,5x11,5 1 S.A
C 2401-001989 C-AL 4.7uF,20%,50V,BP,TP,5x11,5 1 S.A
C 2401-001989 C-AL 4.7uF,20%,50V,BP,TP,5x11,5 1 S.A
C 2401-001989 C-AL 4.7uF,20%,50V,BP,TP,5x11,5 1 S.A
C 2401-001989 C-AL 4.7uF,20%,50V,BP,TP,5x11,5 1 S.A
C 2401-001998 C-AL 1000uF,20%,25V,GP,TP,10x20,5mm 1 S.A
C 2401-001998 C-AL 1000uF,20%,25V,GP,TP,10x20,5mm 1 S.A
C 2401-002268 C-AL 2.2uF,20%,250V,LZ,TP,8X11,5 1 S.A
C 2401-002463 C-AL 470uF,20%,16V,GP,TP,8x11.5,5 1 S.A
C 2401-002619 C-AL 47uF,20%,25V,GP,TP,5x11,5 1 S.A
C 2401-003019 C-AL 470◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
