Image preview - the first page of the document
>> Download 20060428102249265_s64a_p_evapl_4_153 documenatation <<
Text preview - extract from the document
Exploded View & Part List
4. Exploded View & Part List
4-1 WS32Z419D8XXEU
You can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr
M0006 Loc.No. Code No. Description Specification Q'ty SA/SNA Remark
T0074 T0268
CIS3 AA64-04333A DECORATION-POWER Z40,ABS,HB,GR515,AL 1 S.N.A
CIS7 AA61-60003J SPRING ETC-CS -,SUS304,-,-,OD6,N7,OD6,-, 1 S.N.A
M0006 AA63-01369B COVER-REAR 32Z40(SEH),HIPS,FV2,BK500,S64 1 S.A
T0527 M0014 AA94-15817C ASSY PCB MAIN WS32Z419D8XXEU,S64A,UNLIMI 1 S.A
M0112 AA63-01364C COVER-FRONT 32Z41,SEH,HIPS,HB,BLK,BKN157 1 S.A
T0003 AA96-04064C ASSY COVER P-FRONT 32Z41,XEU,HIPS HB,BLK 1 S.A
T0063
T0022 AA64-04326B KNOB CONTROL Z41,ABS,HB,BK500 1 S.N.A
T0065
T0023 AA64-04328B KNOB POWER Z40,ABS,HB,BKN1576 1 S.N.A
T0057 AA64-01062B BADGE-BRAND ALL,AL,T1.5,10.6,L65,BLK.SIL 1 S.N.A
T0003 T0063 AA03-00482A CRT COLOR W76QFV891X302,+380mG,0.245,14. 1 S.A
T0091 T0065 AA94-15823A ASSY PCB CRT WS32Z409D8XXEU,S64A,UNLIMIT 1 S.A
T0074 AA59-00379A REMOCON WS32Z40,TM86,44,PAL,S59B,IDTV/TV 1 S.A
T0091 AA94-15824A ASSY PCB MISC-A/V SIDE WS32Z409D8XXEU,S6 1 S.A
T0098 AA94-15114H ASSY PCB MISC-CONTROL 32Z41,S64A,UNLIMIT 1 S.N.A
T0175 AA96-03164A ASSY SPEAKER P 8ohm,6*13cm,Z31,10W,SPK+W 1 S.A
M0112 T0238 AA64-04340A WINDOW REMOCON-LED Z40(SEH,TSE),PC,CLEAR 1 S.N.A
T0245 AA61-00711D HOLDER-PCB 29U1,U2,HIPS VO,BK502(HB-PROP 1 S.N.A
T0268 AA39-10007X CBF-POWER CORD -,EP3/YES(HK),H03VVH2-F,2 1 S.A
T0175 T0569
T0527 AA65-00061A CLAMPER CORE-D,COIL NYLON-66,VO,NTR 5 S.N.A
T0569 AA61-01433A SUPPORT-CRT Z40,HIPS V0,GR503 2 S.A
T0238
T0607 AA61-40113A STOPPER-PCB 501H,HIPS,-,-,HB,NTR,- 1 S.A
T0607 M0014
T0098
T0245
T0057
CIS3
CIS7
T0023 T0022
Samsung Electronics 4-1
