Image preview - the first page of the document
>> Download 07_Exploded View & Part List documenatation <<
Text preview - extract from the document
Exploded View & Parts List
6. Exploded View & Parts List
6-1 WS32Z68PSGXXEC
No Code No Description;Specification Q'ty Remark S.N.A
1 AA96-01183A ASSY COVER P-C/FRONT;32Z6,HIPS HB 1
1* AA64-02746A CABINET FRONT;WT-32Z6HR,HIPS,HB,W91499,W 1
1-1 AA64-70117B BADGE-BRAND;-,AL,-,-,L65,R2000,SILVER,SS 1
1-2 AA63-00558A COVER-A/V;32Z6,HIPS,HB,G4309,DGN-1189 1
1-3 AA63-00557B COVER-CONTROL;32Z6,HIPS,HB,G4309,DGN-118 1
1-4 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 2 Cover
1-5 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 2 CC+CF S.N.A
1-6 AA64-02752A WINDOW-RMC;29Z6,PC,VO,VIOLET 1
1-7 AA64-02751A KNOB POWER;29Z6,PC,VO,VIOLET 1
1-8 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, 1
1-9 AA64-02753A INDICATOR LED;29Z6,ACRYL,HB,CLEAR 1
1-10 AA64-02750A DECORATION-POWER;29Z6,ABS,HB,GRAY,AL 1
1-11 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 2 DP+CF
1-12 AA94-11730A ASSY PCB MISC-MASTER;Z6,Z7Z9,K55A,S57A,P 1
1-13 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 1 MPP+LP
1-14 AA64-02662A KNOB-CONTROL;Z7,ABS,HB,G3676,S104M+W971 1
1-15 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 2 Cover
1-16 AA41-00651A PCB-CONTROL;CS29Z7HF,FR-1,1L,A,1.6T,330X 1 PCB
1-17 AA94-12054B ASSY PCB MISC-CONTROL;32Z6,K55A,CIS 1
1-18 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 3 AV+CV
1-19 AA91-00507B ASSY HOLDER SPK;DP,-,8OHM/15W,-,29K1 CKD 1
1-20 6003-001024 SCREW-TAPTITE;RWH,+,B,M4,L12,ZPC(YEL),SW 8 SPK+CF
2 AA91-05676A ASSY CPT;WS32Z68PSGXXEC 1
2-1 HA60-00142A SPACER-GUM;,RUBBER,RED,T2.5,M5 4
2-2 AA65-30018A CLAMPER CORE-WIRE;DONG-A,NYLON-66,-,-,-, 5
2-3 AA60-10050V SCREW-ASSY;-,SWRCH18A,M6,L30,HH,+,WC,-,Z 4 CRT+CF
3 AA64-02747C CABINET-BACK;32Z6,ABS,V0,G5433,SVM2012 1
3-1 6003-001025 SCREW-TAPTITE;RH,+,B,M4,L20,ZPC(BLK),SWR 7 CB+CF
3-2 AA96-01127C ASSY POWER CORD;DP,AA39-10001M,CP2,H/C50 1
Samsung Electronics 6-1
Exploded View & Parts List
6-2 CS29Z7HRGX/XHK
No Code No Description;Specification Q'ty Remark S.N.A
1 AA96-00905F ASSY COVER P-CABINET FRONT;29Z7,CS29Z7HR 1
1* AA64-02650G CABINET-FRONT;CS29Z7HRG,ABS,HB0690M,G430 1
1-1 AA64-01062B BADGE-BRAND;32Z5,AL FORGING,-,-,L65,-,SI 1 S.N.A
1-2 AA64-02665A WINDOW-RMC;Z7,PC,VIOLET 1
1-3 AA64-02663B KNOB-POWER;Z7,PC,VIOLET,MASTER 1
1-4 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, 1 KNOPOW S.N.A
1-5 AA64-02664A DECORATION-POWER;Z7,ABS,HB,NTR 1
1-6 AA64-02666A INDICATOR LED;Z7,ACRYL,CLR 1
1-7 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 1 LED+GS S.N.A
1-8 AA64-02656D GRILLE-SPEAKER;29Z7,ABS,HB,G4309,DGM2188 1 S.N.A
1-9 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR 4 GS+CF S.N.A
1-10 AA96-00910D ASSY COVER P-COVER CONTROL;29Z7,CT-29Z7P 1
1-11 AA64-02662A KNOB-CONTROL;Z7,ABS,HB,G3676,S104M+W971 1
1-12 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 2 KC+CC S.N.A
1-13 AA94-12260B ASSY PCB MISC-CONTROL;29Z7,K55A,PAL,HONG 1
1-14 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 2 CPC+CC S.N.A
1-15 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 2 CC+CF S.N.A
1-16 AA96-00909F ASSY COVER P-COVER A/V;29Z7,CS29Z7HRG,HI 1
1-17 AA94-12261B ASSY PCB MISC-A/V SIDE;29Z7,K55A,PAL,HON 1
1-18 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 3 AV+CV S.N.A
1-19 6003-001268 SCREW-TAPTITE;TH,+,B,M4.0,L12.0,ZPC(YEL) 2 CA+CF S.N.A
1-20 AA91-03959A ASSY HOLDER SPK;-,-,8OHM/10W,-,FRONT SPE 1
1-21 6006-001095 SCREW-ASS'Y TAPT;WP,BH,+,M4,L12,ZPC(YEL) 4 SPK+CF S.N.A
2 AA91-05635A ASSY CPT;CS29Z7HRGX/XTT,CHINA,+380MG,SDI 1 * S.N.A
2-1 AA63-60004Y SPACER-GUM,CRT;ALL MODEL,NTR RUBBER,-,-, 4 S.N.A
2-2 AA65-00019A CLAMPER CORE-D,COIL;25-34,NYLON 66,V2,N 4 S.N.A
2-3 AA60-10050V SCREW-ASSY;-,SWRCH18A,M6,L30,HH,+,WC,-,Z 4 CRT+CF S.N.A
3 AA64-02651D CABINET BACK;29Z7,ABS,VO,G4309,SVM2012 1 S.N.A
3-1 AA63-00563A COVER-BACK,R;29Z7,ABS,HB,G4309,DGM2188 1 S.N.A
3-2 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, 2 CV+CB S.N.A
3-3 AA63-00562A COVER-BACK,L;29Z7,ABS,HB,G4309,DGM2188 1 S.N.A
3-4 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, 2 CV+CB+ S.N.A
3-5 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, 5 CB+CF S.N.A
3-6 AA91-03960A ASSY HOLDER SPK;-,-,8OHM/25W,-,WOOFER SP 1
3-7 6006-001095 SCREW-ASS'Y TAPT;WP,BH,+,M4,L12,ZPC(YEL) 3 WOO+CB S.N.A
4 AA96-20126D ASSY POWER CORD;-,EP3/YES,N(H/C500MM),MP 1 S.N.A
CS29Z7HRGX/XHK CS-29Z7HR,K55A,TM63,+200MG,HONG KONG 0
6-2 Samsung Electronics
Exploded View & Parts List
6-3 CS29Z4HNGX/BWT
No Code No Description;Specification Q'ty Remark S.N.A
1 AA91-00748P ASSY CABINET FRONT;,CS29Z4,SV012P K55A C 1
1* AA64-01973F CABINET-FRONT;29Z4,HIPS,HB,G4309,SV012P 1 S.N.A
1-2 AA64-01062B BADGE-BRAND;32Z5,AL FORGING,-,-,L65,-,SI 1 S.N.A
1-3 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR 10 HP+CF S.N.A
1-4 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 2 D-FOCU S.N.A
1-5 AA41-00522A PCB-CONTROL;CS32Z4,FR-1,1L,A,1.6T,245X24 1 PCB S.N.A
1-6 AA64-03209A KNOB-CONTROL;Z4,ABS,HB,WHT,SVM3012 1 S.N.A
1-7 6003-001026 SCREW-TAPTITE;RH,+,B,M4,L15,ZPC(BLK),SWR 2 KC+CF S.N.A
1-8 AA64-01203B INDICATOR LED;32Z5,ACRYL,-,CLR,-,-,- 1
1-9 AA64-03210A KNOB-POWER;Z4,ABS,HB,WHT,SVM3012 1
1-10 AA61-60003J SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-, 1 S.N.A
1-11 AA64-03211A WINDOW-REMOCON;Z4,PC,VIOLET 1 S.N.A
1-12 6003-001070 SCREW-TAPTITE;BH,+,B,M2,L4,ZPC(BLK),SWRC 2 S.N.A
1-13 6003-000333 SCREW-TAPTITE;RH,+,2S,M3,L10,ZPC(YEL),SW 2 WP+HC
1-14 AA41-00521A PCB-MASTER S/W;CS32Z4,FR-1,1L,A,1.6T,245 1 PCB S.N.A
1-15 AA61-00450B HOLDER-POWER;32Z5,ABS,-,-,-,GRAY,HB 1 S.N.A
1-16 6003-001019 SCREW-TAPTITE;RH,+,B,M4,L12,ZPC(BLK),SWR 2 WIN+CF S.N.A
1-17 AA91-00738A ASSY HOLDER SPK;-,PP,8OHM,10W,-,ZEUS-2 F 2
1-18 6006-001096 SCREW-ASS'Y TAPT;WP,BH,+,M4.0,L12,BLK,SW 4 SPK+CF S.N.A
2 AA94-12358A ASSY PCB MISC-LED;Z4,K55A,PAL 1
2-1 6002-000522 SCREW-TAPPING;TH,+,2,M4,L15,ZPC(BLK),SWR 2 BRK+CF S.N.A
3 AA91-03134A ASSY CPT;CT-29Z4HR 1 S.N.A
3-1 AA63-60004Y SPACER-GUM,CRT;ALL MODEL,NTR RUBBER,-,-, 4 S.N.A
3-2 AA60-10050V SCREW-ASSY;-,SWRCH18A,M6,L30,HH,+,WC,-,Z 4 CRT+CF S.N.A
3-3 AA61-10054A BRACKET-CRATER;6277,STS304,T0.5,-,-,-,- 2 S.N.A
4 AA64-01976B CABINET BACK;29Z4,HIPS,FV2,GR503 1
4-1 AA60-10050T SCREW-TAPPING;-,SWRCH18A,M4,L20,RH,+,2S, 8 CB+CF S.N.A
4-2 6006-001095 SCREW-ASS'Y TAPT;WP,BH,+,M4,L12,ZPC(YEL) 5 TBA+HC S.N.A
4-3 AA61-00707B HOLDER-COVER;ALL MODEL,NYLON-66 T1.0 V2, 1 S.N.A
5 AA96-20130H ASSY POWER CORD;-,CP2/NO(4.0R),H/S 500MM 1 S.N.A
Samsung Electronics 6-3
