Image preview - the first page of the document



>> Download 04_EXPLODED_VIEW_&_PART_LIST documenatation <<

Text preview - extract from the document

                                                                                                                                                                     Exploded View & Part List



4. Exploded View & Part List
4-1 TXR2728X/XAP
Yon can search for the updated part code through ITSELF web site.
URL:http://itself.sec.samsung.co.kr


                                                                                                Loc.No.    Code No.                Description;Specification               Q'ty      S.N.A
                                                                                                 CIS7     AA61-60003J     SPRING ETC-CS;-,SUS304,-,-,OD6,N7,OD6,-,          1        S.N.A
                                                                                        T0015
                                                                                                M0014     AA94-13939E   ASSY PCB MAIN;TXP2728X/XAC,KS7A,GOLD RUS            1
         T0074
                                                                                                T0003     AA64-03817B   CABINET FRONT;29M16,SAMEX,HIPS,V0,G4309,            1        S.N.A
                                                                                                T0015     AA64-03820B    CABINET BACK;29M16,SAMEX,HIPS,V0,G4309             1
                                                                                                T0022     AA64-03958A   KNOB CONTROL;29M16,SAMEX,ABS,HB,G3676,SV            1        S.N.A
                                                                    T0527                       T0023     AA64-03823A    KNOB-POWER;29M16,ABS,HB,G3676,SVM3012              1
                                                                                                T0057     AA64-70117B     BADGE-BRAND;,AL,T1.5,10.6,L65,BLK,SILVER          1
                                                                                                T0061     AA64-03824A       WINDOW-REMOCON;29M16,PC,CLEAR                   1
                                                                            T0063
                                                                                                T0063     AA03-00391A   CRT COLOR;A68QCU770X 53N,380MG,1.1MH,14.            1
                                                                                                T0066     AA96-20129A   ASSY POWER CORD;-,EP2/YES,H/C300,ME301P,            1
                                                                                                T0074     AA59-00325B       REMOCON;TM76,K57A,39,G6148,NT,EX                1
                                                                                                T0098     AA96-02084A    ASSY PCB P;A/V SIDE,KS7A,CT-29K10,GOLD R           1
                                                                                                T0175     AA96-01461B   ASSY SPEAKER P;8ohm,28A11,10W,Semidome S            1
                                                                                                T0527     AA65-00019A    CLAMPER CORE-D,COIL;25-34",NYLON 66,V2,N           4        S.N.A
  T0003                                                                                         T0607     AA61-40113A        STOPPER-PCB;501H,HIPS,-,-,HB,NTR,-             1

                                                           T0175
                                                T0022
                                           T0061
                                       CIS7
                                 T0023
     T0098

                T0607                                                               M0014




      T0057


                                          T0066




Samsung Electronics                                                                                                                                                                       4-1
