Image preview - the first page of the document



>> Download Installing-CD-Tray-4076 documenatation <<

Text preview - extract from the document

Installing Sega CD CD Tray




                        Installing Sega CD CD Tray

                                 Step 1 - disassembly Plastic Housing
                                    Remove the six screws on the underside of the console
                                    using a medium phillips screwdriver
                                          1/2 inch bronze screws (6)




                                 Step 2
                                    Remove the 2 screws on the side of the console that
                                    attach the Genesis adapter to the rest of the unit using
                                    a medium phillips screwdriver.
                                          3/8 inch black screws (2)
