Installing Sega CD Genesis Connector




              Installing Sega CD Genesis Connector

                                        Step 1 - disassembly Plastic Housing
                                           Remove the six screws on the underside of the console
                                           using a medium phillips screwdriver
                                                 1/2 inch bronze screws (6)




                                        Step 2
                                           Remove the 2 screws on the side of the console that
                                           attach the Genesis adapter to the rest of the unit using
                                           a medium phillips screwdriver.
                                                 3/8 inch black screws (2)
