Image preview - the first page of the document



>> Download Repairing-Controller-Port-1562 documenatation <<

Text preview - extract from the document

Repairing Sega Dreamcast Controller Port




          Repairing Sega Dreamcast Controller Port
         Tools used in this guide
              Desoldering Wick
              Phillips #2 Screwdriver
              Solder
              Soldering Iron



                                            Step 1 - Expansion bay
                                               Verify that the console is disconnected from
                                               the AC outlet before you begin.


                                               Flip the console over on its back.
                                               Take note of your model number, in case
                                               replacement parts are needed.
