Image preview - the first page of the document



>> Download Repairing-Logic-Board-2346 documenatation <<

Text preview - extract from the document

Repairing Sega Game Gear Logic Board




            Repairing Sega Game Gear Logic Board
         Tools used in this guide
             Small Screwdriver(s)



                                         Step 1 - Battery
                                           Place your device upside down and locate the two
                                           battery compartments.




                                         Step 2
                                           Press on the tabs at the bottom of the battery covers
                                           then lift up to remove.
