Image preview - the first page of the document



>> Download Sharp_LC-60LE822E_[SM] documenatation <<

Text preview - extract from the document

                                                                                                         LC-60LE822E/LC-60LE822ERU


                                                            SERVICE MANUAL
                                                                                                                  No. S90L460LE822E



                                                                        LCD COLOUR TELEVISION


                                                                              LC-60LE822E
                                                   MODELS                     LC-60LE822ERU
In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-
inal condition and only parts identical to those specified should be used.


                                                                 CONTENTS
    SAFETY PRECAUTION                                                         CHAPTER 5. TOUCH SENSOR UNIT POSITIONING
       IMPORTANT SERVICE SAFETY                                               FIGURE
       PRECAUTION....................................................i
                                                            .                 [1] TOUCH SENSOR UNIT POSITIONING
       Precautions for using lead-free solder ..............ii
                                                            .                     FIGURE .........................................................5-1
       End of life disposal ........................................... iii
                                                            .
                                                                              CHAPTER 6. ADJUSTMENT
    OUTLINE                                                                   [1] ADJUSTMENT PROCEDURE ......................6-1
       MAJOR SERVICE PARTS ...............................iv
                                               .
                                                                              CHAPTER 7. TROUBLESHOOTING TABLE
    CHAPTER 1. SPECIFICATIONS                                                 [1] TROUBLESHOOTING TABLE ......................7-1
    [1] SPECIFICATIONS ........................................ 1-1
                                                       .                      [2] LED flashing specification at the time of the
                                                                                  error .............................................................7-14
    CHAPTER 2. OPERATION MANUAL
    [1] Parts Name ................................................... 2-1
                                                              .               CHAPTER 8. MAJOR IC INFORMATIONS
                                                                              [1] MAJOR IC INFORMATIONS .........................8-1
    CHAPTER 3. DIMENSIONS
    [1] DIMENSIONS ............................................... 3-1
                                                          .                   CHAPTER 9. OVERALL WIRING/BLOCK DIAGRAM
                                                                              [1] OVERALL WIRING DIAGRAM ......................9-1
    CHAPTER 4. REMOVING OF MAJOR PARTS                                        [2] SYSTEM BLOCK DIAGRAM .........................9-2
    [1] REMOVING OF MAJOR PARTS .................. 4-1 .
    [2] Caution Cleaning Glass ................................ 4-6
                                                       .                      Parts Guide
    [3] How to replace the Touch Sensor key PWB ........ 4-8




Parts marked with "   " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining the
safety and performance of the set.


                                                                                                  This document has been published to be used for
                                                                                                  after sales service only.
                                                                                                  The contents are subject to change without notice.
