Image preview - the first page of the document
>> Download AR-5316_5320 sm documenatation <<
Text preview - extract from the document
CODE : 00ZAR5320/A1E
DIGITAL COPIER
AR-5316
AR-5316
MODEL AR-5320
AR-5320
(with option installed)
CONTENTS
[ 1 ] NOTE FOR THIS SERVICE MANUAL . . . . . . . . . . . . . . . Refer to AR-M160
[ 2 ] SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .AR-5316/5320
[ 3 ] CONSUMABLE PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .AR-5316/5320
[ 4 ] EXTERNAL VIEWS AND INTERNAL STRUCTURES . . . . . .AR-5316/5320
[ 5 ] UNPACKING AND INSTALLATION . . . . . . . . . . . . . . . . . . . . .AR-5316/5320
[ 6 ] ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Refer to AR-M160
[ 7 ] SIMULATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .AR-5316/5320
[ 8 ] USER PROGRAMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .AR-5316/5320
[ 9 ] TROUBLE CODE LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . Refer to AR-M160
[10] MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .AR-5316/5320
[11] DISASSEMBLY AND ASSEMBLY . . . . . . . . . . . . . . . . . . . Refer to AR-M160
[12] FLASH ROM VERSION UP PROCEDURE . . . . . . . . . . . Refer to AR-M160
[13] ELECTRICAL SECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . .AR-5316/5320
Parts marked with " " are important for maintaining the safety of the set.
Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used for
SHARP CORPORATION after sales service only.
The contents are subject to change without notice.
[1] NOTE FOR THIS SERVICE MANUAL
This Service Manual describes only the items related to the AR-5316 and AR-5320. For the other items common with the AR-M160/M205, please refer
to the AR-M160/205 Service Manual (Document code:00ZARM205/A1E). The table below shows which document(s) should be referred to for each
section. (Refer to the document marked with O.)
Section AR-M160/M205 AR-5316/AR-5320 Changed item
[ 1 ] GENERAL O
[ 2 ] SPECIFICATIONS O O Some specifications
[ 3 ] CONSUMABLE PARTS O
[ 4 ] EXTERNAL VIEWS AND INTERNAL STRUCTURES O O Appearance / Internal / Operation panel
[ 5 ] UNPACKING AND INSTALLATION O O Changing the copy paper size in the tray
[ 6 ] ADJUSTMENTS O
[ 7 ] SIMULATIONS O O Shifter sensors status display, etc. deleted.
[ 8 ] USER PROGRAMS O O USB2.0 mode switch, etc. deleted.
[ 9 ] TROUBLE CODE LIST O
[10] MAINTENANCE O
[11] DISASSEMBLY AND ASSEMBLY O
[12] FLASH ROM VERSION UP PROCEDURE O
[13] ELECTRICAL SECTION O O Block diagram / Actual wiring diagram 1/7
[2] SPECIFICATIONS
The table below shows the specifications of this model and the contents of changes from the AR-M160/M205 and AR-5316/5320.
Item AR-M160 AR-5316 AR-M205 AR-5320
Paper feed system 1cassette + One automatic feeding paper 2cassette + Two automatic feeding paper
Multi manual paper feed tray(250sheets) + Multi manual paper feed trays(250sheets each) +
bypass tray(100sheets) bypass tray(100sheets)
Weight Approx.31.3Kg Approx.31.3Kg Approx.35.1Kg Approx.36.3Kg
(Not including TD cartridge) (Not including TD cartridge)
Interface USB1.1/USB2.0 IEEE1284parallel connector/ USB1.1/USB2.0 IEEE1284parallel connector/
IEEE1284 USB1.1 IEEE1284 USB1.1
Option
Machine Model AR-M160 AR-M205 AR-5316 AR-5320 Remark
250 sheets paper feed unit AR-D24 / D25 O O - -
SPF AR-SP6 O - O O
RSPF AR-RP6 - O - -
Original cover AR-VR5 Standard O Standard Standard
O : The option can be installed.
- : The option cannot be installed.
AR-5316/5320 NOTE FOR THIS SERVICE MANUAL 1-1
[3] CONSUMABLE PARTS
1. Supply system table
A. East Europe / Russia
NO Name Content Life Product name Remark
1 Toner cartridge(Black) Toner x10 160K AR-016LT Life setting by A4 6% document
(Toner: Net Weight 537g) LT=T*10
Vinyl bag x10
2 Developer Developer x10 500K AR-202LD LD=DV*10
(Developer : Net Weight 400g)
3 Drum kit Drum x1 50K AR-202DM
Drum fixing plate x1
Note 1: The individual carton is printed with English, German, French, and Spanish as well as the green mark.
B. Middle East / Africa / Philippine
NO Name Content Life Product name Remark
1 Toner cartridge(Black) Toner x10 190K AR-016ET Life setting by A4 6% document
(Toner: Net Weight 537g) ET=FT*10
Vinyl bag x10
2 Developer Developer x10 500K AR-202CD CD=SD*10
(Developer : Net Weight 400g)
3 Drum kit Drum x1 50K AR-202DR
Drum fixing plate x1
Note 1: The individual carton is printed with English, German, French, and Spanish as well as the green mark.
C. Asia
NO Name Content Life Product name Remark
1 Toner cartridge(Black) Toner x10 190K AR-016CT Life setting by A4 6% document
(Toner: Net Weight 537g) CT=ST*10
Vinyl bag x10
2 Developer Developer x10 500K AR-202CD CD=SD*10
(Developer : Net Weight 400g)
3 Drum kit Drum x1 50K AR-202DR
Drum fixing plate x1
Note 1: The individual carton is printed with English, German, French, and Spanish as well as the green mark.
D. Hong Kong
NO Name Content Life Product name Remark
1 Toner cartridge(Black) Toner x10 190K AR-016CT-C Life setting by A4 6% document
(Toner: Net Weight 537g) CT-C=ST-C*10
Vinyl bag x10
2 Developer Developer x10 500K AR-202CD-C CD-C=SD-C*10
(Developer : Net Weight 400g)
3 Drum kit Drum x1 50K AR-202DR-C
Drum fixing plate x1
Note 1: The individual carton is printed with English and Chinese as well as the green mark.
AR-5316/5320 CONSUMABLE PARTS 3-1
[4] EXTERNAL VIEWS AND INTERNAL STRUCTURES
1. Appearance
1
6 5
1
15 2
3
16 3
9
4 7
10
14
8 11 12 13
1 Document feeder cover (when the SPF 2 Document glass 3 Handles
is installed) /document cover
4 Power switch 5 Operation panel 6 Paper output tray
7 Front cover 8 Paper trays 9 Side cover
10 Side cover handle 11 Bypass tray guides 12 Bypass tray
13 Bypass tray extension 14 Charger cleaner 15 USB 1.1 connector
16 Parallel connector
2. Internal
17 18 19
20 21
22
24 25 26 27
23
17 Document feeder tray 18 Original guides 19 Feeding roller cover
(when the SPF is installed) (when the SPF is installed) (when the SPF is installed)
20 Right side cover 21 Exit area 22 Toner cartridge lock release lever
(when the SPF is installed) (when the SPF is installed)
23 Toner cartridge 24 Roller rotating knob 25 Fusing unit release levers
26 Photoconductive drum 27 Fusing unit paper guide
AR-5316/5320 EXTERNAL VIEWS AND INTERNAL STRUCTURES 4-1
3. Operation Section
1 2 3
The indications of the operation panel may differ
depending on the country and the region.
AR-5316/ The example of a display of inch series
AR-5316X 200%
11X17 141
