Image preview - the first page of the document
>> Download ARM160-205_PG_PWBs_GB-JP documenatation <<
Text preview - extract from the document
q PARTS GUIDE
CODE:00ZARM205/P2/
DIGITAL COPIER
AR-200M [Japan only]
AR-160M [Japan only]
AR-20AR-M205
AR-M205 [Except Japan]
AR-M160 [Except Japan]
AR-5220 [Except Japan]
AR-SP6/RP6 [Option]
AR-D24/D25 [Option]
MODEL AR-EB7 [Option]
CONTENTS
1 MCU PWB
2 CCD PWB
3 COPY OPE PWB
4 I/F PWB
5 SCAN OPE PWB
6 TRAY PWB
7 SPF/RSPF INTERFACE PWB(Option AR-SP6/RP6)
8 SPF SENSOR PWB(Option AR-SP6/RP6)
9 CASETTE PWB(Option AR-D24/D25)
F IMC2 PWB(Option AR-EB7)
I (Index)
This document has been published to be used for
SHARP CORPORATION after sales service only.
The contents are subject to change without notice.
A :
B :
E :
D :
C :
DEFINITION
Rank A : Maintenance parts, and consumable parts which are not included in but closely related to maintenance parts
Rank B : Performance/function parts (sensors, clutches, and other electrical parts), consumable parts
Rank E : Unit parts including PWB
Rank D : Preparation parts (External fitting, packing, parts packed together)
Rank C : Parts other than the above (excluding sub components of PWB)
!
Because parts marked with "!" is indispensable for the machine safety maintenance and operation, it must be replaced with
the parts specific to the product specification.
F ( )
F Other than this Parts Guide, please refer to documents Service Manual(including Circuit Diagram)of this model.
F Please use the 13 digit code described in the right hand corner of front cover of the document, when you place an order.
F For U.S. only-Use order codes provided in advertising literature. Do not order from parts department.
1 MCU PWB
PRICE RANK NEW PART
NO. PARTS CODE Ex. Ja. MARK RANK DESCRIPTION
2 VHI29L0800BQS BD GJ B Frash ROM [AR-M205/AR-5220][IC10] Frash ROM
3 VHI29L0800CQS BD GJ B Frash ROM [AR-200M][IC10] Frash ROM
4 QCNCM0017QSZZ AC DJ C Connector(4pin) [AR-M160/AR-M205/AR-5220][CN29]
8 QCNCM0877FCZZ AF DS C Connector(20pin) [CN36]
9 QCNCM0923FC12 AE DJ C Connector(12pin) [CN2]
10 QCNCM1005MCZZ AB DD C Connector(2pin) [CN30]
11 QCNCM1006MCZZ AB DD C Connector(3pin) [CN28]
12 QCNCM2334SC0B AB DD C Connector(2pin) [CN22]
13 QCNCM2401SC0C AB DJ C Connector(3pin) [CN10,CN20]
14 QCNCM2401SC0D AC DJ C Connector(4pin) [CN32]
15 QCNCM7014SC0C AA DD C Connector(3pin) [CN14,CN25]
16 QCNCM7014SC0D AB DD C Connector(4pin) [CN12,CN17,CN27]
17 QCNCM7014SC0E AB DJ C Connector(5pin) [AR-M205 only][CN13]
18 QCNCM7014SC0F AB DD C Connector(6pin) [CN19]
19 QCNCM7014SC1C AC DD C Connector(13pin) [CN35]
21 QCNCW0024QSZZ AF DS C Connector(32pin) [CN5]
22 QCNCW0077QSZZ AK DX C Connector(25pin) [CN9]
23 QCNCW0078QSZZ AF DS C Connector(35Pin) [CN4]
26 QCNCW0885FCZZ AG DX C Connector(12Pin) [CN37]
27 QCNCW1124LC0D AB DJ C Connector(4pin) [CN8]
28 QCNCW1124LC0H AC DJ C Connector(8pin) [CN24]
29 QCNCW1124LC1C AC DJ C Connector(13pin) [CN26]
31 QSOCZ0002QSZZ AD DJ C IC socket(CICO-083-S8-T) [IC3] IC
32 RCRSP0016QSZZ AD DJ B Crystal(19.6608MHz) [X1]
35 RFILZ0004QSZZ AM EG C Filter(ZJSR5101-223) [L1,L2,L3,L5,L6,L7] -
36 RH-DZ0016FCZZ AB DD B Diode(MA700) [D2]
SDRAM(MT48LC8M16ATG-8E) SDRAM
37 RH-IX0001QSZZ BD GN B
[AR-M160/AR-5220/AR-200M/AR-160M][IC9]
39 RH-IX7001XCZZ AQ EQ B SRAM(IS63LV1024L-12J-TR) [IC8,IC11] SRAM
RMPTW4100QCJJ AA DD B Block resistor(10◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
