Image preview - the first page of the document
>> Download CAMARA SONY DCR - TRV 725---730---828---830 Level 2 v1.1 documenatation <<Text preview - extract from the document DCR-TRV725E/TRV730/TRV730E/TRV828/
TRV828E/TRV830/TRV830E
RMT-814
US Model
SERVICE MANUAL Canadian Model
Korea Model
Level 2 Ver 1.1 2001. 07 DCR-TRV730/TRV828/TRV830
AEP Model
UK Model
DCR-TRV725E/TRV730E/
TRV828E/TRV830E
E Model
Hong Kong Model
DCR-TRV730/TRV730E/TRV828/
TRV828E/TRV830/TRV830E
Australian Model
DCR-TRV730E/TRV828E
Photo : DCR-TRV730E Chinese Model
RMT-814 DCR-TRV828E
M2000 MECHANISM
On the VC-262 board For MECHANISM ADJUSTMENT, refer to the
This service manual provides the information that is premised the "8mm Video MECHANICAL ADJUSTMENT
circuit board replacement service and not intended repair inside the MANUAL IX M2000 MECHANISM " (9-929-861-
VC-262 board. 11).
Therefore, schematic diagram, printed wiring board, waveforms, parts
list and electrical parts list of the VC-262 board are not shown. NTSC model : DCR-TRV730/TRV828/TRV830
The following pages are not shown. PAL model : DCR-TRV725E/TRV730E/
Printed wiring board ......................... Pages 4-11 to 4-14 TRV828E/TRV830E
Schematic diagram .......................... Pages 4-15 to 4-58
Waveforms and parts list ................. Pages 4-101 to 4-104
Electrical parts list ............................ Pages 6-19 to 6-31
SPECIFICATIONS
Fastforward/rewind time Camera mode: Audio/Video input/output
Video camera DCR-TRV730/TRV828/TRV830: 47
