Image preview - the first page of the document
>> Download CAMARA SONY DSR - 250---P ( VERS 1.2 ) documenatation <<Text preview - extract from the document DSR-250/250P RMT-811
SERVICE MANUAL Ver 1.2 2001. 11
US Model
Canadian Model
DSR-250
AEP Model
DSR-250P
Photo : DSR-250 R MECHANISM
RMT-811
NTSC model : DSR-250
PAL model : DSR-250P
SPECIFICATIONS
Viewfinder AUDIO IN/OUT CH-1/CH-2 General
Video camera Electric viewfinder (B&W) Input/output auto switch
recorder Image device RCA pin-jack, 245 mV, (at output Peak inrush current (DSR-250P)
1/3 type CCD (3 Charge Coupled impedance more than 47 kilohms) (1) Hot switching inrush current,
Device) Approx. 380 000 pixels Output impedance with less than measured in accordance with
System
(Effective: Approx. 340 000 pixels) 2.2 kilohms European standard EN55103-1:
Video recording system 6.3 A (230 V)
(DSR-250), Approx. 450 000 pixels Input impedance more than
2 rotary heads Power requirements
(Effective: Approx. 400 000 pixels) 47 kilohms
Helical scanning system 14.4 V (Lithium-ion battery pack)
(DSR-250P) AUDIO IN CH1/CH2
Audio recording system 12 to 17 V (AC power adaptor)
Lens XLR 3-pin, female
Rotary heads, PCM system Average power consumption
Combined power zoom lens
