Image preview - the first page of the document



>> Download SONY_DSC-P31 documenatation <<

Text preview - extract from the document

                                                               DSC-P31/P31M
SERVICE MANUAL                                                                                                                                      US Model
                                                                                                                                                  DSC-P31/P31M
 Level 3                                                                                                                            Canadian Model
                                                                                                                                         AEP Model
                                                                                                                                           UK Model
                                                                                                                                             E Model
Ver 1.1 2002. 04                                                                                                                   Hong Kong Model
                                                                                                                                    Australian Model
                                                                                                                                     Chinese Model
                                                                                                                                        Korea Model
                                                                                                                                       Tourist Model
                                                                                                                                    Japanese Model
                                                                                                                                                             DSC-P31



This service manual contains information for Japanese model as well.


                                                                    SPECIFICATIONS

     System                                                Power, etc.                                          AC-LS1 AC power adaptor (not
     Image device 6.64 mm (1/2. 7 type) color              Power        AA nickel hydride battaries (2)         supplied)
                   CCD                                                 2.4 V                                    Power requirements
                   Primary color filter                                AC-LS1 AC power adaptor                                AC 100
