Image preview - the first page of the document
>> Download SONY_DSC-S70 documenatation <<
Text preview - extract from the document
DSC-S70
SERVICE MANUAL US Model
Canadian Model
Level 2 Ver. 1.2 2001.07 AEP Model
UK Model
E model
Hong Kong Model
Australian Model
Chinese Model
Korea Model
Tourist Model
Japanese Model
This service manual contains information for Japanese model as well.
On the SY-58 board SY-58 board
This service manual procides the information that is premised the Schematic diagram ................................... Pages 4-15 to 4-30
circuit board replacement service and not intended repair inside the Printed wiring board ................................. Pages 4-11 to 4-14
SY-58 board. Electrical parts list .................................... Pages 6-11 to 6-15
Therefore, schematic diagram, printed wiring board and electrical
parts list of the SY-58 board are not shown.
The above-described information is shown in service manual
The following pages are not shown.
Level 3.
SPECIFICATIONS
System Output connector Storage temperature Maximum dimensions
