Image preview - the first page of the document



>> Download SONY_MVC-FD87_FD92 documenatation <<

Text preview - extract from the document

                                           MVC-FD87/FD92
SERVICE MANUAL                                                                                                       US Model
                                                                                                              Canadian Model
 Level 2                                                                                                           AEP Model
                                                                                                                     UK Model
                                                                                                                       E Model
Ver 1.1 2001. 06
                                                                                                             Hong Kong Model
                                                                                                              Australian Model
                                                                                                                 Korea Model
                                                                                                              Japanese Model
                                                        PHoto: MVC-FD92



This service manual contains information for Japanese model as well.

 When the machine needs to be repaired,
 please refer to page 7 to discriminate the
 type of LCD.

 On the FC-85 board                                                         FC-85 board
 This service manual procides the information that is premised the          Schematic diagram ..................................... Page 4-15 to 4-38
 circuit board replacement service and not intended repair inside the       Printed wiring board ................................... Page 4-11 to 4-14
 FC-85 board.                                                               Electrical parts list ...................................... Page 6-10 to 6-18
 Therefore, schematic diagram, printed wiring board and electrical
 parts list of the FC-85 board is not shown.                                The above-described information is shown in service manual
 The following pages are not shown.                                         Level 3.



                                                         SPECIFICATIONS
         System                                          Data system                                             Flash
                                                         FD92: Movie: MPEG                                       Recommended recording
         Image device
         FD92: 5 mm (1/3.6 type) color CCD                     Still: JPEG, GIF (in TEXT                         distance:
         FD87: 6.64 mm (1/2.7 type) color CCD                  mode, Clip Motion), TIFF                          0.3 m to 2.5 m (11 7/8 inches
                                                               Audio with still image:                           to 8 1/3 feet)
         Lens                                                  MPEG (Monaural)
         FD92: 8
