Image preview - the first page of the document
>> Download CAR0401 documenatation <<
Text preview - extract from the document
CONFIDENTIAL CSA-14
Sony Service Company
National Technical Services Service Bulletin
A Division of Sony Electronics Inc.
Park Ridge, New Jersey 07656 Car Stereo
Model: EXR-11, XR-1400 No. 401
Subject: SOUND LEVEL IS LOW IN ONE CHANNEL Date: July 3, 1996
Symptom:
(152) The sound level is low in either the Left or Right channel. The symptom may occur in
some models due to a defective variable resistor.
Solution: If this problem is found to be caused by a defective RV503, remove it and replace it
with a new one.
REF FORMER NEW
DESCRIPTION PART NUMBER DESCRIPTION PART NUMBER
RV503 RESISTOR, 1-223-818-11 RESISTOR, 1-223-818-11
VARIABLE VARIABLE
Reference: ME-96008 PRINTED IN USA
PRINTED ON RECYCLED PAPER
