Image preview - the first page of the document



>> Download CAR0360 documenatation <<

Text preview - extract from the document

                                  Car Stereo                                                      CSA-14
                                  Service Bulletin
                                  Sony Service Company - Technical Services
                                  A Division of Sony Electronics Inc.
                                  Sony Drive, Park Ridge, New Jersey 07656


Model:      MDX-40/400                                                    No.    360
Subject: Audio Skipping                                                   Date: May 1, 1995


Symptom:
  (57)         The audio skips when playing pre-recorded and recordable discs.



Solution:      In some cases, this problem may be eliminated by replacing ferrite bead inductors
               FB304 and FB307 with 0 ohm jumper resistors. If installing the jumper resistors fails
               to correct the problem, conventional troubleshooting techniques should be used.

                   REF                     FORMER                                        NEW
                             DESCRIPTION         PART NUMBER               DESCRIPTION     PART NUMBER

                  FB304      INDUCTOR,              1-414-235-11             RESISTOR,         1-216-295-11
                  FB307     FERRITE BEAD                                      O OHM



               Applicable serial numbers

               MDX-40:       11669 ~ 17049

               MDX-400:      15187 ~ 20899




                                                                                   Main Board Side A




Reference: Technical News ME-95005                                                                PRINTED IN USA
