                                 Car Stereo                                                  CSA-14
                                 Service Bulletin
                                 Sony Service Company - Technical Services
                                 A Division of Sony Electronics Inc.
                                 Sony Drive, Park Ridge, New Jersey 07656

Model:      EXR-21, XR-6450, XR-C190, XR-C210, XR-C410                       No.    396
Subject: No Tape Play In Reverse.                                            Date: April 4, 1996


Symptom:
  (62)         Shortly after reversing the tape, the mechanism returns to forward play. This
               problem may be caused by both pinch lever assemblies simultaneously engaging the
               tape and both capstans.



Solution:      Replace the forward and reverse pinch lever assemblies as shown below:

                  REF                   FORMER                                      NEW
                            DESCRIPTION         PART NUMBER              DESCRIPTION    PART NUMBER
                   111      PINCH LEVER            X-3368-266-1          PINCH LEVER      X-3372-000-1
                              (F) ASSY.                                   (FS) ASSY.
                   112      PINCH LEVER            X-3368-267-1          PINCH LEVER      X-3372-001-1
                              (R) ASSY.                                   (RS) ASSY.




Reference: T/N ME-95030; SEC ME00396                                                         PRINTED IN USA

                                             PRINTED ON RECYCLED PAPER
