                                   Car Stereo                                                    CSA-14
                                   Service Bulletin
                                    Sony Service Company - Technical Services
                                    A Division of Sony Electronics Inc.
                                    Sony Drive, Park Ridge, New Jersey 07656


Model:      XR-U500/U700/U800                                               No.    344
Subject: Noise Heard From Speakers When Using Cellular                      Date: November 30, 1994
            Phone.


Symptom:
  (54)          Noise may be heard from the speakers when using a cellular phone.



Solution:       If the customer complains of this problem, implement the following changes on the
                Main board.

                     REF               DESCRIPTION                          PART NUMBER

                      -           RESISTOR, 33K, 1/4 W                       1-249-435-11



                1-    Cut the traces as indicated by the "X".

                2-    Add 33K resistors between the following points:

                              IC301 pin 11 and IC201 pin 5

                              IC301 pin 13 and IC201 pin 3

                              IC301 pin 24 and IC101 pin 5

                              IC301 pin 26 and IC101 pin 3




Reference: Tecnical News ME-94019                                                               PRINTED IN USA
