>> Download Car0346 documenatation <<Text preview - extract from the document Car Stereo CSA-14
Service Bulletin
Sony Service Company - Technical Services
A Division of Sony Electronics Inc.
Sony Drive, Park Ridge, New Jersey 07656
Model: GEN-CAR No. 346
Subject: Preventing Recurring Damage To Tuner Pack. Date: December 27, 1994
Symptom:
(21) The customer may complain that the tuner sensitivity has become poor, which is
cured by replacing the tuner pack. At a time subsequent to the repair, the customer
complains that the sensitivity has become poor again.
Solution: Replace the tuner pack. Prevent recurring damage to the tuner pack by adding a
discharge gap across the antenna input lead and ground.
REF DESCRIPTION PART NUMBER
- DISCHARGE GAP 1-519-504-11
Example shown is for XR-4400; other models are similar.
Reference: Technical News ME-94013 PRINTED IN USA
Autoflagged - NO
PRINTED ON RECYCLED PAPER
Audio Products Service Bulletin No. xxx
