Image preview - the first page of the document



>> Download HFP0424 documenatation <<

Text preview - extract from the document

                                   Hi-Fi Products                                               CSA-13
                                   Service Bulletin
                                   Sony Service Company - Technical Services
                                   A Division of Sony Electronics Inc.
                                   Sony Drive, Park Ridge, New Jersey 07656


Model:      SS-U241                                                        No.    424
Subject: Removal and re-assembly of Speaker Grille                         Date: December 27, 1994


Symptom:
  (**)          Due to a temporary production change, the SS-U241 speakers manufactured in
                October and November of 1994 had the speaker grilles secured at the bottom two
                holes using Hot Melt glue. The applicable Serial Number range for this procedure is
                8044738 ~ 8058376.



Solution:       To service this speaker, pry the grille off as instructed in the Service Manual (see
                below). When the repair has been completed, re-attach the grill using a water based
                white glue to secure the bottom two holes.




Reference: Delano Fax 12/5/94                                                                  PRINTED IN USA
Autoflagged - NO
                                               PRINTED ON RECYCLED PAPER
Audio Products Service Bulletin No. xxx
