Image preview - the first page of the document



>> Download HFP0474 documenatation <<

Text preview - extract from the document

                                  Hi-Fi Products                                                 CSA-13
                                  Service Bulletin
                                  Sony Service Company - Technical Services
                                  A Division of Sony Electronics Inc.
                                  Sony Drive, Park Ridge, New Jersey 07656

Model:      MDS-101                                                           No.       474
Subject: No Playback of MO Discs                                              Date: March 25, 1996


Symptom:
  (51)         MO discs will display irregular movement on playback such as; no rotation, no focus
               servo, and ejecting. No problem seen when playing pre-recorded non-MO
               MiniDiscs.



Solution:      Replace C259 with the part listed below.


                      REF                 FORMER                                        NEW
                             DESCRIPTION           PART NUMBER            DESCRIPTION     PART NUMBER

                  C259          1UF/50V             1-126-193-11             1UF/50V          1-126-301-11
                             ELECTROLYTIC                                 ELECTROLYTIC
                              CAPACITOR                                    CAPACITOR




Reference: AU-95034                                                                              PRINTED IN USA
