Image preview - the first page of the document
>> Download SONY HCD-CP1 documenatation <<Text preview - extract from the document HCD-CP1
SERVICE MANUAL US Model
Canadian Model
AEP Model
UK Model
Note E Model
CD block, tape deck block and Australian Model
tuner pack are supplied with
the assembled block.
HCD-CP1 is the Amplifier, CD player,
Tape Deck and Tuner section in
CMT-CP1.
Dolby noise reduction manufactured under license Model Name Using Similar Mechanism NEW
from Dolby Laboratories Licensing Corporation. CD
"DOLBY" and the double-D symbol a are trade- CD Mechanism Type KSL-2130CCP/K1N
Section
marks of Dolby Laboratories Licensing Corporation. Optical Pick-up Name KSS-213C/K1N
Tape deck Model Name Using Similar Mechanism HCD-ED1
Section Tape Transport Mechanism Type CMAL1Z023A
SPECIFICATIONS
