Image preview - the first page of the document
>> Download SONY HCD-DR3 documenatation <<Text preview - extract from the document HCD-DR3/DR330/XB200
SERVICE MANUAL AEP Model
UK Model
HCD-XB200
E Model
HCD-DR3/DR330
Australian Model
HCD-DR3
HCD-DR3/DR330/XB200 is the tuner, deck,
CD and amplifier section in LBT-DR3/
DR330/XB200.
Manufactured under license from Dolby Laboratories CD Model Name Using Similar Mechanism HCD-G2500
Licensing Corporation.
SECTION Base Unit Type KSM-213ECM/C2NP
"DOLBY" and the double-D symbol a are trademarks
of Dolby Laboratories Licensing Corporation. Optical Pick-up Type KSS-213E/C2N
TAPE Model Name Using Similar Mechanism NEW
DECK
SECTION Tape Transport Mechanism Type CWL-44-RR
SPECIFICATIONS
Amplifier section MD/VIDEO IN (phono jacks): Wavelength 780
