Text preview - extract from the document
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
V LINEARITY (VLIN), V CORRECTION (VSCO), PIN AMP OSD POSITION ADJUSTMENT (DISP)
(PAMP) AND TRAPEZIUM (TRAP) ADJUSTMENTS
1. Input a color bar signal.
1. Input a cross-hatch signal. 2. Set to Service adjustment Mode.
2. Set to Service adjustment Mode. 3. Select DISP with and .
3. Select VLIN, VSCO, PAMP, and TRAP with and .
4. Adjust with and for the bar center.
4. Adjust with and for the best picture.
5. Write into the memory by pressing then .
5. Write the memory by Pressing then .
V LINEARITY(VLIN) SERVICE VP AFC 0
1000 0000
VS CORRECTION (VSCO) |||||||||||||||------------
ROTATION COIL ADJUSTMENT
PIN AMP (PAMP) 1. Input a monoscope signal.
2. Push Menu button on the Remote (RM-Y171).
3. Select "Set Up" Mode.
4. Select "Tilt Correction". Confirm that number (0) color
changes to red.
TRAPEZIUM (TRAP) 5. Push > (+) on the Remote (RM-Y171). Confirm that number
increases up to +5 and picture rotates clockwise.
6. Push . (+) on the Remote (RM-Y171). Confirm that number
decreases up to -5 and picture rotates counterclockwise.
7. Push > (+) on the Remote (RM-Y171). Return to 0.
V ANGLE (VANG), V BOW (VBOW), UPPER PIN (UCPN)
AND LOW PIN (LCPN) ADJUSTMENTS
SET-UP
1. Input a cross hatch signal.
2. Set to Service Adjustment Mode.
3. Select VVANG, VBOW, UCPN, and LCPN with and .
4. Adjust with and for the best picture.
5. Write the memory by Pressing then .
+5
Please use VANG data from 312. Adjust from 3 to12 only.
Channel Set-up
V ANGLE (VANG) Favorite Channel
Video Label
Language: English
0
V BOW (VBOW)
X Tilt Correction : 0
Menu
UPPER PIN (UCPN) -5
LOW PIN (LCPN)
-- 30 --
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
6-1 BLOCK DIAGRAM (1/5) (KV-32FS10/32FV15/34FV10/34FV15/34FV15C/34FV15K/34FV15T/36FS10/36FV15/38FV15K) SECTION 6 DIAGRAMS
-- 31 -- -- 32 -- -- 33 --
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
6-2 BLOCK DIAGRAM (2/5) (KV-32XBR250/34FX250C/36XBR250/38FX250/38FX250C/38FX250T)
-- 34 -- -- 35 -- -- 36 --
FOLDOUT 31-36 2 5/10/99, 8:15 AM
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
6-3 BLOCK DIAGRAM (3/5) (ALL MODELS)
6-4 BLOCK DIAGRAM (4/5)
(KV-32FV15/34FV15/34FV15C/34FV15K/34FV15T/36FV15/38FV15K)
-- 37 -- -- 38 -- -- 39 -- -- 40 --
FOLDOUT 37-44 1 5/10/99, 8:17 AM
KV-32FS10/32FV15/32XBR250/34FV10/34FV15/34FV15C/34FX250C/34FV15K
34FV15T/36FS10/36FV15/36XBR250/38FX250/38FX250C/38FX250T/38FV15K
6-6. CIRCUIT BOARDS LOCATION
6-5 BLOCK DIAGRAM (5/5)
(KV-32XBR250/34FX250C/36XBR250/38FX250/38FX250C/38FX250T) ALL MODELS (Except KV-32XBR250/34FX250C (KV-32XBR250/34FX250C/36XBR250 A [ MICON, Y/C/J, TUNER, PIN-MOD, V-DEF, H-DEF ]
A BOARD LOCATOR LIST
36XBR250/38FX250/38FX250C/38FX250T 38FX250/38FX250C/38FX250T ONLY)
1 2 3 4 5 6 7 8 9 10 11 12 DIODE IC
D001 A-5 IC001 B-2
HX HX
D002 D-2 IC002 C-2
D003 A-5 IC352 D-9
C C A D004 C-2 IC353 D-10
D011 A-5 IC354 C-9
D012 C-1 IC355 D-5
HB HB D013 C-5 IC501 G-2
D014 D-3 IC561 G-6
D015 C-3 IC1001 D-8
WA D016 D-4 TRANSISTOR
WA B D018 D-4 Q001 A-5
HA HA D019 C-8 Q002 C-4
D301 C-7 Q003 H-1
D302 E-3 Q004 H-1
G/GA G/GA
D303 D-4 Q005 B-5
A A D368 C-7 Q006 H-1
D384 F-6 Q007 I-1
AK AK C D388 C-6 Q010 D-3
UY UX
D501 H-2 Q011 D-3
T D502 I-8 Q012 D-3
D503 I-8 Q013 D-3
6-7. PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS D504 I-7 Q014 D-3
D505 I-6 Q015 D-3
