Image preview - the first page of the document
>> Download SONY RDR-HX900 DVD RECORDER documenatation <<
Text preview - extract from the document
RDR-HX900 RMT-D206P
SERVICE MANUAL AEP Model
UK Model
SPECIFICATIONS
System LINE 1 -TV: 21-pin
Laser: Semiconductor laser CVBS IN/OUT
Channel coverage: S-Video/RGB OUT (upstream)
PAL/SECAM (B/G, D/K, I, L) LINE 3/DECODER: 21-pin
VHF: E2 to E12, R1 to R12, F1 to F10, Italian CVBS IN/OUT
A to H, Ireland A to J, South Africa 4 to 13/ S-Video/RGB IN
UHF: E21 to E69, R21 to R69, B21 to B69, S-Video OUT (downstream)
F21 to F69/CATV: S01 to S05, S1 to S20, Decoder
France B to Q/HYPER: S21 to S41 DV IN: 4-pin/i.LINK S100
DIGITAL OUT (OPTICAL): Optical output
