Image preview - the first page of the document
>> Download SONY XM-SD46X POWER AMPLIFIER-ver.1-2004 documenatation <<Text preview - extract from the document XM-SD46X
SERVICE MANUAL US Model
Canadian Model
Ver. 1.0 2004. 12
AEP Model
UK Model
E Model
SPECIFICATIONS
AUDIO POWER SPECIFICATIONS (US MODEL)
POWER OUTPUT AND TOTAL HARMONIC DISTORTION
60 watts per channel minimum continuous average power into
4 ohms, both channels driven from 20 Hz to 20 kHz with no more
than 0.08% total harmonic distortion per Car Audio Ad Hoc
Committee standards.
Other Specifications
Circuit system OTL (output transformerless) circuit Input level adjustment range
Pulse power supply 0.3
